- Page 1 X720D Mini IP Dome Camera User’s Manual Version 3.5.0...
- Page 2 Welcome Thank you for purchasing our IP camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference!
- Page 3 Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC in the IEC60950-1. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.
- Page 4 Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the device.
-
Page 5: Table Of Contents
Table of Contents General Introduction ........................1 Overview ........................1 Features ......................... 1 Specifications ........................ 2 1.3.1 Performance ......................2 1.3.2 Factory Default Setup ................... 3 Framework ........................... 9 Dimensions ........................9 Structure ........................10 Installation..........................12 Device Installation ...................... 12 SD Card Installation .................... -
Page 6: General Introduction
1 General Introduction 1.1 Overview This series IP camera integrates the traditional camera and network video technology. It adopts audio and video data collection, transmission together. It can connect to the network directly without any auxiliary device. This series IPC uses standard H.264 video compression technology and MJPEG audio compression technology, which maximally guarantee the audio and video quality. -
Page 7: Specifications
Support video watermark function to avoid vicious video modification. 1.3 Specifications 1.3.1 Performance Please refer to the following sheet for IPC performance specification. Model X720D Parameter Main TI Davinci high performance DSP Processor Embedded LINUX System Support real-time network, local record, and remote operation at the Resources same time. -
Page 8: Factory Default Setup
Installed in the places such as wall or the ceiling 1.3.2 Factory Default Setup Please refer to the following sheet for factory default setup information. Default setup Function Item Setup Type X720D Brightness Contrast Saturation Exposure mode Auto Gain Scope... - Page 9 Default setup Function Item Setup Type X720D Resolution 1080P（1920*1080） Frame rate PAL: 25 （FPS） NTSC:30 Bit stream type Reference 3584-6144 Kb/S bit rate Bit rate 8192 I frame interval Watermark Enable settings Watermark DigitalCCTV character Enable Enable Bit stream General...
- Page 10 Default setup Function Item Setup Type X720D Depends on the device address IP version IPV4 IP address 192.168.1.168 Subnet 255.255.255.0 mask Default 192.168.1.1 gateway Preferred 8.8.8.8 Alternate 8.8.8.8 Enable ARP/Pingto Enable address service connection TCP port 37777 Connection UDP port...
- Page 11 Default setup Function Item Setup Type X720D Authenticati on (Encrypt mode) Title IPC Message (Subject) Attachment Enable Main Receiver Interval Disable ，interval=60m Health email Enable UPnP Disable UPnP SNMP v1 Disable SNMP v2 Disable SNMP v3 Disable SNMP port Read...
- Page 12 Default setup Function Item Setup Type X720D Record Enable Channel Record 10 seconds Delay Send email Disable Snapshot Disable Enable Send email Enable Capacity limit (Space threshold) Send email Enable Send email Abnormity Enable Disable Record Enable Record delay Enable...
- Page 13 Default setup Function Item Setup Type X720D Language English Video NTSC standard Date format Y-M-D Time format Time zone GMT+08:00 Current Sync PC time Disable DTS type Week 00:00:00 of the first Sunday of the Start time month 00:00:00 of the second Monday of the...
-
Page 14: Framework
2 Framework 2.1 Dimensions Please refer to the following figure for the dimension information. The unit is mm. See Figure 2-1 through Figure 2-3. Figure 2-1 Figure 2-2... -
Page 15: Structure
Figure 2-3 2.2 Structure Please refer to the following figure for detailed information. See Figure 2-4. Figure 2-4 Please refer to the following sheet for detailed information. - Page 16 Name X-Y-Z rotation module Device lens Dome camera enclosure Name Function Connect to the DC 12+ power to Power input port input the power. Network data input, output and Network port PoE.
-
Page 17: Installation
3 Installation 3.1 Device Installation This series IPC can be put on the table to realize surveillance. Or you can use the bracket or the in- ceiling installation to realize the hang function. Please refer to the steps listed below. Figure 3-1 Figure 3-2 Step1... -
Page 18: Sd Card Installation
the cable from the side port of the cable channel when you are installing the device cable. And then you can draw out the cable from the cable channel of the pedestal. Step 3 Adjust the device installation pedestal to the proper position and then draw the cable through the cable exit you just dug in the ceiling (wall). - Page 19 Step 1 Please refer to the step 1 in chapter 2.1 to open the device. Step 2 Find the “SD CARD” indicator in the enclosure. Adjust the SD card to the proper direction and then install. See Figure 3-4. Step 3 Please refer to the step 5 in chapter 2.1 to complete the installation.
-
Page 20: Quick Configuration Tool
4 Quick Configuration Tool 4.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 4.2 Operation Double click the “ConfigTools.exe’”... - Page 21 Select the “Open Device Web” item; you can go to the corresponding web login interface. See Figure 4-3. Figure 4-3 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set.
- Page 22 Figure 4-5...
-
Page 23: Web Operation
5 Web Operation This series IPC product support the Web access and management via PC. Web includes several modules includes monitor channel preview, PTZ control, system configuration, alarm and etc. IP camera factory default setup: IP address: 192.168.1.108. User name: admin ... - Page 24 Figure 5-2 If it is your first time to login in, system pops up warning information to ask you whether install control webrec.cab or not after you logged in for one minute. Please click OK button, system can automatically install the control. When system is upgrading, it can overwrite the previous Web too. If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the control download.
- Page 25 Figure 5-4 Please refer to the Web Operation Manual included in the resource CD for detailed operation instruction.
-
Page 26: Faq
6 FAQ I can not boot up Please click RESET button for at least five seconds to restore the device. factory default setup. card write Do not set the SD card as the storage media to storage the times schedule record file. It may damage the SD card duration. I can not use the When disk information is shown as hibernation or capacity is 0, disk as the storage... -
Page 27: Appendix Toxic Or Hazardous Materials Or Elements
Appendix Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Circuit Board ○ ○ ○ ○ ○ ○ Component Device ○ ○ ○ ○ ○ ○ Construction Material ○ ○ ○ ○ ○...
