  • Page 1 XP5000T Megapixel Indoor IP Camera User’s Manual Version 3.5.1...
  • Page 2 Welcome Thank you for purchasing our IP camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference!
  • Page 3 Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC or 24V AC in the IEC60950-1. Before you replace the SD card, please unplug the power cable and then remove the shell We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.
  • Page 4 Accessory Name Amount Unit C/CS adapter ring Quick Start Guide...

  • Page 5: Table Of Contents

    Table of Contents General Introduction ........................1 Overview ........................1 Feature ........................... 1 Specifications ........................ 2 1.3.1 Performance ......................2 1.3.2 Factory Default Setup ................... 4 Framework ..........................12 Rear Panel ........................12 Side Panel ........................16 Front Panel ........................16 Bidirectional talk......................
  • Page 6 3.4.1 Installation......................24 3.4.2 Remove ......................... 24 I/O Port ......................... 25 Quick Configuration Tool ......................27 Overview ........................27 Operation ........................27 Web Operation .......................... 30 Network Connection ....................30 Login and Logout ......................30 FAQ ............................33 Appendix Toxic or Hazardous Materials or Elements ............... 34...

  • Page 7: General Introduction

    1 General Introduction 1.1 Overview This series IP camera integrates the traditional camera and network video technology. It adopts audio video data collection, transmission, storage together. It can connect to the network directly without any auxiliary device. This camera uses standard H.264 video compression technology and PCM, G.711a/u audio compression technology, which maximally guarantees the audio and video quality.

  • Page 8: Specifications

    realize the network power supply.  To guarantee proper performance, please make sure the power sourcing device can supply at least 10W power.  Usually, do not use the PoE for the WIFI/3G device.  Day/Night mode auto switch (ICR switch.) ...
  • Page 9 Support customized setup. Flip Support Mirror Support Snapshot Max 1f/s snapshot. File extension name is JPEG Privacy Mask Each channel supports max 4 privacy mask zones Video Setup Support parameter setup such as bright, contrast. Video Channel title, time title, motion detect, privacy mask. Information Lens Optional...

  • Page 10: Factory Default Setup

    Weight 650g Installation Support various installation modes（Enclosure and bracket is optional） 1.3.2 Factory Default Setup Please refer to the following sheet for factory default setup information. Default Setup Setup Item XP5000T Brightness Contrast Sharpness Saturation Anti-flicker Outdoor Exposure Mode Auto...
  • Page 11 Default Setup Setup Item XP5000T Stream stream General type Encode H.264B mode Resoluti CIF(352*288/352*240) Frame PAL: 25 Rate NTSC:30 （FPS） Bit Rate Type Recomm 192-1024Kb/S ended Bit Bit Rate 1024 I Frame Snapsho General t Type Image 1080P（1920*1080） Snapshot Size...
  • Page 12 Default Setup Setup Item XP5000T Version 192.168.1.108 Address Subnet 255.255.255.0 Mask Default 192.168.1.1 Gateway Preferred 8.8.8.8 Alternate 8.8.8.8 Enable ARP/Pin Enable device IP address service Connecti 37777 TCP Port UDP Port 37778 HTTP Port Connection RTSP Port HTTPs Disable Port...
  • Page 13 Default Setup Setup Item XP5000T Update 10 minutes Period Trusted IP Filter Disable sites SMTP none Server Port Anonymit Disable User anonymity Name Passwor Sender none Authentic ation SMTP(Email) (Encrypti on mode) Title IPC Message (Subject) Attachme Enable Mail Receiver...
  • Page 14 Default Setup Setup Item XP5000T SNMP v1 Disable SNMP v2 Disable SNMP v3 Disable Enable Enable Bonjour Server “SN”. It depends on the device. Name Multicast 239.255.42.42 Address Multicast Port 36666 Real-time Monitor Comman Wireless Disable Enable Disable Anti- 5 seconds...
  • Page 15 Default Setup Setup Item XP5000T Activation Relay in Alarm 1 Anti- 0 second dither Sensor Type Record Enable Channel Record 10 seconds Delay Relay out Enable Alarm 10 seconds Delay Send Disable Email Disable Snapshot Disable Relay output Enable Disable...
  • Page 16 Default Setup Setup Item XP5000T Delay Enable Disable Record Enable Record 10 seconds Delay IP Conflict Relay out Enable Relay out 10 seconds Delay Week Sunday Enable Time 00:00:00 to 23:59:59 Schedule Disable Setup Motion Enable Detect Alarm Enable Record...
  • Page 17 Default Setup Setup Item XP5000T Date Y-M-D Format Time Format Time GMT+08:00 Zone System Sync PC Time Disable Date Week time Type Start 00:00:00 of the first Sunday of the month Time End Time 00:00:00 of the second Monday of the month Disable clock.isc.org...

  • Page 18: Framework

    2 Framework 2.1 Rear Panel This series IP camera real panel is shown as below. See Figure 2-1. The rear panel with the network port The rear panel with the 100M fiber port Figure 2-1 Please refer to the following sheet for detail information. Interface Name Connector Function...
  • Page 19 TV monitor to view video.  AC 24V/ DC 12V Power port Power port.  Input 12V DC or AC 24V  STATUS Red light System boot up- Indication Light red light is on  System upgrades-red light flashes  System resets- red light flashes.
  • Page 20 the external alarm device. Alarm output port Alarm output port. To output alarm signal to the alarm device.  NO: Normal open alarm output end.  C: Alarm output public end. Alarm input ground end. RS485 port RS485_A port, control external PTZ RS485_B port, control external PTZ...
  • Page 21 JACK port. from devices such as pick-up.  Network port Ethernet port Connect to standard Ethernet cable.  Support PoE function. 100M fiber port 155M single fiber Transmit 100M dual-direction SFP Ethernet data. fiber module SD card port Connect to SD card. Note ...

  • Page 22: Side Panel

    Please make sure the device is securely earthed to prevent the thunderstorm strike. 2.2 Side Panel Please refer to the following interface for side panel dimension information. The unit is mm. See Figure 2-2. Figure 2-2 2.3 Front Panel Please refer to the following interface for the front panel information. The unit is mm. See Figure 2-3.

  • Page 23: Bidirectional Talk

    Figure 2-3 2.4 Bidirectional talk 2.4.1 Device-end to PC-end Device Connection Please connect the speaker or the MIC to the audio input port in the device rear panel. Then connect the earphone to the audio output port in the PC. Login the Web and then click the Audio button to enable the bidirectional talk function.

  • Page 24: Alarm Setup

    2.5 Alarm Setup The alarm setup interface is shown as below. See Figure 2-4.  Connect the alarm input device to the alarm input port.  Connect the alarm output device to the alarm output port and alarm output public port. The alarm output port supports NO (normal open) alarm device only.

  • Page 25: Ir Light Connection

    If the type is NC, this button is normal off. The button becomes off when there is an alarm output. Figure 2-6 2.5.2 IR Light Connection Please refer to the following figure for external IR light information. See Figure 2-7. IR synchronization input signal.

  • Page 26: Installation

    3 Installation 3.1 Lens Installation 3.1.1 Auto Aperture Lens Please follow the steps listed below for auto aperture lens installation. The interface is shown as in Figure 3-1 and Figure 3-2.  Remove the CCD protection cap of the device, and then line up the lens to the proper installation position.

  • Page 27: Remove Lens

    Figure 3-2 3.1.3 Remove Lens Please follow the steps listed below to remove lens. The interface is shown as in Figure 3-3.  Turn the lens counter clockwise and then remove it from the camera.  Unplug the auto lens cable socket from the auto lens connector. If you are using the manual aperture lens, please skip to the following step.

  • Page 28: Remove

    Figure 3-4 Figure 3-5 3.2.2 Remove Please follow the steps listed below to remove SD card. The interface is shown as Figure 3-6.  Use the screwdriver to loosen the screw of SD card protection cap in the rear panel. Remove the cap from the camera.

  • Page 29: Remove

     Use the screwdriver to loosen the 3G card protection cap screw in the side panel, and then remove the 3G card protection cap from the camera.  Install the 3G card to the camera according to the proper installation position. ...

  • Page 30: Wifi Antenna

    3.4 3G/WIFI Antenna 3.4.1 Installation Line up the thread of the screw of the 3G/WIFI antenna to the thread of the rear panel. See Figure 3-10. Please turn according to the direction in the following figure until antenna is secure firmly. See Figure 3-11.

  • Page 31: I/O Port

    Use your hands to hold the 3G/WIFI thread end and then turn according to the following figure. See Figure 3-13. Now you can see the antenna is away from the thread. See Figure 3-14. Figure 3-13 Figure 3-14 Remove the 3G/WIFI antenna from the port of the rear panel. See Figure 3-15. Figure 3-15 3.5 I/O Port Install Cable...
  • Page 32 Use the small slotted screwdriver to press the corresponding button of cable groove. Insert the cable into the groove and then release the screwdriver. Remove Cable Please follow the steps listed below to remove the cable. Use the small slotted screwdriver to press the corresponding button of cable groove. Remove the cable out of the groove and then release the screwdriver.

  • Page 33: Quick Configuration Tool

    4 Quick Configuration Tool 4.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 4.2 Operation Double click the “ConfigTools.exe”icon, you can see an interface is shown as in Figure 4-1.
  • Page 34 Figure 4-2 Select the “Open Device Web” item; you can go to the corresponding web login interface. See Figure 4-3. Figure 4-3 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set.
  • Page 35 Please note the port information here shall be identical with the port value you set in TCP port in Web Network interface. Otherwise, you can not login the device. If you are using device background upgrade port 3800 to login, other setups are all invalid. Figure 4-4 After you logged in, the configuration tool main interface is shown as below.

  • Page 36: Web Operation

    5 Web Operation This series IPC product support the Web access and management via PC. Web includes several modules: monitor channel preview, PTZ control, system configuration, alarm and etc. 5.1 Network Connection Please follow the steps listed below for network connection. ...
  • Page 37 Figure 5-2 If it is your first time to login in, system pops up warning information to ask you whether install control webrec.cab or not after you logged in for one minute. Please click OK button, system can automatically install the control. When system is upgrading, it can overwrite the previous Web too. If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the control download.
  • Page 38 Figure 5-4 Please refer to the Web Operation Manual included in the resource CD for detailed operation instruction.

  • Page 39: Faq

    6 FAQ I can not boot up Please click RESET button for at least five seconds to restore the device or can factory default setup. not control the device. SD card hot swap Before draw out SD card, please stop record or snapshot first and then wait for at least 15 seconds to remove the SD card.

  • Page 40: Appendix Toxic Or Hazardous Materials Or Elements

    Appendix Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Circuit Board ○ ○ ○ ○ ○ ○ Component ○ ○ ○ ○ ○ ○ Case ○ ○ ○ ○ ○ ○ Wire and Cable Packing ○...
