- Page 1 KOBE Brand Range Hood Model No. CX1836GS-8 CX-183 SERIES – 4” HEIGHT “GLASS CANOPY WITH LED SCREEN” INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
-
Page 2: Table Of Contents
- READ AND SAVE THESE INSTRUCTIONS - CONTENTS Important Safety Instructions………………………………………………………………. Components of Package…………………………………………………………………… Installation…………………………………………………………………………………… Operating Instructions…………………………………………………………………….. Maintenance…………………………………………………………………………………. Specifications………………………………………………….……..……………………… Measurements & Diagrams…………………………………………………………...…… Parts List…………………………………………………………………..…………………. Circuit Diagram………………………………………………………………...……………. Disclaimer……………………………………………………………………………………. Warranty…………………………………………………………………...………………… Product Registration………………………………………………………...……………… - READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING - A L L W IR IN G M U S T B E D O N E B Y A P R O F E S S IO N A L A N D IN A C C O R D A N C E W IT H N AT IO N A L A N D L O C A L E LE C T R IC A L C O D E S . -
Page 3: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 4 What to Do In The Event Of a Range Top Grease Fire SMOTHER FLAMES with a close fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 5: Components Of Package
COMPONENTS OF PACKAGE (M u s t k e e p a ll m a te ria l fo r re tu rn s o r re fu n d s ) Range Hood Box {A} KOBE Range Hood with Two-Piece Duct Cover {B} Warranty Registration Card {C} Instructions Manual {D} Duct Cover-Mounting Bracket... -
Page 6: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate the length of the installation, please refer to Table 1. (All calculation is measure in inches.) TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood Bottom (Recommended... - Page 7 Peel protective film off the duct cover and the hood (if any). Place rubber seal on hood venting area as shown in Figure 3. Use eight (4x20 mm) screws (provided) to attach plastic damper and rubber seal to hood venting area. Refer to Figure 4.
- Page 8 Align hood to the hood-mounting bracket on the wall and hook hood into place as shown in Figure 6 & 7. CAUTION: MAKE SURE THE HOOD IS SECURE BEFORE RELEASING. For safety purposes, install the safety bracket (provided) with one screw (not provided) to the wall as shown in Figure 8.
- Page 9 12. Test the operation of the hood before moving on to the next step. Make sure power is supplied to the hood. Duct Cover Installation 13. Using references in Table 1 and measurements on page 13, mark the leveling point for duct cover-mounting bracket.
-
Page 10: Operating Instructions
OPERATING INSTRUCTION This KOBE hood is equipped with five electronic controls with LED screen, one powerful centrifugal squirrel cage with stainless steel filter, two bright 12-volt 20-watt halogen lights, and one oil container. The five control buttons are Power Control (On/Off), Auto Control, Speed Control (Low & High Speed), Light Control and Timer Control. - Page 11 Speed Control Press once for High speed to start. Output Display: Press twice for Low speed to start. Output Display: Light Control Press Light Control to turn on the two halogen lights. Timer Control Press Timer Control to start timer. When Timer Control is pressed, fan will automatically shut off after set time.
-
Page 12: Maintenance
MAINTENANCE CAUTION: NEVER PUT YOUR HAND INTO THE AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. For the optimal level of operation, clean the range hood surface, stainless steel filter, and oil container regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. Regular care will help preserve its fine appearance. - Page 13 To Replace Light Bulb CAUTION: HALOGEN LIGHT UNIT MAY BE HOT! WAIT UNTIL UNIT IS COOL. 1) Make sure all control switches are off, and range hood is unplugged. 2) Use a flat head screwdriver to pop out the protective covering as shown in Figure 13. 3) Gently pull out the defective light bulb and discard.
-
Page 14: Specifications
SPECIFICATIONS MODEL / SIZE COLOR VOLTAGE / CONSUMPTION NUMBER OF MOTORS DESIGN FAN TYPE EXHAUST CONTROLS HALOGEN LIGHTS HOOD DIMENSION (W x D x H) DUCT COVER DIMENSION (W x D x H) OPTIONAL ACCESSORIES (W x D x H) WEIGHT (lbs) SPEED Air Capacity (cfm)*... -
Page 15: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS ***All inch measurements are converted from millimeters. Inch measurements are estimated. ***All measurements in ( ) are millimeters. VIEWING DOWN FROM THE TOP ***VIEW FROM THE SIDE... -
Page 16: Parts List
PARTS LIST MODEL NO.: CX1836GS-8 DESCRIPTION Oil Container (Round) Stainless Steel Filter Screw Stainless Steel Filter Halogen Light Support Halogen Light (12V 20W Max.) Bottom Casing Control Box Control Box Screw Hood Casing Hood-Mounting Bracket Plastic Damper Transformer Electrical Wire Box Processor Board Capacitor Rubber Seal... - Page 17 MODEL NO.: CX1836GS-8...
-
Page 18: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: CX1836GS-8... -
Page 19: Disclaimer
DISCLAIMER 1. CAREFULLY INSPECT ALL ITEMS FOR DAMAGES BEFORE ACCEPTING DELIVERY. NOTE ANY DAMAGES ON THE FREIGHT BILL OR EXPRESS RECEIPT. REQUEST NAME AND SIGNATURE OF THE CARRIER’S AGENT AND KEEP COPY TO SUPPORT YOUR CLAIM. Upon acceptance of items, owner assumes responsibility for its safe arrival. Damages should be reported to carrier and a claim filed. -
Page 20: Warranty Certificate
WARRANTY KOBE Range Hoods, Inc. warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component part, which its examination shall disclose to be so defective. -
Page 21: Consequential Damage
Some states do not allow limitations on the duration of implied warranties. This warranty gives you specific legal rights, and may also have rights, which vary from state to state. For service contact: KOBE Range Hoods 4934 Walnut Grove Avenue Suite 202 San Gabriel, CA 91776 U.S.A... -
Page 22: Product Registration
KOBE Range Hoods Agent or KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection.
