- Page 1 KOBE Range Hoods Brillia Series CXX81 Series Model No.: CXX8130QF-GBK-1 (30”) CXX8136QF-GBK-1 (36”) CXX8130QF-MBK-1 (30”) CXX8136QF-MBK-1 (36”) INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
- Page 2 IMPORTANT READ THIS FIRST READ BEFORE INSTALLATION 1. Carefully check all contents of packages. 2. Thoroughly inspect the unit for any shipping damages, cosmetic damages or defects. 3. Have a certified contractor/electrician test the unit before installation. IF THERE IS ANY PROBLEM: 1.
-
Page 3: Table Of Contents
[ENGLISH] - READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..................1 COMPONENTS OF PACKAGE ....................3 INSTALLATION .......................... 4 OPERATING INSTRUCTIONS ....................7 MAINTENANCE .......................... 9 SPECIFICATIONS ........................10 MEASUREMENTS & DIAGRAMS ..................... 11 PARTS LIST ..........................12 CIRCUIT DIAGRAM ........................ -
Page 4: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 5 What to Do In The Event Of a Range Top Grease Fire SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 6: Components Of Package
(Must keep all material for returns or refunds) Glass Canopy Box (Box 1 of 2) {A} Glass Canopy Range Hood Box (Box 2 of 2) {B} KOBE Range Hood {C} 2-pc Duct Cover {D} Duct Cover Mounting Bracket {E} Warranty Registration Card... -
Page 7: Installation
1. Read any provided document(s). 2. Test the range hood by temporarily connecting it to an outlet and turning the fan and lights ON. 3. If you run into any problems, contact KOBE Range Hoods. Venting Requirements 4. This range hood has top 6” round exhaust (default). - Page 8 6. It is recommended to use metal/aluminum duct/pipe with a uniform size (ex. 6” round pipe from range hood to the outside). 7. If an elbow is necessary, a minimum of 12” straight run is necessary before the elbow. Clearance 8.
- Page 9 Electrical Wire 19. Connect the range hood to an outlet. 20. If hardwired is desired, cut off the plug and connect three wires (black, white, green) to the outlet wires and cap with wire connectors. Connect the wires according to color (ex: black to black). Finish 21.
-
Page 10: Operating Instructions
OPERATING INSTRUCTIONS Note: For best results, turn fan on prior to any preparation or cooking and keep fans running while cooking. Adjust speed as needed. Button Control Power Control Light Control Decrease Fan Speed Increase Fan Speed Power Control To turn the hood ON/OFF, press the power button once. Speed Control To adjust the speed level, press the decrease fan speed button to decrease the speed and the increase fan speed button to increase the speed. - Page 11 Light Control Press the light button to turn LED lights ON and OFF. The LED lights have 4 brightness levels, ranging from 1 to 4 (1 being the lowest and 4 being the brightest). Press and hold down the light button to increase the brightness by 1 level every 3 seconds.
-
Page 12: Maintenance
MAINTENANCE For optimal performance, clean the range hood surface and filters regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. **Regular care will help preserve its fine appearance. 1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth. 2. -
Page 13: Specifications
MODEL / SIZE CXX8130QF-GBK-1 (30”) CXX8136QF-GBK-1 (36”) CXX8130QF-MBK-1 (30”) CXX8136QF-MBK-1 (36”) COLOR CXX8130QF-GBK-1 (30”) – Gloss Black Finishing CXX8136QF-GBK-1 (36”) – Gloss Black Finishing CXX8130QF-MBK-1 (30”) – Matte Black Finishing CXX8136QF-MBK-1 (36”) – Matte Black Finishing CONSUMPTION / AMPERE 240W / 2.0A... -
Page 14: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS ***All inch measurements are converted from millimeters. Inch measurements are estimated. ***All measurements in ( ) are millimeters. -
Page 15: Parts List
PARTS LIST Model No.: CXX8130QF-GBK-1 (30”) CXX8136QF-GBK-1 (36”) CXX8130QF-MBK-1 (30”) CXX8136QF-MBK-1 (36”) DESCRIPTION MODEL PART NO. Duct Cover Mounting Bracket 02-009 Black Duct Cover CXX-0001 Processor Board CXX-0005 Capacitor CXX-0003 LED Lights x 2 02-005 Black Control Unit CXX-0002 Blower System... - Page 16 Model No.: CXX8130QF-GBK-1 (30”) CXX8136QF-GBK-1 (36”) CXX8130QF-MBK-1 (30”) CXX8136QF-MBK-1 (36”)
-
Page 17: Circuit Diagram
CIRCUIT DIAGRAM Model No.: CXX8130QF-GBK-1 (30”) CXX8136QF-GBK-1 (36”) CXX8130QF-MBK-1 (30”) CXX8136QF-MBK-1 (36”) -
Page 18: Trouble Shooting
TROUBLE SHOOTING Issue Possible Cause Solution After The power is not on. Make sure the circuit breaker and the Installation, unit’s power is ON. Use a voltage both motors meter to check the power supply. and lights are The wire connection is not secure. Check and tighten wire connection. -
Page 19: Warranty
ONE-YEAR LIMITED LABOR WARRANTY ON KOBE BRILLIA SERIES: For one year from the date of your original invoice from a KOBE authorized dealer, we will repair any parts or components free of charge that failed due to manufacturing defects. KOBE reserves the right to replace, rather than repair the product free of charge at our sole discretion. - Page 20 THIS WARRANTY WILL BE VOIDED BY: 1. Improper installation and failure to follow installation instructions. 2. Any repair, alteration, modification not authorized by KOBE. 3. Duct alteration, modification and connection. 4. Incorrect electric current, voltage or wiring. 5. Improper usage of the product such as commercial, outdoor or other usage other than residential indoor usage.
-
Page 21: Warranty Information Form
: __________________________ For warranty service or spare parts purchase in US, contact: KOBE Service Center Email (best): customer.service@koberangehoods.com Phone: 1-626-775-8880 Toll Free: 1-877-BUY-KOBE (289-5623) For warranty service or spare parts purchase in Canada, contact: Email (best): customer.service@koberangehoods.com Phone: 1-626-775-8880 Your notes:... - Page 22 This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a KOBE hood overseas is at your own risk and will void your warranty.
