- Page 1 KOBE Brand Range Hood Model No. CH8136SQ CH-181 SERIES – 11” HEIGHT INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
-
Page 2: Table Of Contents
- READ AND SAVE THESE INSTRUCTIONS - CONTENTS Important Safety Instructions………………………………………………………………. Components of Package………………………….……………………………………….. Installation…………………………………………………………………………………… Operating Instructions…………………………………...…………………………………. Maintenance…………………………………………………………………………………. Specifications…………………………………………………….……..…………………… Measurements & Diagrams…………………………………………………………...…… Parts List…………………………………………………………………..…………………. Circuit Diagram………………………………………………………………...……………. Disclaimer……………………………………………………………………………………. Warranty…………………………………………………………………...………………… Product Registration………………………………………………………...……………… - READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING - ALL WIRING MUST BE DONE BY A PROFESSIONAL AND IN ACCORDANCE WITH NATIONAL AND LOCAL ELECTRICAL CODES. -
Page 3: Important Safety Instructions
KOBE RANG E HOODS authorized agents. Any repair carried out without the supervision of KOBE RANGE HOODS authorized agents will automatically void the warranty. - Page 4 What to Do In The Event Of a Range Top Grease Fire SMOTHER FLAMES with a close fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 5: Components Of Package
COMPONENTS OF PACKAGE (Must keep all material for returns or refunds) Range Hood Box {A} KOBE Range Hood with Two-Piece Duct Cover {B} Warranty Registration Card {C} Instructions Manual {D} Duct Cover Bracket {E} Hood-Mounting Bracket {F} Oil Containers (Round) -
Page 6: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before installation To calculate the length of the installation, please refer to Table 1. (All calculation is measure in inches.) TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood Bottom (Recommended... - Page 7 - If necessary, prepare back wall frame with cross framing lumber for secure installation. Using references on Table 1 and the measurements on page 12, decide the level of the lumber. Refer to Figure 2. - Peel protective film off the duct cover and the hood (if any). - Loosen hood-mounting brackets at the back of the hood, adjust brackets and tighten screws as shown in Figure 3.
- Page 8 Mounting Screws Figure 5 Ductwork Installation Use 6” round pipe to connect the plastic exhaust on the hood to the ductwork above. Use duct tape to make all joints secure and air tight. Refer to Figure 6. For 7” round ductwork, attach the 7” round duct adapter (provided) to the 6” round plastic exhaust on the hood.
- Page 9 10. Using reference E from Table 1 and measurements on page 12, mark the leveling point for duct cover bracket. 11. Secure the duct cover bracket to the wall with two screws (not provided). Make sure all screws are tightened. NOTE: Inner duct cover will cover the duct cover bracket. 12.
-
Page 10: Operating Instructions
OPERATING INSTRUCTIONS This KOBE hood is equipped with two-switch control panel, two powerful centrifugal turbine impellers with safety screens, two bright 12-volt 20-watt halogen lights, and four oil containers. The two control switches are Light Control and Speed Control. The two control switches operate independently of each other. -
Page 11: Maintenance
MAINTENANCE CAUTION: NEVER PUT YOUR HAND INTO THE AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. For the optimal level of operation, clean the range hood surface, safety screens, and oil containers regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. *** Regular care will help preserve its fine appearance. - Page 12 To Replace Light Bulb CAUTION: HALOGEN LIGHT UNIT MAY BE HOT! WAIT UNTIL UNIT IS COOL. 1) Make sure all control switches are off, and range hood is unplugged. 2) Use a flat head screwdriver to pop out the protective covering as shown on Figure 13. 3) Gently pull out the defective light bulb and discard.
-
Page 13: Specifications
CONTROLS Three Speed (QuietMode™, Low, High) HALOGEN LIGHTS 12V 20W x 2 HOOD DIMENSION (W x D x H) (CH8136SQ) 35-1/4” x 19-1/2” x 11” DUCT COVER DIMENSION (CH81SDC) 8-1/4” x 8-7/8” x (14-1/8”~27-1/4”) (W x D x H) OPTIONAL ACCESSORIES... -
Page 14: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS ***Hood-Mounting Bracket ***Duct Cover Bracket... -
Page 15: Parts List
PARTS LIST MODEL NO.: CH8136SQ DESCRIPTION MODEL /SIZE PART NO. Duct Cover CH81SDC 90A-1-0001 7” Round Adapter 90A-2-0002 Duct Cover Position Plate 90A-3-0003 Exhaust Duct Stand 90A-4-0004 Side Trim (Right) 90A-5-2005 Side Trim (Left) 90A-5-1005 Front Trim 90A-6-0006 Hood Casing... - Page 16 MODEL NO.: CH8136SQ...
-
Page 17: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: CH8136SQ... -
Page 18: Disclaimer
2. PLEASE INSPECT CONTENTS OF PACKAGE (S) CAREFULLY UPON RECEIPT! We must be notified in writing of any damages and/or missing parts within the allocated days upon your receipt of package(s). Contact your local KOBE dealer or distributor or call KOBE for the time limit. -
Page 19: Warranty
WARRANTY WARRANTY CERTIFICATE KOBE Range Hoods, Inc. warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component, which its examination shall disclose to be so defective. - Page 20 KOBE Range Hoods Agent as applicable, for any traveling expenses and costs of transporting the range hood or parts thereof to and from the dealer or Service Agent.
-
Page 21: Product Registration
KOBE Range Hoods Agent or KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection.
