Winmate FA33 User Manual

Motherboard sbc with freescale imx6 dual core processor
Hide thumbs Also See for FA33:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
FA33 Motherboard
SBC with Freescale iMX6 Dual Core Processor
User Manual / Engineering Spec.
Version 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FA33 and is the answer not in the manual?

Questions and answers

Related Manuals for Winmate FA33

Summary of Contents for Winmate FA33

  • Page 1 FA33 Motherboard SBC with Freescale iMX6 Dual Core Processor User Manual / Engineering Spec. Version 1.1...

  • Page 2: Fcc Statement

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at him own expense. FA33 Motherboard User Manual...

  • Page 3: Copyright Notice

    Applications that are described in this manual are for illustration purposes only. Winmate Communication Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
  • Page 4 Declaration Note!  Winmate Products are shipped without root access to Android operating system. However, Winmate can provide support for access upon special request by contacting Winmate Sales Caution!  Rooting is a process that allows users to attain root access to the Android Operating System Code.

  • Page 5: Packing List

    In addition, free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products. Please do not hesitate to call or e-mail us. FA33 Motherboard User Manual...

  • Page 6: Safety Precautions

    CPU card. Modern electronic devices are very sensitive to static electric charges. As a safety precaution, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. FA33 Motherboard User Manual...
  • Page 7 F. The equipment has obvious signs of breakage. 15. Do not leave this equipment in an uncontrolled environment where the storage temperature is below -40° C (-40°F) or above 70° C (157° F). It may damage the equipment. FA33 Motherboard User Manual...
  • Page 8 Revision History Version Date Note Author 2015.04.13 First Release Jimmy Chen CPU changed to 2015.09.01 Jimmy Chen dual core FA33 Motherboard User Manual...

  • Page 9: Table Of Contents

    MIPI Camera Connector (CON1) ................14 2.1.16 DIDO Connector (CN9) ....................14 2.1.17 Light Sensor Connector (CN7) ..................15 2.1.18 SPI Connector (CN18) ....................15 2.1.19 OTG (CN32) ........................ 15 2.1.20 Jumper Setting Description................16 VIII FA33 Motherboard User Manual...
  • Page 10 Boot Modes (SW1) ......................16 2.2.1 Backlight power selector (JP2) ..................16 2.2.2 Panel Power Selector (JP1) ..................... 16 2.2.3 Brightness Adjust Mode Selector (JP4) ................17 2.2.4 FA33 Motherboard User Manual...
  • Page 11 General Information This chapter includes the FA33 Motherboard background information. Sections include:  Introduction  Feature  Motherboard Specifications  Function Block  Board Dimensions FA33 Motherboard User Manual...

  • Page 12: Chapter 1 General Information

    Chapter 1 General Information 1.1 Introduction FA33 SBC is an integrated package that provides customers a complete RISC platform for project evaluation, application development and solution feasibility testing that decreases lead-time and lowers initial cost and investment. In peripheral connectivity, FA33 SBC features with two COM port, two USB 2.0 A-type connectors, one LAN port support PoE function, one DC...

  • Page 13: Motherboard Specifications

    146 mm x 101 mm (3.5” form factor) Dimensions Operating temperature: -25 deg. C to 65 deg. C Mechanical & Operating Humidity: 10 ~ 90% Relative humidity, environmental non-condensing Power Input DC IN 12V Power Consumption FA33 Motherboard User Manual...

  • Page 14: Function Block

    1.4 Function Block FA33 Motherboard User Manual...

  • Page 15: Platform Descriptions

     2D graphics accelerator  Dedicated OpenVG 1.1 accelerator 1.5.2 System Memory: 1.35V DDR3L SDRAM 1.5.3 LAN Chip: AR8031 integrated 10/100/1000 Mbps Ethernet Transceiver 1.5.4 HD Audio Codec: WM8962 Ultra-Low Power Stereo CODEC with Audio Enhancement FA33 Motherboard User Manual...
  • Page 16 Installations This chapter provides information on how to use the jumps and connectors on the FA33 Motherboard. The Sections include:  I / O Connector Description  Jumpers Setting Description FA33 Motherboard User Manual...

  • Page 17: Chapter 2 Installations

    Chapter 2 Installations 2.1 I/O Connector Description 2.1.1 DC Jack (CN24) Power Conn (CN29) CN24 CN29 Pin No SYMBOL Pin No SYMBOL FA33 Motherboard User Manual...

  • Page 18: D-Sub 9 Com Port (Cn27 & Cn28)

    ※ VIN:12V 2.1.2 D-Sub 9 COM Port (CN27 & CN28) Pin No SYMBOL SOUT RI(5V) 2.1.3 External USB 2.0 (CN21) Pin No Symbol Pin No Symbol 2.1.4 Speaker Out (CN12 & CN14) FA33 Motherboard User Manual...

  • Page 19: Mic Connector (Cn10)

    HDMI_CLKM HDMI_CEC_OUT H_CLK_OUT H_DAT_OUT HDMI_5V 2.1.7 Backlight Connector (JP2) Connector type: Wafer 7 PIN pitch 2.0 mm Pin Assignment Name Name +BKLPWR BRIGHTNESS +BKLPWR +BKLPWR Backlight enable Refer to JP4 jumper setting for brightness mode select. FA33 Motherboard User Manual...

  • Page 20: Lvds Connector (Cn4)

    LVDS1_TX1_N LVDS1_TX1_P LVDS1_TX2_N LVDS1_TX2_P LVDS1_CLK_N LVDS1_CLK_P LVDS1_TX3_N LVDS1_TX3_P 2.1.9 Internal USB 2.0 Connector (USB 1 , USB 2) Connector type : 2*4p Wafer, P:2.0mm Pin Assignment (USB 1) Name Name VUSB_VBUS5 VUSB_VBUS4 USB_PN5 USB_PN4 USB_PP5 USB_PP4 FA33 Motherboard User Manual...

  • Page 21: Msata Card Slot (Cn15)

    Pin Assignment (USB 2) Name Name VUSB_VBUS3 VUSB_VBUS2 USB_PN3 USB_PN2 USB_PP3 USB_PP2 2.1.10 mSATA card slot (CN15) Connector type : mini-PCIE slot, H: 6.8mm Name Name +V3.3S +V1.5S SATA_RXP1 +V3.3S SATA_RXN1 +V1.5S SATA_TXN1 SATA_TXP1 +V3.3S +V3.3S +V1.5S SSD_LED# +V3.3_3G FA33 Motherboard User Manual...

  • Page 22: Rj45 Poe Connector (Lan1)

    MDI3- MDI0- MDI0+ TRCT1 PoE_A1+ PoE_A1- PoE_A2+ PoE_A2- LAN1_1000_O LAN1_100_10_G LAN1_ACTIVE_Y Internal COM (CN1) Name Name IO_DCDC# IO_DSRC# IO_SINC IO_RTSC# IO_SOUTC IO_CTSC# IO_DTRC# IO_RIC# OR 5V 2.1.12 Debug Connector (J1) Pin Assignment Name TXD233 RXD232 DBUG_VBUS FA33 Motherboard User Manual...

  • Page 23: Can Bus Connector (Cn3)

    On / Off Connector (CN22) Name CPUPWRON CPUPWRON Reset Connector (CN25) Name +V3.3S PWRON 2.1.13 CAN BUS Connector (CN3) Pin Assignment Name Name +V_CAN_A CAN1_RX CAN1_TX 2.1.14 UART Connector (CN19) Pin Assignment Name Name VUART UARTTXD UARTRXD FA33 Motherboard User Manual...

  • Page 24: Buzzer Connector (Cn16)

    MIPI_CSI_D1P MIPI_CSI_D1M MIPI_CSI_CLKP MIPI_CSI_CLKM MIPI_CSI_D0P MIPI_CSI_D0M MCLK_1V8 GEN_2V8 GEN_1V8 LED_FLASH- 2.1.17 DIDO Connector (CN9) Connector type : Header 2 x 5pin, P:2.0mm Pin Assignment Name Name DIO +5V DOUT3_L DOUT1_L DOUT2_L DOUT0_L DIN3_L DIN1_L DIN2_L DIN0_L FA33 Motherboard User Manual...

  • Page 25: Light Sensor Connector (Cn7)

    2.1.18 Light Sensor Connector (CN7) Pin Assignment Name Name LED_B# Light_PWR LED_R# LED_G# LS_DATA LS_CLK 2.1.19 SPI Connector (CN18) Pin Assignment Name Name +V3.3S ECSPI3_MISO ECSPI3_MOSI ECSPI3_CS1 ECSPI3_SCLK 2.1.20 OTG (CN32) Pin Assignment Name Name VUSB_VOTG USB_OTG_CON_DN USB_OTG_CON_DP USB_OTG_ID FA33 Motherboard User Manual...

  • Page 26: Jumper Setting Description

    2.2 Jumper Setting Description 2.2.1 Boot Modes (SW1) PIN1 PIN2 Boot from fuses (default) Serial downloader Boot from board settings Reserved 2.2.2 Backlight power selector (JP2) Name INVERTER +V5S 2.2.3 Panel Power Selector (JP1) 3.3Volts 5Volts 12Volts FA33 Motherboard User Manual...
  • Page 27 2.2.4 Brightness Adjust Mode Selector (JP4) FA33 Motherboard User Manual...
