Kodak ESP 5200 Extended User Manual page 12

Connecting to a WPS wireless router
If your router supports Wi-Fi Protected Setup (WPS), you can use WPS Connect.
WPS lets you configure your printer for a wireless network by pressing buttons or
entering a PIN.
To connect to a network using WPS:
1. Press Home.
2. Press to select Network Settings, then press OK.
3. With WiFi Setup Wizard selected, press OK.
NOTE: The Wi-Fi radio turns on automatically when you select Wi-Fi Setup
Wizard.
4. With WPS Connect selected, press OK.
5. Select one of two methods of connecting:
Before you press OK on the printer, make sure you know where the
IMPORTANT:
router's push button is, or where to enter the generated PIN. If
necessary, consult your Internet service provider or router device
manufacturer's documentation for more information.
Pressing a button
NOTE: You will have two minutes to
press or select the WPS
button. It may be a button on
the device or a virtual button
in the device's software.
a. With Push Button Configuration
selected, press OK.
b. Press or select the WPS button for
your wireless router.
6. When the confirmation message appears, press OK.
If the printer is successfully connected, the Wi-Fi LED stops blinking and
remains lit.
7. If you haven't yet installed the KODAK All-in-One Printer Software, go to
www.kodak.com/go/esp5250downloads
www.kodak.com/go/esp5210downloads, and follow the on-screen instructions
to install the software.
The printer with a wireless connection is listed as the name of the printer plus a
number (for example, KodakESP5200+1133).
www.kodak.com/go/aiosupport
KODAK ESP 5200 Series All-in-One Printer
Entering a PIN
a. Press to select Generate
WPS PIN, then press OK.
b. In your wireless router's
software, locate the PIN screen.
c. Enter the PIN you received on
the LCD into the PIN screen.
or
7
