6. Control Panel Connections
The table below shows the connection details to various control panels.
Control Panel
Menvier TS400/TS410
Menvier TS510
Menvier TS690R
Menvier TS690/TS700
Menvier TS790/TS900/TS2500
A1 Advantage
ADE Optima XM
ADE Optima 2+
ADE Concept 6
ADE Accenta 6
Ademco Infra 6
Ademco Infra 16
C & K 700L
CQR Premia 9
DA Abacus 6
DA Abacus 8
Gardtec 500 Series
Gardtec 800 Series
JSB Regent
Pyronix Paragon + /E
Pyronix Octagon
Pyronix Conqueror
Scantronic 9448
Scantronic 9452/3
Scantronic 9454
Scantronic 9455
Texecom Veritas R8
Texecom Veritas 8 Compact
+
* Control panel output requires programming.
When using the bell output to trigger the SD1+, you may find that the external sounder is
partially triggered. If this is the case a 1K resistor will need to be connected between the
SD1+ trigger input and +12V.
TRIG A TRIG B
Fire PA
Zone 4 Zone 5
N/A OP 2 *
OP 1 OP 2
Digi 1 Digi 2
Digi 1 Digi 2
N/A N/A
N/A N/A
Fire PA
N/A N/A
N/A N/A
N/A N/A
1* 2
N/A N/A
FA * PA
N/A N/A
N/A N/A
N/A N/A
D1 * PA
COM1 COM2
N/A N/A
N/A PA
N/A N/A
N/A COM 2
N/A COM 1
N/A COM 1
N/A COM 1
N/A N/A
N/A N/A
TRIG C Polarity
Alarm
ALM -
OP 1 * +
OP 3 -
Digi 3 -
Digi 3 -
Bell - -
B -
Intruder -
B -
B -
3 +
3 +
S- -
IA +
Bell -
Bell -
Bell - -
12Hr -
COM3 +
BA -
ALM -
BA -
COM 3 -
COM 3 -
COM 3 -
COM 3 -
B -
B -
Supply + Supply -
Aux + Aux -
Aux + Aux -
Aux + Aux -
Aux + Aux -
Aux+ Aux -
Aux + Aux -
13V + 13V -
13V + 13V -
13V + 13V -
13V + 13V -
Aux + Aux -
Aux + Aux -
Aux + Aux -
Aux 12V Aux 0V
+12V 0V
+12V 0V
Power + Power -
12V 0V
12V 0V
Aux + Aux -
Aux + Aux -
Aux + Aux -
12V 0V
Aux 12V Aux 0V
12V 0V
12V 0V
Aux + Aux -
Aux + Aux -
Trigger
Type
0V app.
12V app.
0V app.
0V app.
0V app.
0V app.
0V app.
0V app.
0V app.
0V app.
12V app.
12V app.
0V app.
12V app.
0V app.
0V app.
0V app.
0V app.
12V app.
0V app.
0V app.
0V app.
5V rem.
5V rem.
5V rem.
5V rem.
0V app.
0V app.
