- Page 1 KOBE Range Hoods Brillia Series Model No.: Under Cabinet: CHX3830SQBD-3 (30”) CHX3836SQBD-3 (36”) Wall Mount: CHX3830SQBD-WM-3 (30”) CHX3836SQBD-WM-3 (36”) INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
- Page 2 3. Contact your merchant for product replacement due to shipping damages, cosmetic damages or defects. 4. For all other issues, call 1-877-BUY-KOBE (289-5623), or e-mail to info@koberangehoods.com NO RETURN, NO REFUND, NO EXCHANGE IF: 1. PRODUCT HAS BEEN INSTALLED 2.
-
Page 3: Table Of Contents
[ENGLISH] - READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..................1 COMPONENTS OF PACKAGE....................3 INSTALLATION .......................... 4 OPERATING INSTRUCTIONS....................10 MAINTENANCE ........................11 SPECIFICATIONS ........................12 MEASUREMENTS & DIAGRAMS .....................13 PARTS LIST ..........................15 CIRCUIT DIAGRAM ........................17 TROUBLE SHOOTING ......................18 WARRANTY ..........................19 WARRANTY INFORMATION FORM ..................21 - READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING -... -
Page 4: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 5 What to Do In The Event Of a Range Top Grease Fire • SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 6: Components Of Package
Knob attached to baffle filter 4 x 6mm (4 PCS) 2 PCS Wire caps (3) M4 x 3/4" (4) M4 x 1-1/2 (5) M4 x 1-1/4” (4) FOR MORE INFORMATION, PLEASE VISIT OUR W EBSITE www.koberangehoods.com CONTACT KOBE RANGE HOODS AT (626) 775-8880. -
Page 7: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to TABLE 1 and TABLE 2. (All calculation in inches.) - FOR UNDER THE CABINET - TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36") C = Preferred Height of Counter Top to... -
Page 8: Safety Warning
SAFETY WARNING HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF REMOVING ANY PARTS FOR INSTALLING, CLEANING OR SERVICING. NOTE: BE CAREFUL WHEN USING ELECTRICAL SCREWDRIVER, DAMAGE TO THE HOOD MAY OCCUR. Installation Contents UNDER THE CABINET WALL MOUNT... - Page 9 UNDER CABINET INSTALLATION Preparation before Installation Figure 1 Temporarily wire the hood to test for proper operation before installing. If the hood does not operate, check the circuit breaker or house fuse. If the hood is still not working, disconnect power supply and check the continuity of all wire connections.
- Page 10 Figure 2 Wiring to Power Supply CAUTION : If moving the cooking range is necessary to install the hood, turn off the power in an electric range at the main electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS RANGE.
-
Page 11: Wall Mount Installation
WALL MOUNT INSTALLATION ***This installation requires to have Duct Cover Model No. CH1120DC-1 Figure 3 Preparation before Installation Temporarily wire the hood to test for proper operation before installing. If the hood does not operate, check the circuit breaker or house fuse. - Page 12 Figure 6 Wiring to Power Supply CAUTION : If moving the cooking range is necessary to install the hood, turn off the power in an electric range at the main electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS RANGE.
-
Page 13: Operating Instructions
OPERATING INSTRUCTIONS Note: For best results, turn fan on prior to any preparation or cooking and keep fans running while cooking. Adjust speed as needed. To operate the fan function • Press button to choose from speed. o Q = QuietMode™ speed o L = Low speed o H = High speed •... -
Page 14: Maintenance
MAINTENANCE For optimal performance, clean the range hood surface and baffles regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. *** Regular care will help preserve its fine appearance. 1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth. 2. -
Page 15: Specifications
Ductless CONTROLS Mechanical Push Button LIGHTS 3-watt LED light x 2 HOOD DIMENSION CHX3830SQBD-3 and CHX3830SQBD-WM-3 29-3/4" x 21-11/16" x 5-7/8" (W x D x H) CHX3836SQBD-3 and CHX3836SQBD-WM-3 35-3/4" x 21-11/16" x 5-7/8" OPTIONAL ACCESSORIES 1) Two-Piece Adjustable Duct Cover (Included in Wall Mount Hood) (W x D x H) (CH1120DC-1) 11-13/16"... -
Page 16: Measurements & Diagrams
***All inch measurements are converted from millimeters. Inch measurements are estimated. ***All measurements in ( ) are millimeters. -FOR UNDER THE CABINET- MODEL NO.: CHX3830SQBD-3 (30”) CHX3836SQBD-3 (36”) 30" = Knockout Holes "A" 36" = Knockout Holes "B" - FOR WALL MOUNT (DUCT COVER IS INCLUDED) - MODEL NO.:... - Page 17 ***Hood-Mounting Bracket ***Duct Cover-Mounting Bracket ***Duct Cover Support...
-
Page 18: Parts List
PART LIST MODEL NO.: CHX3830SQBD-3 and CHX3830SQBD-WM-3 (30”) CHX3836SQBD-3 and CHX3836SQBD-WM-3 (36”) DESCRIPTION MODEL /SIZE PART NO. LED Light (3W) L1-0403-0301 Capacitor Support L1-0201-3830D Control Panel Support L1-0207-1630 Control Switch L1-0405-0301 Capacitor x 1PCS L1-0401-0120-03 Motor (A) L1-0301-0120-103A L1-0301-0120-103B Motor (B) - Page 19 MODEL NO.: CHX3830SQBD-WM-3 and CHX3830SQBD-WM-3 (30”) CHX3836SQBD-WM-3 and CHX3836SQBD-WM-3 (36”)
-
Page 20: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: CHX3830SQBD-3 and CHX3830SQBD-WM-3 (30”) CHX3836SQBD-3 and CHX3836SQBD-WM-3 (36”) -
Page 21: Trouble Shooting
TROUBLE SHOOTING Issue Possible Cause Solution After The power is not on. Make sure the circuit breaker and the unit’s Installation, power is ON. Use a voltage meter to check both motors the power supply. and lights are The wire connection is not secure. Check and tighten wire connection. -
Page 22: Warranty
TWO-YEAR LIMITED WARRANTY FOR PARTS AND LABOR ON KOBE PREMIUM SERIES: For two years from the date of your original invoice from a KOBE authorized dealer, we will, at our sole discretion, choose to repair or replace the product free of charge that failed due to manufacturing defects. - Page 23 3. Have the model number 4. Have the serial number 5. Have a description of the nature of any defect in the product or part TO REQUEST WARRANTY SERVICE, PLEASE CONTACT THE KOBE RANGE HOODS SERVICE CENTER: KOBE SERVICE CENTER (USA ONLY)
-
Page 24: Warranty Information Form
1. Date of purchase 2. Model No. 3. Serial No. For warranty service or spare parts purchase contact: KOBE Service Center (USA ONLY) Toll Free: 1-855-800-KOBE (5623) Email: kobe@adcoservice.com For service in Canada and to report a problem, please... - Page 25 Arcadia, CA 91006 USA www.koberangehoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a KOBE hood overseas is at your own risk and will void your warranty.
