- Page 1 KOBE Brand Range Hood Model No. CH8136SQB CH-181 SERIES – 11” HEIGHT INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
-
Page 3: Table Of Contents
- READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ... 1 COMPONENTS OF PACKAGE ... 3 INSTALLATION... 4 OPERATING INSTRUCTIONS ... 8 MAINTENANCE ... 9 SPECIFICATIONS ... 11 MEASUREMENTS & DIAGRAMS... 12 PARTS LIST... 13 CIRCUIT DIAGRAM ... 16 DISCLAIMER ... -
Page 4: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 5 What to Do In The Event Of a Range Top Grease Fire SMOTHER FLAMES with a close fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 6: Components Of Package
COMPONENTS OF PACKAGE (Must keep all material for returns or refunds) {A} Body {B} Warranty Registration Card {C} Instructions Manual {D} 6-1/4” Plastic Damper {E} Rubber Seal {F} Inner / Outer Duct Cover with Bracket {G} Hood-Mounting Bracket Screw Package {I} Baffle Filters... -
Page 7: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTION BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to Table 1. (All calculation in inches.) TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood Bottom (Recommended 27”... - Page 8 2. Peel protective film off the duct covers and the hood (if any). 3. If necessary, remove the rubber stand at the back of the hood and store in case of future use. (For a more secure installation, KOBE recommends not removing the rubber stands.) Refer to Figure 3.
- Page 9 Hood Installation CAUTION If moving the cooking range is necessary to install the hood, turn off the power in an electric range at the main electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS RANGE. 8. Using references in Table 1 and measurements on page 12, mark the leveling point for hood-mounting bracket on the wall.
- Page 10 Wiring Power Supply SAFETY WARNING RISK OF ELECTRICAL SHOCK. THIS RANGE HOOD MUST BE PROPERLY GROUNDED. MAKE SURE THIS IS DONE BY SPECIALIZED ELECTRICIAN IN ACCORDANCE WITH APPLICABLE NATIONAL CONNECTING WIRES, SWITCH POWER OFF AT SERVICE PANEL TO PREVENT POWER FROM BEING SWITCHED ON ACCIDENTALLY.
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS This hood is equipped with three speeds, powerful centrifugal squirrel cage with baffle filters, and two bright 12-volt 20-watt halogen lights. The control buttons are the light and speed controls (QuietMode™, Low and High). Refer to Figure 12. Light Control Speed Control Figure 12... -
Page 12: Maintenance
MAINTENANCE SAFETY WARNING NEVER PUT YOUR HAND INTO AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. For optimal operation, clean range hood surface and stainless steel baffle filters regularly. Cleaning Hood Surface CAUTION NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. Regular care will help preserve the appearance of the hood. - Page 13 Cleaning Stainless Steel Baffle Filter CAUTION : DRAIN OIL BEFORE RESIDUE CAN OVERFLOW. 1. Grasp knob on baffle filter and push filter toward rear . 2. Gently pull each baffle filter down 3. Wash baffle filters with warm soapy water. 4.
-
Page 14: Specifications
SPEED *In House Test Static Pressure “0”. One Sone is equivalent to the sound of a refrigerator at 40 decibels. **Specifications subject to change without notice. CH8136SQB / 36” # 304 Commercial Grade Stainless Steel 20-Gauge / Satin Finish Squirrel Cage 6-1/4”... -
Page 15: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS All inch measurements are converted from millimeters. Inch measurements are estimated. -
Page 16: Parts List
PARTS LIST MODEL NO.: CH8136SQB DESCRIPTION Duct Cover Bracket Inner Duct Cover Outer Duct Cover 6-1/4” Plastic Damper Rubber Seal Screws (3/16” X 3/8”) Back Casing Blower Assembly Screws (3/16” X 3/8”) Brackets Hood Frame Left / Right Side Trim... - Page 17 MODEL NO.: CH8136SQB...
- Page 18 Blower Assembly Screw (3/16” X 3/8”) Air Flow Grill Right Locknut Motor Fixture Ring Vent Plate Left Blower Left Locknut Air Chamber Right Blower DESCRIPTION MODEL / SIZE PART NO. G3231 CY0406 CY0382 CY0519 CY0572 CY0529 CY0160 CY0365 CH0052 CY0161...
-
Page 19: Circuit Diagram
CIRCUIT DIAGRAM WHITE BLACK AC 120V 60Hz CAPACITOR MOTOR 12uF / 450V... -
Page 20: Disclaimer
DISCLAIMER 1. CAREFULLY INSPECT ALL ITEMS FOR DAMAGES BEFORE ACCEPTING DELIVERY. NOTE ANY DAMAGES ON THE FREIGHT BILL OR EXPRESS RECEIPT. REQUEST NAME AND SIGNATURE OF THE CARRIER’S AGENT AND KEEP COPY TO SUPPORT YOUR CLAIM. Upon acceptance of items, owner assumes responsibility for its safe arrival. Damages should be reported to carrier and a claim filed. -
Page 21: Warranty
WARRANTY KOBE Range Hoods, Inc. warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component part, which its examination shall disclose to be so defective. -
Page 22: Consequential Damage
Some states do not allow limitations on the duration of implied warranties. This warranty gives you specific legal rights, and may also have rights, which vary from state to state. For service contact: KOBE Range Hoods 10505 Valley Blvd, Suite 302 EI Monte, CA 91731 U.S.A... -
Page 23: Product Registration
KOBE Range Hoods Agent or KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection. - Page 24 KOBE Range Hoods 10505 Valley Blvd Suite # 302 El Monte, CA 91731 USA http://www.KOBERangeHoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country.
