Summary of Contents for Winmate FA30

  • Page 1 FA30 Motherboard SBC with Freescale iMX6Q Processor User Manual / Engineering Spec. Version 1.0...
  • Page 2: Fcc Statement

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at him own expense. FA30 Motherboard User Manual...
  • Page 3: Copyright Notice

    Applications that are described in this manual are for illustration purposes only. Winmate Communication Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
  • Page 4: Packing List

    In addition, free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products. Please do not hesitate to call or e-mail us. FA30 Motherboard User Manual...
  • Page 5: Safety Precautions

    CPU card. Modern electronic devices are very sensitive to static electric charges. As a safety precaution, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. FA30 Motherboard User Manual...
  • Page 6 F. The equipment has obvious signs of breakage. 15. Do not leave this equipment in an uncontrolled environment where the storage temperature is below -20° C (-4°F) or above 60° C (140° F). It may damage the equipment. FA30 Motherboard User Manual...
  • Page 7: Revision History

    FA30 Motherboard User Manual / Engineering Spec. Revision History Version Date Note Author 2014.08.27 First Release Woody Huang FA30 Motherboard User Manual...
  • Page 8: Table Of Contents

    CN18: LED Backlight Power ..................... 13 2.4.5 CN13: SPK_L ........................13 2.4.6 CN14: SPK_R ........................13 2.4.7 CN15: Headphone ......................13 2.4.8 CN16: Mic ........................13 2.4.9 CN20: HDMI FPC Connector ................... 13 2.4.10 CN6: SD Card Slot ....................... 14 FA30 Motherboard User Manual...
  • Page 9 CN7: RJ45 LAN Connector ..................15 2.4.17 CN12: Keypad Connector ................... 15 2.4.18 CN5: Isolated Expansion Port ..................15 2.4.19 CN21: 24V DC in for Expansion Port ................16 2.4.20 CN4: mSATA SSD Connector ..................16 FA30 Motherboard User Manual VIII...
  • Page 10 FA30 Motherboard User Manual / Engineering Spec. FA30 Motherboard User Manual...
  • Page 11: General Information

    FA30 Motherboard User Manual / Engineering Spec. General Information This chapter includes the FA30 Motherboard background information. Sections include:  Introduction  Feature  Motherboard Specification  Function Block  Board Dimensions FA30 Motherboard User Manual...
  • Page 12: Chapter 1 General Information

    Motherboard User Manual / Engineering Spec. Chapter 1 General Information 1.1 Introduction FA30 SBC is an integrated package that provides customers a complete RISC platform for project evaluation, application development and solution feasibility testing that decreases lead-time and lowers initial cost and investment.
  • Page 13: Motherboard Specifications

    1 x mSATA SSD Slot 1 x keypad by FPC connector Dimensions 144 mm x 115.28 mm Operating temperature: -10 deg. C to 60 deg. C Mechanical & Operating Humidity: 10 ~ 90% Relative humidity, environmental non-condensing FA30 Motherboard User Manual...
  • Page 14: Function Block

    FA30 Motherboard User Manual / Engineering Spec. 1.4 Function Block FA30 Motherboard User Manual...
  • Page 15: Board Dimensions

    FA30 Motherboard User Manual / Engineering Spec. 1.5 Board dimensions FA30 Motherboard User Manual...
  • Page 16 FA30 Motherboard User Manual / Engineering Spec. FA30 Motherboard User Manual...
  • Page 17 FA30 Motherboard User Manual / Engineering Spec. Installations This chapter provides information on how to use the jumps and connectors on the FA30 Motherboard. The Sections include:  I / O Equipment Installation  Switches and Connectors  Switch Setting ...
  • Page 18: Chapter 2 Installations

    10/100/1000 Mbps Ethernet protocol compatible. It is supported by major network operating systems. 2.1.4 USB ports FA30 have four USB port which two as A-type connector and others as pin-header. The USB ports support hot-plug connection. 2.1.5 Isolated CAN BUS Two CANBUS combined in one connector and with isolated design.
  • Page 19: Led Backlight Power Supply

    Power Input Connector Connector (L/R) Headphone HDMI FPC Connector mSATA SD Card Slot SSD Slot Micro USB Micro USB Debug Port 24V DC input for 2*USB expansion Wafer port BT1-Button Cell Battery connector CN12- Keypad FPC connector FA30 Motherboard User Manual...
  • Page 20: Switch Setting

    Engineering Spec. 2.3 Switch Setting There are 3 switches on FA30 and the switch setting combination will decide its boot up path such as from eMMC, mSATA SSD or SD card. If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes.
  • Page 21: Connectors And Pin Assignment

    RJ45 LAN Connector RJ45 LAN Connector CN12 Keypad Connector 4p P:1.0mm for FPC Isolated Expansion Port 2*Device port and 3p GPIO CN21 24V DC in for Expansion Port 4Pin header mSATA SSD Connector Mini PCIe Socket FA30 Motherboard User Manual...
  • Page 22: Cn8: 12V Dc Input

    Touch_I2C2_SCL Touch_VCC Touch_RST 2.4.3 CN17: LVDS Connector Pin No. SYMBOL Pin No. SYMBOL LCDVDD LVDS0_TX0_N_F LVDS1_TX0_N_F LCDVDD LVDS0_TX0_P_F LVDS1_TX0_P_F LCDVDD LVDS0_TX1_N_F LVDS1_TX1_N_F LVDS0_TX1_P_F LVDS1_TX1_P_F LVDS0_TX2_N_F LVDS1_TX2_N_F LVDS0_TX2_P_F LVDS1_TX2_P_F LVDS0_CLK_N_F LVDS1_CLK_N_F LVDS0_CLK_P_F LVDS1_CLK_P_F LVDS0_TX3_N_F LVDS1_TX3_N_F LVDS0_TX3_P_F LVDS1_TX3_P_F FA30 Motherboard User Manual...
  • Page 23: Cn18: Led Backlight Power

    GND_ANALOG Headphone_L GND_ANALOG Headphone_R GND_ANALOG 2.4.8 CN16: Mic NAME NAME MICROPHONE_DET GND_ANALOG MIC_RAW GND_ANALOG MICBIAS2_RAW GND_ANALOG 2.4.9 CN20: HDMI FPC Connector NAME NAME NAME NAME DDC_DATA TMDS0- HPD1 TMDS2- TMDS0+ TMDS2+ TMDS1- TMDS1+ CLK+ DDC_CLK CLK- FA30 Motherboard User Manual...
  • Page 24: Cn6: Sd Card Slot

    2.4.11 CN11: Micro USB(OTG) NAME NAME OTG_VBUS USB_OTG_CON_DN USB_OTG_CON_DP USB0_OTG_ID 2.4.12 USB Wafer (2*USB) SYMBOL SYMBOL USBVCC USBVCC USB - USB - USB + USB + 2.4.13 CN1: CANBUS Connector NAME NAME CANL_2_CONN_L CANL_1_CONN_L CANH_2_CONN_L CANH_1_CONN_L FA30 Motherboard User Manual...
  • Page 25: Cn3: Dual Usb 2.0 A-Type

    GLED TX1- DGND TX4- OLED TX2+ TX3+ YLED SHIELD TX2- TX3- LED GND SHIELD 2.4.17 CN12: Keypad Connector NAME NAME CPUPWRON_C DIMM-_C DIMM+_C 2.4.18 CN5: Isolated Expansion Port NAME NAME Digital Input Digital Input Digital Input FA30 Motherboard User Manual...
  • Page 26: Cn21: 24V Dc In For Expansion Port

    NAME NAME RESERVED RESERVED +3.3V +1.5V +3.3V RESERVED RESERVED RESERVED RESERVED SMB_CLK RESERVED RESERVED +1.5V RESERVED SMB_DATA VENDOR RESERVED RESERVED RESERVED RESERVED VENDOR RESERVED +1.5V RESERVED RESERVED DA/DSS RESERVED +3.3V RESERVED RESERVED DET# RESERVED +3.3V +3.3V FA30 Motherboard User Manual...
