Page 1
SNMP Manageable Media Converter Chassis Installation Manual This manual contains information to help with the installation and operation of Black Box Corporation's series of SNMP Manageable Media Converters: LMC100C-M LMC100C-S LMC120A LMC120A-DC LMC121A LMC121A-DC LMC600A LMC600A-DC LMC601A LMC601A-DC LMC130C-ST LMC130C-SC...
Page 2
Disclaimer Black Box Corporation makes no warranties with respect to this document and disclaims any implied warranties of merchantability or fitness for a particular purpose. Black Box Corporation assumes no responsibility for any errors that may appear in this document or for incidental consequential damages in connection with the performance or use of this material.
Chapter 1 Introduction About SNMP Manageable Media Converters As networks grow in size and complexity, the ability to quickly detect problems and determine where they reside in your network becomes increasingly important. Using interchangeable media conversion modules that can be installed in any combination, the SNMP Manageable Media Converter series of products (including SNMP Manageable 12-Slot Telco Chassis and SNMP Manageable 6-Slot Chassis) not only can meet virtually any installation...
The following SNMP Management Modules are available: SNMP Management Master Module — includes two RJ-45 connectors, one for a 10 Mbps Ethernet connection, the other for a serial RS-485 connection (LMC100C-M) SNMP Management Slave Module — includes two RJ-45 connectors for two serial RS-485 connections (LMC100C-S) About SNMP Manageable 12-Slot Telco Chassis Figure 1.2 SNMP 12-Slot Telco Chassis with SNMP Master Module...
Each SNMP Telco Chassis includes one 50-pin Telco connector, supporting up to twelve 10 Mbps Ethernet ports, and comes with one 2 ft. Telco cable. The following SNMP Telco Chassis versions are available: SNMP Telco Chassis 1U — rackmountable for 1 - 12 conversions;...
SNMP Telco Module, TP — 10 Mbps Ethernet; includes one RJ-45 connector for a Telco to twisted pair conversion (LMC133C) SNMP Telco Module, BNC — 10 Mbps Ethernet; includes one BNC connector for a Telco to thin coaxial conversion (LMC134C) About SNMP Manageable 6-Slot Chassis Figure 1.3 SNMP 6-Slot Chassis with SNMP Master Module SNMP Manageable 6-Slot Chassis (hereafter referred to as SNMP...
SNMP 6-Slot Chassis-DC 1U — rackmountable for 1 - 6 conversions; includes one -48 VDC power supply and slot for installing second power supply (LMC600A-DC) SNMP 6-Slot Chassis 2U — rackmountable for 1 - 6 conversions; includes one universal power supply (90/240 VAC) and slot for installing second power supply (LMC601A) SNMP 6-Slot Chassis-DC 2U —...
Page 9
SNMP TX/FX-SingleMode — 100 Mbps Fast Ethernet; includes one RJ-45 connector and one pair ST (LHC615C-ST) or SC (LHC615C-SC) connectors; 1300 nm single- mode fiber optic SNMP TX/FX-SingleMode/PLUS — same as above with higher power budget; includes one pair ST (LHC616C-ST) or SC (LHC616C-SC) connectors SNMP S2MM 1300 MultiMode to 1300 SingleMode —...
Chapter 2 Hardware Installation SNMP Media Converters can be installed as either managed or unmanaged devices. Hardware installation information for both is included in this chapter. If the SNMP Media Converter is to be a managed device, refer to the SNMP Software Installation Manual (included with an SNMP Master Module) for information regarding software installation.
Power supplies are available in 90/240 VAC or -48 VDC power versions. If the chassis is shipped with only one power supply module, a blank bracket covers the slot where a second power supply module can be installed. To install a power supply module in an SNMP Telco Chassis or SNMP 6-Slot Chassis, remove the blank bracket covering the slot where the module is to be installed by removing the screws located closest to the outside edges of the bracket.
Installing a Managed SNMP Media Converter The hardware installation for a managed SNMP Media Converter is similar to that of an unmanaged SNMP Media Converter, except that each managed SNMP Media Converter has to either have an SNMP Master or Slave Module installed. Slave SNMP Media Converters must be connected to a Master SNMP Media Converter.
The SNMP Master Module is connected to the LAN via an external 10Base-T hub connection. The SNMP Slave Module provides an SNMP management uplink to the SNMP Master Module. Once each Slave is installed, it has to be connected to the Master SNMP Media Converter (either directly or through another Slave connected to a Master).
Connecting a Slave SNMP Media Converter Slave SNMP Media Converters are connected to a Master SNMP Media Converter via a straight-through, twisted pair cable. Master and Slave SNMP Media Converters communicate via an RS-485 connection. Multiple Slave SNMP Media Converters are connected in a daisy-chain configuration.
LEDs on SNMP Master Modules The diagram below shows the LEDs, and their locations, on an SNMP Master Module. Figure 2.5 SNMP Master Module The LEDs on SNMP Master Modules function the same regardless of the type of SNMP Manageable Modules that are installed. The LED functions are as follows: Glows green when a link is established with the device the Master SNMP Media Converter is connected to via...
type of SNMP Manageable Modules that are installed. The LED functions are as follows: SNMP Active Glows amber when using SNMP Glows green when power supply One has power Glows green when power supply Two has power LinkLoss and FiberAlert Since media converters are a transparent link in a network, twisted pair and fiber SNMP Manageable Modules feature LinkLoss.
the near side of the fiber segment nor the twisted pair segment will be affected. Figure 2.9 Application with LinkLoss and FiberAlert Disabled As shown in Figure 2.10, using the same application, if LinkLoss is enabled on the near side and FiberAlert is enabled on the far side, the near side will be notified of any fiber link faults on the far side, thus eliminating “silent failures.”...
Page 18
problem resides with the fiber segment. If LinkLoss is disabled and the connection between the SNMP Media Converter and the hub/switch is NOT reestablished, the failure resides with the twisted pair segment. When a failure occurs, check that cables are properly connected.
Chapter 3 Technical Specifications Telco Cable and Connector Pinouts Each SNMP Telco Chassis comes with one 2ft. Telco cable. If a longer cable is necessary, a standard, 25-pair Category 3 Telco cable may be used. When using a standard Telco cable with a right-angle connector hood, one jackscrew on the SNMP Telco Chassis’...
Fiber Optic Cleaning Guidelines Fiber Optic transmitters and receivers are extremely susceptible to contamination by particles of dirt or dust, which can obstruct the optic path and cause performance degradation. Good system performance requires clean optics and connector ferrules. 1) Use fiber patch cords (or connectors, if you terminate your own fiber) only from a reputable supplier;...
3) Hold boards by the edges only; do not touch the electronic components or gold connectors. 4) After removal, always place the boards on a grounded, static free surface, ESD pad or in a proper ESD bag. Do not slide the board over any surface.
7:00 AM Monday to midnight Friday; 8:00 AM to 4:00 PM Saturday (EST) Fax: (724) 746-0746 or in North America 1-800-321-0746 Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Technical Support and fax orders 24 hours a day Warranty Please contact Black Box Corporation for warranty information.
(89/336/EEC) and the Council Directive on Electrical Equipment Designed for use within Certain Voltage Limits (73/23/EEC). For further details, contact Black Box Corporation. NOTE: Modules are FCC approved and UL, TUV/GS and CE certified when installed in a Black Box chassis only.
