EP-3VBA
Note: The "Halt On:" field is used to determine when to halt the system
by the BIOS if an error occurs.
Note: Floppy 3 Mode support is a mode used to support a special 3.5"
drive used in Japan. This is a 3.5" disk that stores only 1.2 MB,
the default setting for this is disabled.
Selecting the "BIOS FEATURES SETUP" option in the CMOS SETUP UTIL-
ITY menu allows users to change system related parameters in the displayed
menu. This menu shows all of the manufacturer's default values for the EP-
3VBA.
Pressing the [F1] key will display a help message for the selected item.
Virus Warning
CPU Internal Cache
External Cache
CPU L2 Cache ECC Checking
Quick Power On Self Test
Boot Sequence
Swap Floppy Drive
Boot Up Floppy Seek
Boot Up NumLock Status
IDE HDD Block Mode
Gate A20 option
Memory Parity/ECC Check
Typematic Rate Setting
Typematic Rate (Chars/Sec)
Type matic Delay (Msec)
Security Option
PCI/VGA Palette Snoop
OS Select For DRAM > 64MB
Virus Warning:
During and after the system boots up, any attempt to write to the boot sector
or partition table of the hard disk drive will halt the system and an error
message will appear.
You should then run an anti-virus program to locate the virus. Keep in mind
that this feature protects only the boot sector, not the entire hard drive.
The default value is Disabled.
ROM PCI/ISA BIOS(2A6LGPAA)
BIOS FEATURES SETUP
AWARD SOFTWARE, INC.
: Disabled
Video BIOS Shadow
: Enabled
C8000-CBFFF Shadow
: Enabled
CC000-CFFFF Shadow
: Disabled D0000-D3FFF Shadow
D4000-D7FFF Shadow
: Enabled D8000-DBFFF Shadow
: A, C, SCSI DC000-DFFFF Shadow
: Disabled
: Enabled
: On
: Enabled
: Fast
: Disabled
: Disabled
: 6
Esc : Quit
: 250
F1 : Help
: Setup
F5 : Old Values
: Disabled
F7 : Load Setup Defaults
: Non-OS2
Figure 3: BIOS Features Setup
BIOS
: Enabled
: Disabled
: Disabled
: Disabled
: Disabled
: Disabled
: Disabled
: Select Item
PU/PD/+/- : Modify
(Shift) F2 : Color
Page 4-3
