7.11.3 Hook and loop foot strap (Fig. 39)
Drill holes from below through the more posterior section of the footplate at the desired positions.
Attach the foot straps with the two screws positioned beside one another to the footplate and
tighten with knurled nuts below the footplate. Should straps be necessary also over the forefoot,
fit them the same way.

7.12 Grab Rail and Grab Rail Padding

First insert the longer part of the grab rail
knobs point towards the front. Then insert the shorter end into the second fixture while pressing
the spring knob.
Open the grab rail by both pressing the spring knob and pulling the rail up to remove it.
Thread grab rail padding onto the grab rail.
39
(Fig. 40) into the seat fixture. Make sure that the spring
40
61
