Unpacking And Preparation - Currie tech IZIP VIA URBANO Assembly Manual

A
B
Tab
(push to unlock QR lever)
Steering column
Please recycle
packaging materials!
Swing QR lever open
Hinge

Unpacking and Preparation

1.
Carefully remove the
bicycle from the box.
You should have a friend
help you with this, as it is
heavy. If you are alone, you
can lay the box on its side
and gently slide the bike
Stand the bicycle
out.
upright on its fork and
rear wheel. (photo A).
2.
Find the parts box and
charger box.
The charger
is in a brown cardboard
box, the parts box is small
and white. Inside the parts
box you will find the tools
and components you need
to complete this assembly.
3.
Cut the zip-ties holding
the front wheel to the
bike frame set the
, then
wheel aside for now.
Make sure the fork is
properly aligned to the
bike
; the disc brake caliper (black box attached to one of the fork legs)
should be on the left side of the bicycle when the fork is rotated correctly.
4.
Remove the packaging from the front of the bike, exposing the steering
Push the silver tab to unlock the quick-release
column and hinge.
(QR) lever on the steering column, then open the lever
photo B. Raise the steering column, then close the quick-release
to lock the column in position (photo C).
lever
Currie Technologies
Technical and Customer Service
C
as shown in
1-800-377-4532
