- Page 1 X720B HD IR Waterproof Fixed IP Camera User’s Manual Version 1.1.0...
- Page 2 Welcome Thank you for purchasing our IP camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference!
- Page 3 Important Safeguards and Warnings Electrical safety All installation and operation here should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC.This series product supports PoE too. Please note: Do not connect these two power supplying sources to the device at the same time;...
- Page 4 Be sure to use all the accessories recommended by manufacturer. Before installation, please open the package and check all the components are included. Contact your local retailer ASAP if something is broken in your package. Accessory Name Amount X720B Unit Quick Start Guide Installation Accessories Bag...
- Page 5 Table of Contents ........................1 ........................1 ........................1 ........................ 2 ............................4 ................ 4 ..................4 ........................6 ......................8 ........................8 ........................8 ............................11 ............... 12...
- Page 6 Support record via Web and the recorded file are storage in the client-end Function l Support network storage function such as FTP. l The X720B supports one-channel video data transmit to network terminal and then decode. Delaying time is within 270ms (network bandwidth support needed) Network l...
- Page 7 Please refer to the following sheet for the X720B performance specification. Model X720B Series Parameter Main Processor TI Davinci high performance DSP Embedded LINUX System Support real-time network, local record, and remote operation at the Resources same time. User Interface...
- Page 8 Management 1- channel wire Ethernet port, 10/100 Base-T Ethernet Wire Network Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP, Network Protocol SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour, SNMP. Remote Monitor, system setup, file download, log information, maintenance , Operation upgrade and etc Restore...
- Page 9 You can refer to the following figure for multiple-function combination cable information. See Figure Figure 2-1 Please refer to the following sheet for detailed information. Port Name Function Connection Note Ethernet 1.LAN Network port Connect to standard Ethernet cable. port Power input 2.DC12V...
- Page 10 Figure 2-2 Figure 2-3...
- Page 11 Please follow the steps listed below to install the device. Please refer to Figure 3-1 and Figure 3-2 X720B for reference. l Paste the installation map on the surface of the wall or the ceiling. l Dig the installation holes according to the installation map.
- Page 12 Figure 3-2...
- Page 13 You can set the IP address, subnet mask and gateway for the camera and PC. Please note the camera IP address and PC IP address shall be in the same network segment if there is no router. The X720B default IP address is 192.168.1.108. If there is a router, please set the corresponding gateway and subnet mask.
- Page 14 Figure 4-2 Select the “Open Device Web” item; you can go to the corresponding web login interface. See Figure 4-3 Figure 4-3...
- Page 15 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set. In the configuration tool search interface (Figure 4-1), please select a device IP address and then double click it to open the login interface.
- Page 16 I cannot boot up Please click RESET button for at least five seconds to restore factory default setup. the device or operate properly. The water leakage The unauthorized front or rear cap remove many result in water occurred. leakage. The glass front cap has sustained heavy push or strike. The waterproof plug of the rear cap becomes loosen.
- Page 17 Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Circuit Board ○ ○ ○ ○ ○ ○ Component Device Case ○ ○ ○ ○ ○ ○ Wire and Cable ○ ○ ○ ○ ○ ○ Packing ○ ○ ○...
