Canon imagePROGRAF iPF6000S User Manual page 425

Setting Item
H
Orientation
K
Rotate Page 90 degrees
(Conserve Paper)
L
Paper Source
M
Roll Paper Width
N
Roll Paper Options
P
Output Method
O
Size Options
S
Defaults
Downloaded from ManualsPrinter.com Manuals
Choose the printing orientation.
Making the Original Orientation Match the Paper Orientation (→P.353)
Activate this setting to rotate the document image by 90 degrees before
printing.
Conserving Roll Paper by Rotating Originals 90 Degrees (→P.333)
Choose the feed source, as desired.
Options displayed in the list vary depending on the selection in Media Type
on the Main sheet.
Choose the roll width.
For details on available roll widths, see "Paper Sizes". (→P.109)
Complete optional roll paper settings. Click to display the Roll Paper
Options dialog box.
A
Under Automatic Cutting, you can specify Yes or No and Print Cut
Guideline.
Cutting Roll Paper After Printing (→P.363)
B
Select Banner Printing when printing multiple pages continuously.
Printing Multiple Pages Continuously (→P.308)
Click to display the Output Method dialog box, which enables you to
complete the Output Method and Name of data to be saved settings.
Click to display the Paper Size Options dialog box, which enables you to
register additional paper sizes or select the size system for use.
Restores all settings on the sheet to the default values.
Description
Printer Driver
Windows Software 411
