Battery Installation - Currie tech IZIP VIA URBANO Assembly Manual

P
Charger port location
R
Battery release button
Battery
Battery
Charging
The Via Urbano battery can be charged while inside the bike, or it can be
removed and charged separately. The charger port is located on the right side
of the frame, near the center folding hinge. (Photo P)
Removal
To remove the battery pack from the frame:
1.
Fold the frame in half at the center hinge
terminals; be careful not to cross them with your fingers or jewelry.
2.
Press the battery release button while pulling the battery out of
the frame.
The battery fits tightly into the frame to prevent vibration, so it
may initially be difficult to remove.
Installation
To re-insert the battery pack:
Push the battery back into the frame, making sure the release button lines up
and "pops" through its hole
Currie Technologies
Technical and Customer Service
. This will expose the battery
1-800-377-4532
