Bike HW3015 OWNER’S MANUAL CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment, should not be undertaken without first consulting a physician. No specific health claims are made or implied as they relate to the equipment.
ATTACHMENT - A IMPORTANT SAFETY ADVICE PRECAUTIONS This bike has been designed and constructed to provide maximum safety. Nevertheless, certain precautions should be taken when using exercise equipment. Read the whole manual before assembling and using the bike. The following safety precautions should also be observed: 1.
Page 4
IMPORTANT SAFETY ADVICE 15. Pedals can cause injury. 16. Before using the bike, thoroughly inspect the bike for proper assembly. 17. A parameter distance of 3 feet / 1meter is required before operating the unit. 18. User must adjust the seat and handlebars to the user’s height requirements. Please be sure the adjustment knob is locked tight and seat and handlebars are secure.
HARDWARE PACKAGE / TOOLS Note: Use the tools only for this exercise bike. 1 PC 1 PC PRE-ASSEMBLY INSTRUCTIONS GENERAL INSTRUCTIONS Carefully read through the instructions contained in this manual. It provides you with important information about assembly, safety and use of the machine. 1.
ASSEMBLY INSTRUCTIONS STEP 1 SECURE FRONT STABILIZER (2) TO MAIN FRAME (1) AND ATTACH IT WITH CARRIAGE BOLTS (43), WASHERS (44), AND DOME NUTS (45). STEP 2 SECURE REAR STABILIZER (3) TO MAIN FRAME (1) AND ATTACH IT WITH CARRIAGE BOLTS (43), WASHERS (44), AND DOME NUTS (45).
Page 8
ASSEMBLY INSTRUCTIONS STEP 3. SLIDE THE HANDLEBAR POST (6) INTO THE MAIN FRAME (1) AND TIGHTEN THE PLASTIC ADJUSTABLE KNOB (54) TO SECURE. STEP 4 ATTACH THE HANDLE BAR (7) TO THE MAIN FRAME (1) AND ATTACH IT WITH BOLTS (57), WASHERS (29).
Page 9
ASSEMBLY INSTRUCTIONS STEP 5. SLIDE THE SEAT POST (4) INTO THE MAIN FRAME (1) AND ATTACH IT WITH THE PLASTIC ADJUSTABLE KNOB (54). STEP 6 SECURELY ATTACH THE SEAT (36) TO THE SEAT BAR (5). SLIDE THE SEAT BAR (5) INTO THE SEAT POST (4) AND TIGHTEN THE PLASTIC ADJUSTABLE KNOB (54) TO SECURE...
Page 10
ASSEMBLY INSTRUCTIONS STEP 7. Failure to follow the directions can result in damage to either the crank or the pedal threads. The right-hand pedal, marked with the letter (R),screws onto the right-hand crank, also marked with an (R), in a clockwise direction till tight. The left-hand pedal, marked with the letter (L),screws onto the left-hand crank, also marked with an (L), in a counter clockwise direction till tight.
Operation of Your Bike Getting familiar with the control panel SPECIFICATIONS: TIME………………………………………………………………………………………..……………00:00-99:59MIN SPEED………………...…….…………………………………………………………………..0.0-99.99KM/H or ML/H DISTANCE………………………………………………………………………………...………..0-9.999KM or ML CALORIES…………………………………………………………………………………………….…0-99.99KCAL ODOMETER (IF HAVE) ……………………………………………………………...…………..0 -9.999KM or ML PULSE (IF HAVE)…………….…..……………………………………………………………………….…40-240BPM KEY FUNCTIONS: MODE/SELECT: To select the function you want. Hold the key for 4 seconds to have all function values reset (total reset) SET (if have): To input the target value by the key.
MAINTENANCE INSTRUCTIONS CLEANING Care has been taken to assure that your bike has been properly adjusted and lubricated at the factory. It is not recommended that the user attempt service on the internal components instead seek service from an authorized service center. However, from time-to-time the outer surfaces may appear dull or dirty, following the instructions listed below will restore and preserve the original finish.
TROUBLE SHOOTING RESISTANCE ADJUSTMENT: PEDALLING RESISTANCE IS CONTROLLED BY THE TENSION KNOB. PROPERLY ADJUSTING THE SEAT WILL HELP REDUCING THE RISK OF INJURY AND ENSURE MAXIMUM EXERCISE EFFICIENCY AND COMFORT. (THE MOST APPROPRIATE POSITION WHILE USING THIS BIKE IS WITH ONE PEDAL IN THE DOWNWARD POSITION, WHILE THE OTHER LEG IS SLIGHTLY BENT AT THE KNEE.) TO ADJUST THE SEAT HEIGHT SIMPLY TURN THE ADJUSTABLE KNOB LOOSE, THEN PULL THE KNOB TO MOVE THE SEAT UP OR DOWN TO THE DESIRE HEIGHT (THERE ARE DIFFERENT SEAT HEIGHT POSITIONS FOR ADJUSTMENT).
Spin Bike HW3015 PARTS LIST PART NO. PART NO. DESCRIPTION SIZE DESCRIPTION SIZE MAIN FRAME BB PARTS FRONT CRANK STABILIZER PEDALS REAR STABILIZER ADJUSTABLE FOOT SEATPOST ADJUSTABLE NUT SEATBAR CARRIAGE BOLT M8X40 FRONT POST WASHER Φ8 HANDLEBAR M12X1 CHAIN ADJUSTABLE...
