XVision XPB621 Instruction Manual

True day/night 580/700 tvl ir bullet camera with 50m night vision and auto iris varifocal lens
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XPB621
Model:
True Day/Night 580/700 TVL IR Bullet
Camera with 50m Night Vision & Auto
Iris Varifocal Lens

Before you begin

• Please unpack the box carefully and identify that all the parts are present.
The camera is suitable for indoor or outdoor use. Please bear in mind the following
points when choosing a mounting position.
• The camera must be positioned so that it will not point directly into the sun (sunrise
and sunset) or any bright light, as this may cause damage to the camera.
• Do not cut the camera cables, this will void the warranty.
• Make sure you use only the recommended power supply. Damage caused to the
camera by incorrect voltage or wiring is not covered by the warranty.
Model:
XPB621
True Day/Night 580/700 TVL IR Bullet Camera
with 50m Night Vision & Auto Iris Varifocal Lens

Advertisement

Table of Contents
loading

Related Manuals for XVision XPB621

Summary of Contents for XVision XPB621

  • Page 1: Before You Begin

    XPB621 Model: True Day/Night 580/700 TVL IR Bullet Camera with 50m Night Vision & Auto Iris Varifocal Lens Before you begin • Please unpack the box carefully and identify that all the parts are present. The camera is suitable for indoor or outdoor use. Please bear in mind the following points when choosing a mounting position.

  • Page 2: Safety Precautions

    2. Product Description The XPB621 bullet camera is designed for high risk applications. It offers very high resolution images of 580 TVL in Colour mode and 700 TVL in B/W mode, with a low lux sensitivity of 0.0003 lux.
  • Page 3 700 TVL resolution images in B/W mode and 580 TVL in Colour. z Sony 1/3” Ex View CCD Image Sensor with Xvision XX3 DSP. z 3.5 to 16.0mm Aspherical Auto Iris Varifocal lens for 17° to 85° viewing angle for super sharp images and easy selection of the optimum viewing angle during installation.

  • Page 4: Product Assembly

    5. Product Assembly Unscrew the camera here to access the Camera OSD Controls and the Zoom & Focus Adjustment Rings Figure 1 6. Installation 1. Drill a hole in the wall approximately 20mm in diameter, to feed the cables through. 2.

  • Page 5: Lens Adjustment

    7. Lens Adjustment The XPB621 is fitted with a Varifocal lens. You can make adjustments to both the Zoom and Focal Length by following these easy steps: 1. Carefully unscrew the camera housing and pull the casing away. 2. Connect the Video Output to a monitor or other video device through a 75 Ohms type coaxial cable.

  • Page 6: Camera Osd Control

    8. Camera OSD Control 1. Unscrew the camera housing to access the OSD Menu. (See 5. Product Assembly for details) 2. Push the joystick controller down to access the menu options. OSD Joystick Controller OSD Joystick Controller Actions Press this Control For this Action UP, DOWN Select a new item...
  • Page 7 10. SETUP Menu Functions 1. LENS <Option : DC / MANUAL> This option should be left on DC. 2. EXPOSURE <Option : SHUTTER / BRIGHTNESS / AGC / SENS-UP / BLC / D-WDR / RETURN> • SHUTTER: Adjusts shutter settings <AUTO / FLK / MANUAL> - AUTO - Adjusts shutter settings to control the brightness level on screen.

  • Page 8: White Balance

    10. SETUP Menu Functions continued 3. WHITE BALANCE <Option : ATW / AWB / AWC-SET / MANUAL / INDOOR / OUTDOOR > • ATW: Auto Tracking White Balance. Use this mode when the colour temperature is between 1800k~10,500k • AWB: Automatic White Balance. This feature automatically adjusts the colour temperature of the camera image to match the type of light available, so that white and other colours appear as natural as possible.
  • Page 9 10. SETUP Menu Functions continued 6. SPECIAL MENU 6.1 CAM TITLE <Option : ON / OFF> Use the feature to display a title on the monitor. CAM TITLE 0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z / = &...
  • Page 10 10. SETUP Menu Functions continued 6.4 MOTION <Option : ON / OFF> This function will transmit an alert signal when it detects motion on screen. MOTION AREA SELECT AREA 1 AREA DISPLAY LEFT/RIGHT WIDTH TOP/BOTTOM HEIGHT SENSITIVITY MOTION VIEW RETURN •...
  • Page 11 10. SETUP Menu Functions continued 7. ADJUST <Option : SHARPNESS / BLUE / RED / RETURN > Adjust Sharpness, RED and BLUE levels on the camera image. MOTION SHARPNESS BLUE RETURN 8. RESET Resets all settings to Factory Default. 9. EXIT (SAVE) Select to save OSD Menu settings and EXIT the Setup Menu.

  • Page 12: Specifications

    Dimensions (WxHxD): 73 x 69 x 235mm TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a 3 Year warranty. The Warranty excludes products that have been misused, (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
