Viper Dragon DR2000DC Dust Control Owner's Manual page 4

Operation of High Speed Floor Machine
*THIS IS A SPECIALIZED
WHICH REQUIRES THE OPERATOR TO
UTILIZE A VIPER APPROVED PAD, AND
MUST BE ADJUSTED PROPERLY TO
ENSURE THE
PERFORMANCE AND PRODUCTIVITY.
*Read operators manual thoroughly prior
to operating or servicing this machine.
GENERAL USE
1] Remove any obstructions
obstacles in the area which is to be
cleaned.
2] Remove dust recovery bag and empty it
out in a trash receptacle.
dust recovery bag on machine, ensuring
it is sealed tightly to the machine.
3] Place handle in upright position and tilt
machine back until handle rests on the
floor.
*Be sure the machine is not plugged into
an outlet.
4] Remove the pad center gripping device
by unscrewing the thumbscrews.
5) Place a "Viper approved" burnishing pad
on the pad driver and re-attach the
center gripping device. (check with your
Viper distributor for approved pads)
6] Place machine back into its upright
position.
7] Plug power cord into grounded outlet.
*Do not use an extension cord in
conjunction with the standard power
cord.
MACHINE
HIGHEST POSSIBLE
or other
Replace
8] The handle height may be adjusted by
lifting up on the handle release lever,
located on the right side of the
switch housing.
lower handle to desired operating
position.
handle into place.
9] To start the machine, push on the red
safety release button located on the
top of the switch housing and
squeeze either switch lever.
10) Once the machine has reached
operating speed, look at the digital pad
pressure meter located on the top of
the motor cover. There are 3 light
colors which will help you determine
optimal pad pressure for operating the
machine. RED LIGHT(S): If one or both
red lights are illuminated, stop the
machine and turn the pad pressure
2
Pull trigger and
Release trigger to lock
