Installation
Device Connectors
J2
1 Power LED connector
1
Speaker - Connect to the system's speaker for beeping
Reset - Closed to restart system.
IR Connector
1
J3
IDE LED indicator - LED ON when Onboard PCI IDE Hard
+
disks is activate
Turbo LED indicator - LED ON when higher speed is selected
+
Power On/Off - This is connected to the power button on the case.
Using the Soft-Off by Pwr-BTTN feature, you can choose either
Instant Off (turns system off immediatly), or 4 sec delay (you need
to hold the button down for 4 seconds before the system turns off).
When the system is in 4 sec delay mode, we has added a special
feature to make the system go into suspend mode when the button
is pressed momentarily.
Page 3-8
(continued)
1. Power LED(+)
2. N/C
3. GND
1. Speaker
2. N/C
1. VCC
2. NC
3. IRRX
4. NC
5. GND
3. GND
4. GND
4. GND
5. IRTX
EP-3VBA
