Before you begin

• Please unpack the box carefully and identify that all the parts are present.
• Please bear in mind the following points when choosing a mounting position.
> The camera must be positioned so that it will not point directly into the sun (sunrise
and sunset) or any bright light, as this may cause damage to the camera
> Avoid viewing areas where half the area is in bright sunlight and the other half is
dark, such as in the shadow of a building. All types of cameras have difficulty in
'seeing' with such a large lux level variation.
• Do not cut the camera cables, this will void the warranty.
• Make sure you use only the recommended power supply. Damage caused to the
camera by incorrect voltage or wiring is not covered by the warranty.
XPB731WIR-2
Model:
700 TVL 50m IR Camera
with DNR, WDR and 6m NPR
User Manual

Advertisement

Table of Contents
loading

Related Manuals for XVision XPB731WIR-2

Summary of Contents for XVision XPB731WIR-2

  • Page 1: Before You Begin

    • Do not cut the camera cables, this will void the warranty. • Make sure you use only the recommended power supply. Damage caused to the camera by incorrect voltage or wiring is not covered by the warranty. XPB731WIR-2 Model: 700 TVL 50m IR Camera...

  • Page 2: Table Of Contents

    Contents 1. Safety Precautions ............3 2. Product Description ............4 3. Features ................ 4 4. Contents ............... 4 5. Installation ..............5 6. Camera OSD Control ............. 7 7. OSD Menu Structure ............. 7 8. SETUP Menu Functions ..........9 8.1 Exposure ..............

  • Page 3: Safety Precautions

    Thank you for purchasing this Xvision camera. Before operating this product, please read this instruction manual carefully. 1. Safety Precautions z Do not disassemble or modify the camera. Please refer repairs or service to a qualified service technician. z Take care when installing the camera. Avoid scratching the front glass window.

  • Page 4: Product Description

    2. Product Description The XPB731WIR-2 IR camera is designed for high risk applications, offering very high resolution images of 700 TVL. The camera feature high power Infrared (IR) LEDs offering 50m nightvision in complete darkness and split glass technology that elimates any IR bounceback.

  • Page 5: Installation

    5. Installation 1. Select a suitable position on the wall or ceiling to install the camera and map out the holes for the bracket. 2. Drill a hole in the middle of area on the wall or ceiling where the camera is to be mounted, to allow the power and video cable to be fed through.
  • Page 6 5. Installation continued CONNECT THE POWER & VIDEO CABLES 1. Connect the video output to the monitor or other video device through a 75 Ohms type coaxial cable. 2. Connect the power source, insert the AC plug into the AC socket and the DC plug into the DC Jack (+12V DC in jack centre).

  • Page 7: Camera Osd Control

    7. OSD Menu Structure EXPOSURE COLOUR DAY/NIGHT FUNCTION MOTION DETECTION PRIVACY ZONE CAMERA SETTINGS SYSTEM EXIT Please Note: • At the bottom of each menu item there is the option of ‘EXIT’ . Once the user has changed the required settings within the menu option, selecting the ‘EXIT’ option will give the following options: - SAVE: This option will save any changes and will then return to the main menu.

  • Page 8: Exposure

    8. SETUP Menu Functions 8.1. EXPOSURE This option allows the user to alter the camera’s lens settings. The following options are available: • LENS: Users can either select DC or ELC. • HBLC/D-WDR: There are 4 background light functions to choose from - BLC (Backlight Compensation): The BLC function makes objects in front of a bright scene (such as a window on a bright sunny day) clearer to see by increasing their brightness and making the background darker.

  • Page 9: Setup Menu Functions

    8. SETUP Menu Functions continued 8.2. Colour (RGB) Continued • WB MODE (White Balance) - It is used to restore the authenticity of the color, affected by the change of color temperature. Users can select the options: Auto White Balance / Auto-tracking White Balance / Lock White Balance / Manual White Balance respectively.

  • Page 10: Motion Detection

    8. SETUP Menu Functions continued 8.5. Motion Dectection This function alerts the user if motion has been detected within a defined area: • MOTION: Select to choose to activate the motion dectection (ON or OFF) • AREAS SEL: Users can select upto 4 individual motion detection areas. •...

  • Page 11: Camera Settings

    8. SETUP Menu Functions continued 8.7. CAMERA SETTINGS This function allows the user to add on-screen viewing options: • TITLE DISP: Allows the user to set a custom title to be displayed on the screen. • MANUAL DPC (Dead Pixel Compensation): Manual process dead pixels on the screen.

  • Page 12: Specifications

    101.3 x 97.3 x 298.2 mm Weight: 1.1 Kg TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a 1 Year warranty. The Warranty excludes: Products that have been misused, (including accidental damage) and damage caused by normal wear and tear.
