BIOS
The menu displays all the major selection items. Select the item you need to
reconfigure. The selection is made by moving the cursor (press any direction key )
to the item and pressing the 'Enter' key. An on-line help message is displayed at
the bottom of the screen as the cursor is moved to various items which provides a
better understanding of each function. When a selection is made, the menu of the
selected item will appear so that the user can modify associated configuration
parameters.
Choose "Standard CMOS Setup" in the CMOS SETUP UTILITY Menu (Figure
2). The Standard CMOS Setup allows the user to configure system settings such
as the current date and time, type of hard disk drive installed, floppy drive type,
and display type. Memory size is auto-detected by the BIOS and displayed for
your reference. When a field is highlighted (use direction keys to move the cursor
and the <Enter> key to select), the entries in the field can be changed by pressing
the <PgDn> or the <PgUp> key.
Date (mm:dd:yy) : Wed, Apr 17 1996
Time (hh:mm:ss) : 14 : 30 : 50
HARD DISKS TYPE
Primary Master : Auto
Primary Slave : Auto
Secondary Master : Auto
Secondary Slave : Auto
Drive A : 1.44M, 3.5 in.
Drive B : None
Video : EGA/VGA
Halt On : All, But Keyboard
ESC : Quit
F1 : Help
Note: If the hard disk Primary Master/Slave and Secondary Master/
Slave are set to Auto, then the hard disk size and model will be
auto-detected.
Page 4-2
ROM PCI/ISA BIOS(2A6LGPAA)
STANDARD CMOS SETUP
AWARD SOFTWARE, INC.
SIZE CYLS HEAD
0 0 0
0 0 0
0 0 0
0 0 0
: Select Item
(Shift) F2 : Change Color
Figure 2: Standard CMOS Setup
PRECOMP LANDZONE
0 0
0 0
0 0
0 0
Base Memory :
Extended Memory :
Other Memory :
Total Memory :
PU/PD/+/- : Modify
EP-3VBA
SECTORS MODE
0 Auto
0 Auto
0 Auto
0 Auto
640K
392192K
384K
393216K
