KOBE Brand Range Hood
CH-178 Model

INSTALLATION INSTRUCTIONS

AND OPERATION MANUAL
- READ AND SAVE THESE INSTRUCTIONS -
- READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING -
ALL WIRING MUST BE DONE BY A PROFESSIONAL AND IN
ACCORDANCE WITH NATIONAL AND LOCAL ELECTRICAL CODES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CH-178 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KOBE CH-178

Summary of Contents for KOBE CH-178

  • Page 1: Installation Instructions

    KOBE Brand Range Hood CH-178 Model INSTALLATION INSTRUCTIONS AND OPERATION MANUAL - READ AND SAVE THESE INSTRUCTIONS - - READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING - ALL WIRING MUST BE DONE BY A PROFESSIONAL AND IN ACCORDANCE WITH NATIONAL AND LOCAL ELECTRICAL CODES.
  • Page 2 Any repair carried out without the supervision of KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries, whether caused directly or indirectly by the range hood.

  • Page 3: Important Safety Instructions

    -IMPORTANT SAFETY INSTRUCTIONS- W ARNING – TO REDUCE THE RISK OF PERSONAL INJURY IN THE EVENT OF A RANGE TOP GREASE FIRE: Keep fan, optional filter and grease-laden surfaces clean.  Always turn hood ON when cooking at high heat. ...

  • Page 4: Preparing The Installa Tion Loca Tion

    2) Plastic packet of small parts containing: a) Two safety screen b) Two rectangle & 2 round oil cups c) Halogen Lights 12V20W(CH-178 Models only) d) Plastic exhaust duct outlet ring for 6" or 7" Opening e) Installation Manual & Warranty Card 3) Patented installation template guide (screw position &...

  • Page 5: Installing The Range Hood

    ----SAFETY WARNING---- IF DRILLING INTO THE WALLS, BE CAREFUL NOT TO CUT EXISTING ELECTRICAL CABLES, WHICH WOULD CREATE A HAZARD. ALL ELECTRICAL CONNECTIONS MUST BE IN ACCORDANCE WITH LOCAL CODES, ORDINANCES, NATIONAL ELECTRICAL CODE. IF YOU ARE UNFAMILIAR WITH METHODS OF INSTALLING ELECTRICAL WIRING, SECURE THE SERVICES OF A QUALIFIED ELECTRICIAN.
  • Page 6 For top venting: (CH-178 Series) cut along the dotted line of the template leaving a rectangle opening on the bottom of the cabinet. Tear out & dispose of the template. This rectangle opening is required for 6”, 7”...
  • Page 7 For Mounting on a Cabinet with a Recessed Bottom 1) If you need to move the cooking range to work on the cabinet, turn off the power for an electric range at the main electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS RANGE.
  • Page 8 Roof Cap Transition Elbow Cabinet 6”RD, 7”RD 3 ¼” x 10” Duct Elbow Transition Second floor Roof Cap Ceiling Wall Cabinet 6”RD, 7”RD 3 ¼” x 10” Duct Vertical Ducting on second floor house...
  • Page 9 Stop when the bottom of the connector reaches conductor. Follow all codes. 4) Plug into electrical outlet. Turn on power and check operation of fans and light. Congratulations, your KOBE range hood is ready to be used! NOTE: The recommended height from range hood...
  • Page 10 KOBE range hood motors can be operated independently of one another. This KOBE range hood model is operated by two 2-speed switches located on the front of the hood. Each switch controls a separate motor with high and low settings. (Fig. 4) The low setting will handle most exhaust requirements while the high speed should be used for heavier cooking.
  • Page 11 Cleaning To clean the hood surface, use only mild soap or detergent solutions. Dry up surfaces using soft cloth. CAUTION: Never use abrasive cleaners, pads, or cloths. If the hood looks splotchy (stainless steel hood), use an orange base cleaner to clean the surface of the hood (make sure the cleaner does not get on any control switches).
  • Page 12 Changing the Light Bulb CH-178 Series: 1) Make sure all control switches are off and range hood is unplugged. CAUTION: Wait until halogen light is cool to the touch before changing. 2) Remove the metal support from the bottom of the halogen light. The halogen light should drop out of the light cavity.
  • Page 13 Changing the Fuse CH-178 Series: 1) Undo the three screws at the bottom of the range hood. CAUTION: To avoid electric shock, unplug range hood FIRST. Take off the bottom panel of the hood and place on a flat surface.

  • Page 14: Troubleshooting Guide

    Troubleshooting Guide Problem Solution Light does not turn on. Check power is plugged in.  Check light bulb.  Check fuse.  One fan is turning faster than the other. Clean fans.  Check for loose wires.  Fan is not turning. Check power is plugged in.
  • Page 15 - Circuit Diagram - Model CH -178 (30’’, 36”, 42”)
  • Page 16 -Parts List- Model CH -178 (30’’ 36’’ 42’’) Casing Wind Box Fuse Exhaust Wind Tunnel Separate Stand Fuse Housing Oil Tunnel Piece Quiet Mode Switch Line Circle Light Switch Motor Stand Right Control Motor Switch Motor Stand Worn Pin Left Control Motor Switch Motor Input Wire Motor Vibration Seal...
  • Page 17 Model CH -178 (30’’ 36’’ 42’’)
  • Page 18 -Parts List- Model CH -178(48”) Casing Motor Stand Worn Pin Fuse Motor Position Screw Fuse Housing Motor Vibration Seal Quiet Mode Switch Motor Light Switch Impeller Right Control Motor Switch Impeller Cover Left Control Motor Switch Impeller Cover Screw Input Wire Impeller Plastic Cover Wire Hole Rubber Oil Tunnel...
  • Page 19 Model CH –178 (48”)
  • Page 20 - Circuit Diagram - Model CH -178 (48’’)

  • Page 21: Specification

    - Specification - Model CH7830, CH7836, CH7842SQ, CH7848SQ Size 30”/ 36”/ 42”/ 48” Color 304 Commercial Grade Stainless Steel (all sizes), White (30”/36), Charcoal Black (30”36) Voltage 120V 60Hz Consumption CH7830 - 202W CH7842 - 237W CH7836 - 202W CH7848 - 348W 760 cfm (twin motors) 1,380 cfm (triple motors) (48”...

  • Page 22: Warranty Certificate

    WARRANTY CERTIFICATE KOBE Range Hoods warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component part which its examination shall disclose to be so defective.
  • Page 23 We must be notified in writing of any damages and/or missing parts within the allocated days upon receipt of package(s) Contact your local KOBE dealer or distributor or call KOBE for the time limit. CLAIMS WILL NOT BE ACCEPTED AFTER THE ALLOCATED DAYS.

  • Page 24: Consequential Damage

    This warranty gives you specific legal rights, and may also have rights which vary from state to state. SERVICE For service contact: KOBE Range Hoods 1039 South San Gabriel Blvd., San Gabriel, CA 91776 Call Toll Free 1-877-BUY-KOBE (1-877-289-5623) Email: info@koberangehoods.com www.koberangehoods.com...
