Configuration

To configure the USB Serial port:
1. In the Device Manager, double-click on "Ports (COM & LPT)" to expand.
2. Right-click on the newly added serial port and select "Properties".
3. From within the Properties window, the "Setting" tabs offer configuration
options for the USB Serial Adapter functions:

Pinout

Pin Signal
1
2
3
4
5
6
7
8
9
Instruction Manual
DCD
TxD
RxD
DTR
GND
DSR
RTS
CTS
RI
