- Page 1 KOBE Brand Range Hood Model No. CH8136SQ CH-181 SERIES – 11” HEIGHT INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
-
Page 2: Table Of Contents
- READ AND SAVE THESE INSTRUCTIONS - CONTENTS Important Safety Instructions………………………………………………………………. Components of Package………………………….……………………………………….. Installation…………………………………………………………………………………… Operating Instructions…………………………………...…………………………………. Maintenance…………………………………………………………………………………. Specifications…………………………………………………….……..…………………… Measurements & Diagrams…………………………………………………………...…… Parts List…………………………………………………………………..…………………. Circuit Diagram………………………………………………………………...……………. Disclaimer……………………………………………………………………………………. Warranty…………………………………………………………………...………………… Product Registration………………………………………………………...……………… - READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING - A L L W IR IN G M U S T B E D O N E B Y A P R O F E S S IO N A L A N D IN A C C O R D A N C E W IT H N AT IO N A L A N D L O C A L E LE C T R IC A L C O D E S . -
Page 3: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 4 What to Do In The Event Of a Range Top Grease Fire SMOTHER FLAMES with a close fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 5: Components Of Package
COMPONENTS OF PACKAGE (M u s t k e e p a ll m a te ria l fo r re tu rn s o r re fu n d s ) Range Hood Box {A} KOBE Range Hood with Two-Piece Duct Cover {B} Warranty Registration Card {C} Instructions Manual {D} Duct Cover Bracket... -
Page 6: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before installation To calculate the length of the installation, please refer to Table 1. (All calculation is measure in inches.) TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood Bottom (Recommended... - Page 7 - If necessary, prepare back wall frame with cross framing lumber for secure installation. Using references on Table 1 and the measurements on page 12, decide the level of the lumber. Refer to Figure 2. - Peel protective film off the duct cover and the hood (if any). - Loosen hood-mounting brackets at the back of the hood, adjust brackets and tighten screws as shown in Figure 3.
- Page 8 Figure 5 Ductwork Installation Use 6” round pipe to connect the plastic exhaust on the hood to the ductwork above. Use duct tape to make all joints secure and air tight. Refer to Figure 6. For 7” round ductwork, attach the 7” round duct adapter (provided) to the 6” round plastic exhaust on the hood.
- Page 9 10. Using reference E from Table 1 and measurements on page 12, mark the leveling point for duct cover bracket. 11. Secure the duct cover bracket to the wall with two screws (not provided). Make sure all screws are tightened. NOTE: Inner duct cover will cover the duct cover bracket. 12.
-
Page 10: Operating Instructions
OPERATING INSTRUCTIONS This KOBE hood is equipped with two-switch control panel, two powerful centrifugal turbine impellers with safety screens, two bright 12-volt 20-watt halogen lights, and four oil containers. The two control switches are Light Control and Speed Control. The two control switches operate independently of each other. -
Page 11: Maintenance
MAINTENANCE CAUTION: NEVER PUT YOUR HAND INTO THE AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. For the optimal level of operation, clean the range hood surface, safety screens, and oil containers regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. *** Regular care will help preserve its fine appearance. - Page 12 To Replace Light Bulb CAUTION: HALOGEN LIGHT UNIT MAY BE HOT! WAIT UNTIL UNIT IS COOL. 1) Make sure all control switches are off, and range hood is unplugged. 2) Use a flat head screwdriver to pop out the protective covering as shown on Figure 13. 3) Gently pull out the defective light bulb and discard.
-
Page 13: Specifications
Twin Turbine Impeller 6” Round 7” Round Adapter (Included) Three Speed (QuietMode™, Low, High) 12V 20W x 2 (CH8136SQ) 35-1/4” x 19-1/2” x 11” (CH81SDC) 8-1/4” x 8-7/8” x (14-1/8”~27-1/4”) 1) Two-Piece Extension Duct Cover (CH81SDC) 8-1/4” x 8-7/8” x (14-1/8”~27-1/4”) 2) Euro Style Steel Rack (CH81SR) 35-1/2”... -
Page 14: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS ***Hood-Mounting Bracket ***Duct Cover Bracket... -
Page 15: Parts List
PARTS LIST MODEL NO.: CH8136SQ DESCRIPTION Duct Cover 7” Round Adapter Duct Cover Position Plate Exhaust Duct Stand Side Trim (Right) Side Trim (Left) Front Trim Hood Casing Control Unit Halogen Light (12V 20W Max.) Wire Box Capacitor Center Position Panel... - Page 16 MODEL NO.: CH8136SQ...
-
Page 17: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: CH8136SQ... -
Page 18: Disclaimer
DISCLAIMER 1. CAREFULLY INSPECT ALL ITEMS FOR DAMAGES BEFORE ACCEPTING DELIVERY. NOTE ANY DAMAGES ON THE FREIGHT BILL OR EXPRESS RECEIPT. REQUEST NAME AND SIGNATURE OF THE CARRIER’S AGENT AND KEEP COPY TO SUPPORT YOUR CLAIM. Upon acceptance of items, owner assumes responsibility for its safe arrival. Damages should be reported to carrier and a claim filed. -
Page 19: Warranty Certificate
WARRANTY KOBE Range Hoods, Inc. warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component part, which its examination shall disclose to be so defective. -
Page 20: Consequential Damage
Some states do not allow limitations on the duration of implied warranties. This warranty gives you specific legal rights, and may also have rights, which vary from state to state. For service contact: KOBE Range Hoods 4934 Walnut Grove Avenue Suite 202 San Gabriel, CA 91776 U.S.A... -
Page 21: Product Registration
KOBE Range Hoods Agent or KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection.
