BLADEZ U300 Owner's Manual

Bladez fitness equipment
Hide thumbs Also See for U300:

Advertisement

Table of Contents

U300
OWNER'S MANUAL
Important: Read all instructions carefully before using this product. Retain this owner's manual for future reference.
FOR SERVICE PLEASE CONTACT BLADEZ FITNESS
TOLL FREE: 866-325-2339
Bladez Fitness | 20155 Ellipse, Foothill Ranch, California 92610 | p.949.206.0330 | f.949.206.0013 | www.BladezFitness.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BLADEZ U300

Summary of Contents for BLADEZ U300

  • Page 1 Important: Read all instructions carefully before using this product. Retain this owner’s manual for future reference. FOR SERVICE PLEASE CONTACT BLADEZ FITNESS TOLL FREE: 866-325-2339 Bladez Fitness | 20155 Ellipse, Foothill Ranch, California 92610 | p.949.206.0330 | f.949.206.0013 | www.BladezFitness.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Title Page Introduction Safety Information Exercise Instruction Training Guidelines Suggested Stretches Assembly Instructions Exploded View Drawing Parts List Console Operations Maintenance and Cleaning Warranty...

  • Page 3: Introduction

    CONGRATULATIONS Congratulations on your purchase of Bladez Fitness equipment. We hope you appreciate the style, quality, and value that exercisers around the world have come to expect from Bladez Fitness. If you have any questions, concerns or product issues please call our Customer Service Team at 1-866-325-2339 or email us at CustomerSupport@BHNorthAmerica.com.

  • Page 4: Safety Information

    6. This machine must only be used for the purposes described in this manual. DO NOT use accessories that are not recommended by Bladez Fitness. Read manual prior to use and follow all warnings and instructions. 7. Do not place sharp objects near the machine.

  • Page 5: Exercise Instruction

    EXERCISE INSTRUCTION Use of the machine offers various benefits; it can improve fitness, muscle tone and when used in conjunction with a calorie controlled diet, it can help you lose weight. 1. Consult your doctor before starting any exercise program. It is advisable to undergo a complete physical examination.

  • Page 6: Training Guidelines

    TRAINING GUIDELINES Exercise is one of the most important factors in the overall health of an individual. Listed among its benefits are: • Increased capacity for physical work (strength endurance) • Increased cardiovascular (heart and arteries/veins) and respiratory efficiency • Decreased risk of coronary heart disease •...
  • Page 7 OXYGEN UPTAKE The effort that you can exert over a prolonged period of time is limited by your ability to deliver oxygen to the working muscles. Regular vigorous exercise produces a training effect that can increase your aerobic capacity by as much as 20 to 30%. An increased VO2 Max indicates an increased ability of the heart to pump blood, of the lungs to ventilate oxygen, and of the muscles to take up oxygen.
  • Page 8 HEART RATE As you exercise, your heart beat increases. This is often used as a measure of the required intensity of an exercise. You need to exercise hard enough to condition your circulatory system, and increase your pulse rate, but not enough to strain your heart. Your initial level of fitness is important when developing an exercise program for you.
  • Page 9 MUSCLE SORENESS For the first week or so, muscle soreness may be the only indication you have that you are on an exercise program. This, of course, does depend on your overall fitness level. A confirmation that you are on the correct program is a very slight soreness in most major muscle groups. This is quite normal and will disappear in a matter of days.

  • Page 10: Suggested Stretches

    SUGGESTED STRETCHES Head Rolls Rotate your head to the right for one count while feeling the stretch up the left side of your neck. Next, rotate your head back for one count, stretching your chin to the ceiling. Rotate your head to the left for one count, and finally, drop your head to your chest for one count.
  • Page 11 SUGGESTED STRETCHES Inner Thigh Stretch Sit with the soles of your feet together with your knees pointing outward. Pull your feet as close into your groin as possible. Gently push your knees towards the floor. Hold for 15 counts. Toe Touches Slowly bend forward from your waist, letting your back and shoulders relax as you stretch toward your toes.

  • Page 12: Assembly Instructions

    ASSEMBLY INSTRUCTIONS & WARNING LABELS...
  • Page 13 STEP 1 Lock the Front Stabilizer (31) and Rear Stabilizer (32) to the Main Frame (29) by using the wrench (87), Hex Bolt (30) and Washer (26).
  • Page 14 STEP 2 Assemble the Pedal (37L/R) to the Main Frame (29) with Spanner (88) on each side of crank.
  • Page 15 STEP 3 Connect the Computer Link Wire 1 (18b) to the Computer Link Wire 2 (27), and insert the Handlebar Post (24) into the Main Frame (29). Then secure the Handlebar Post (24) and Main Frame (29) with Wrench S6 (87), Hex Screw (25) and Washer (26).
  • Page 16 STEP 4 Connect the Computer Wire (1a) to the Computer Link Wire (18a), then attach the Computer (1) on the Handlebar Post (24) with Spanner (88) and Screw (20).
  • Page 17 STEP 5 Fasten the Handlebar (3)to the Handlebar Post (24). Then, using the Bolt (23), place through the spacer (22) and Clamp (21), then lock the Handlebar (3) into Handlebar Post (24). At last, insert the Pulse Wire (6) into the hole at the back of the Computer.
  • Page 18 STEP 6 Slide the Saddle Post (15) into the Main Frame (29), and then lock it with Adjusting Knob (28). Fasten the Saddle Post Joint (11) to the Saddle Post (15) with the Bolt (14), and the Washer (13). Attach the Saddle (10) to the Saddle Post Joint (11).

  • Page 19: Exploded View Drawing

    EXPLODED VIEW DRAWING...
  • Page 20 EXPLODED VIEW DRAWING...

  • Page 21: Parts List

    PARTS LIST To order replacement parts: provide your customer service representative with the product model number and the part number located on the Parts List below, along with the quantity you require. Description Description U300-1 Computer Washer U300-1a Computer wire...

  • Page 22: Console Operations

    CONSOLE OPERATIONS THE THINGS YOU SHOULD KNOW BEFORE EXERCISE: A. Input Power Plug in the adaptor to the bike and then the computer will produce a beep sound. The computer will start at the Manual mode. B. Program select and setting value 1.
  • Page 23 5. CALORIES: The computer will estimate the cumulative calories burned at any given time during your workout. 6. PULSE: The computer displays your pulse rate in beats per minute during your workout. 7. AGE: The computer is age-programmable from 10 to 99 years. If you do not set an age, this function will always default to age 35.
  • Page 24 3. DOWN key: • Press the key to decrease the resistance during exercise mode. • During the setting mode, press the key to decrease the value of Time, Distance, Calories, Age and select Gender and Program. 4. ENTER key: • During the setting mode, press this key to accept the current data entry. •...
  • Page 25 2. Press the ENTER key to enter your workout program. 3. The TIME will flash and you can press UP or DOWN keys to set your exercise TIME. Press ENTER key to confirm your desired TIME. 4. The DISTANCE will flash and you can press UP or DOWN keys to set your target DISTANCE.
  • Page 26 Program 18 is the 55% Max H.R.C. - - Target H.R. = (220 – AGE) x 55% Program 19 is the 65% Max H.R.C. - - Target H.R. = (220 – AGE) x 65% Program 20 is the 75% Max H.R.C. - - Target H.R. = (220 – AGE) x 75% Program 21 is the 85% Max H.R.C.
  • Page 27 (5feet 7 inches). 4. The WEIGHT will flash and you can press UP or DOWN keys to set your WEIGHT. Press ENTER key to confirm your WEIGHT. The default WEIGHT is 70kgs or 155lbs. 5. The GENDER will flash and you can press UP or DOWN keys to select your sex. Number 1 equals male and "zero"...
  • Page 28 E3 (ERROR 3): Faulty Motor Technical data of the current adapter: Available for Input: 110V/50Hz or 60Hz Output: 6V DC/0.5~1A LCD WORKOUT GRAPHICS: Program 1 Manual Program 2 Steps Program 3 Hill Program 4 Rolling Program 5 Valley Program 6 Fat Burn Program 7 Ramp Program 8 Mountain Program 9 Intervals...
  • Page 29 USER SETTING PROGRAM: Program 14 User 1   Program 15 User 2   Program 16 User 3   Program 17 User 4   HEART RATE PROGRAM PROFILES: Program 18 55% H.R.C.   Program 19 65% H.R.C   Program 20 75% H.R.C.  ...
  • Page 30 Program 21 85% H.R.C.   Program 22 85% Target H.R.C.   BODY FAT TEST PROGRAMS: Program 23 BODY FAT (STOP MODE) BODY FAT (START MODE)   One of the Following Six Profiles Will Display Automatically after Measuring Your BODY FAT: Workout Time: 40 minutes Workout Time: 40 minutes Workout Time: 20 minutes...

  • Page 31: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Care has been taken to assure that your equipment has been properly adjusted and lubricated at the factory. It is not recommended that the user attempt service on the internal components. Instead, seek service from an authorized service center. However, you may clean the outer surface.

  • Page 32: Warranty

    Owner’s Manual. Register your product warranty easily online at: www.BladezFitness.com FOR WARRANTY REPAIRS, PLEASE DO NOT TAKE YOUR MACHINE BACK TO THE RETAIL STORE. CONTACT BLADEZ FITNESS FIRST. Bladez/BH North America Corporation 20155 Ellipse Foothill Ranch, CA 92610 Phone: 949.206.0330;...

This manual is also suitable for:

R300
