EPOX EP-3VBA User Manual page 35

EP-3VBA
MODEM Use IRQ:
Name the interrupt request (IRQ) line assigned to the modem (if any) on your
system. Activity of the selected IRQ always awakens the system.
Default is IRQ 3.
N/A: No IRQ is used.
4: IRQ 4
7: IRQ 7
10: IRQ 10
The EP-3VBA supports HDD Power Down, Doze and Standby power saving
functions when using the Intel Pentium II Processor.
The default is Disabled
Soft-Off by PWR-BTTN:
Use this to select your soft-off function.
The default is Delay 4 sec.
Instant Off: Turns off instantly.
Delay 4 Second : Turns off after a 4 second delay. If momentary press of
PWRON After PW-Fail:
The system will stay of or power on after a power interrupte.
The default is Fomer-Status.
Fomer-Status: Stay off or power on depend on system safe shut-down or
power fail.
ON: System always power on after a power interrupte.
OFF: System always stay off after a power interrupte.
HDD Power Down:
HDD Standby timer can be set from 1 to 15 minute(s).
Doze Mode:
The "Doze" mode timer starts to count when no "PM events" have occurred.
Suspend Mode:
This function works only when the Pentium II Processor is installed. The
timer starts to count when "System Standby" mode timer is timed out and no
"PM Events" are occurring. Valid range is from 1 minute up to 1 hour.
3: IRQ 3
5: IRQ 5
9: IRQ 9
11: IRQ 11
button, the system will go into Suspend Mode. Press again
to take system out of Suspend Mode.
BIOS
Page 4-13
