The PNP/PCI configuration program is for the user to modify the PCI/ISA IRQ
signals when various PCI/ISA cards are inserted in the PCI or ISA slots.
WARNING: Conflicting IRQ's may cause the system to not find certain
devices.
PNP OS Installed
Resources Controlled By
Reset Configuration Data
IRQ-3 Assigned to
IRQ-4 Assigned to
IRQ-5 Assigned to
IRQ-7 Assigned to
IRQ-9 Assigned to
IRQ-10 Assigned to
IRQ-11 Assigned to
IRQ-12 Assigned to
IRQ-14 Assigned to
IRQ-15 Assigned to
DMA-0 Assigned to
DMA-1 Assigned to
DMA-3 Assigned to
DMA-5 Assigned to
DMA-6 Assigned to
DMA-7 Assigned to
PNP OS Installed:
Do you have a PNP OS installed on your system. The default is No.
Yes: Select if you are using a PNP OS
No: Select if your OS does not support PNP.
Resources Controlled By:
Who controlled the system PNP/PCI resources.
The default is Manual.
Manual: PNP Card's resources will be controlled manually. You can set
which IRQ-X and DMA-X are assigned to PCI/ISA PNP or Legacy
ISA Cards.
Auto: If your ISA card and PCI card are all PNP cards, BIOS will assign
the interrupt resource automatically.
ROM PCI/ISA BIOS(2A6LGPAA)
PNP/PCI CONFIGURATION
AWARD SOFTWARE, INC.
: No
: Manual
: Disabled
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
Figure 6: PCI Configuration Setup
CPU to PCI Write Buffer
PCI Dynamic Bursting
PCI Master 0 WS Write
PCI Delay Transaction
PCI#2 Access #1 Retry
AGP Master 1 WS Write
AGP Master 1 WS Read
Solt 1 Use IRQ No.
Solt 2 Use IRQ No.
Solt 3 Use IRQ No.
Solt 4 Use IRQ No.
Solt 5 Use IRQ No.
Esc : Quit
F1 : Help
F5 : Old Values
F7 : Load Setup Defaults
BIOS
: Enabled
: Enabled
: Enabled
: Disabled
: Disabled
: Enabled
: Disabled
: Auto
: Auto
: Auto
: Auto
: Auto
: Select Item
PU/PD/+/- : Modify
(Shift) F2 : Color
Page 4-15
