Maintaining Your Printer

Replacing the printhead

44
Replacing the printhead is not a regular maintenance procedure. Replace
IMPORTANT:
the printhead only if you receive a new printhead from Kodak.
To replace the printhead:
1. Make sure your printer is on.
2. Lift the printer access door, and wait for the carriage to move to the access
position.
3. Remove both ink cartridges and set them aside.
4. Unlatch the used printhead by lifting the button in the center of the carriage.
www.kodak.com/go/aiosupport
