SECTION 6 MECHANICAL PARTS
[CASE]
REF. ORDER
DESCRIPTION
NO. NO.
MF1 2710000750 FBA08A12LZ (RIB)
W1 8900013140 OPC-1323 (2731 POWER-SW CABLE)
W2 8900013210 OPC-1307 (2731 DC CABLE)
W3 8900013240 OPC-1373 (2731 FAN CABLE)
W4 8900013170 OPC-1306 (2731 TRX-ANT CABLE)
W5 8900013170 OPC-1306 (2731 TRX-ANT CABLE)
EP1 6910008330 G80-18
MP1 8010019581 2732 CHASSIS-1
MP2 8930062871 2731 R-PLATE-1
MP3 8930062861 2731 L-PLATE-1
MP4 8110008171 2731 COVER-1
MP5 8210023000 2732 PANEL (B)
MP6 8930062851 2731 M-PLATE-1
MP7 8930062851 2731 M-PLATE-1
MP8 8930062841 2731 FAN HOLDER-1
MP9 8930063090 BH-60S
MP10 8850002040 Z-8S
MP12 8930048350 2146 LENS
MP13 8950003170 Nylon clip SL-8N
MP14 8810006470 setscrew (C) 4×12 SUS
MP15 8810003361 setscrew (C) 3×6 ZC3
MP16 8810003361 setscrew (C) 3×6 ZC3
MP17 8810003361 setscrew (C) 3×6 ZC3
MP18 8810003361 setscrew (C) 3×6 ZC3
MP20 8810003361 setscrew (C) 3×6 ZC3
MP21 8810002950 binding screw M3×6 SUS
MP22 8810002950 binding screw M3×6 SUS
MP23 8810002950 binding screw M3×6 SUS
MP24 8810010131 setscrew (C) 3×35 ZC3
MP25 8810003391 setscrew (C) 4×8 ZC3
MP26 8810003391 setscrew (C) 4×8 ZC3
MP27 8830000111 Nut M4 ZC3
MP28 8850000140 flat washer M4 BS NI
MP29 8850000130 flat washer M3 BS NI 3×8×0.5
MP30 8810002950 binding screw M3×6 SUS
[FRONT UNIT]
REF. ORDER
DESCRIPTION
NO. NO.
J1 6450002101 CMS1410-016010
J2 6450002101 CMS1410-016010
J3 6510020251 B9B-PH-SM4-TB (LF) (SN)
J4 6510022311 B5B-PH-SM4-TB (LF) (SN)
DS1 5040003070 MPG4371F
S1 2220000631 MFS201N-16-Z
[REAR UNIT]
REF. ORDER
DESCRIPTION
NO. NO.
J2 6510016171 52018-8836
[ACCESSORIES]
REF. ORDER
QTY. DESCRIPTION
NO. NO.
1 F1 5210000071 FGB 10A PBF
1 W1 8900013190 OPC-1309 (2731 DC-IN CABLE)
1 W2 8900010551 OPC-1069A
1
1 EP1 7800000330 Utility CD
1
MP1 8930057680 Rubber leg (O)
1
1
1
1
1
1
W1
W2
2
2
2
1
4
1
F1
1
4 MP1
4
4
4
4
Screw abbreviations BiH: Binding head
1
12 SUS: Stainless NI: Nickel
2
BS: Brass
1
4
4
4
1
1
1
2
QTY.
1
1
1
1
1
1
QTY.
1
6 - 1
[CHASSIS-T PARTS]
REF. ORDER
QTY.
NO. NO.
2
IC204 1150002042 RA30H1317M-121
1
J1 6510004910 NR-DSE-01
1
P1 5610000380 TMP-K01X-A1
1
P2 5610000380 TMP-K01X-A1
4
MF1 2710000590 MF40D-12H-001
W1 8900010890 OPC-1115
W2 8900010890 OPC-1115
W3 9025900540 62/99/270/C31/C31
W4 9086700300 08
MP1 8010019621 2506 CHASSIS (A)-2
MP2 8810008661 Screw BT B0 3×8 NI-ZC3 (BT)
MP3 8810008661 Screw BT B0 3×8 NI-ZC3 (BT)
MP4 8810008661 Screw BT B0 3×8 NI-ZC3 (BT)
MP5 8110006640 2047 COVER
MP6 8810008451 binding screw M4×8 ZK3
EP1
MP7 8810008661 Screw BT B0 3×8 NI-ZC3 (BT)
MP9 8110005751 1729 FAN COVER-1
MP10 8810009111 Screw M2.6×16 ZK3
MP11 8510012210 2047 MAIN SHIELD
MP12 8810007131 setscrew (H) 3×6 ZC3
MP13 8930001170 earth spring (A) (FX-294)
[MAIN-T UNIT]
REF. ORDER
NO. NO.
J1 6510009351 B2B-ZR (LF) (SN)
J2 6510021721 30FLT-SM2-TB (LF) (SN)
J3 6510021721 30FLT-SM2-TB (LF) (SN)
J4 6510018450 TMP-S01X-B1
W1 8900004880 OPC-465
MP1 8510011111 1922 VCO CASE-1
MP2 8510011111 1922 VCO CASE-1
MP3 8510014760 2493 PLL CASE
MP4 8510017220 2850 VCO COVER
MP5 8510017220 2850 VCO COVER
MP6 8510014750 2493 PLL COVER
MP7 8930056580 Spacer (AD)
MP8 8810007131 setscrew (H) 3×6 ZC3
MP9 8930059770 2633 M-HOLDER
MP10 8930014140 earth spring (D)
[LOGIC-T UNIT]
REF. ORDER
NO. NO.
J1 6510022711 30FLZ-SM2-TB (LF) (SN)
J2 6510022711 30FLZ-SM2-TB (LF) (SN)
J4 6510019271 52365-0671
J5 6510021431 S8B-ZR-SM4A-TF (LF) (SN)
J6 6510023861 S9B-ZR-SM4A-TF (LF) (SN)
W1 8900013180 OPC-1312 (2732 TX-CTRL CABLE)
MP1 8510014481 2506 CPU SHIELD-1
MP3 8510002280 VCO shield plate (A)
[CHASSIS-R PARTS]
REF. ORDER
DESCRIPTION QTY.
NO. NO.
1 J1 6510004910 NR-DSE-01
1 W1 8900010890 OPC-1115
W2 8900010890 OPC-1115
1
1 MP1 8010019621 2506 CHASSIS (A)-2
MP2 8810008661 screw BT B0 3×8 NI-ZC3 (BT)
* 1 MP3 8810008661 screw BT B0 3×8 NI-ZC3 (BT)
MP4 8810008661 screw BT B0 3×8 NI-ZC3 (BT)
1 MP5 8110006640 2047 COVER
1 MP6 8810008451 binding screw M4×8 ZK3
1 MP7 8510012210 2047 MAIN SHIELD
1 MP8 8810007131 setscrew (H) 3×6 ZC3
1
[MAIN-R UNIT]
2
2
REF. ORDER
7
NO. NO.
1
J1 6510021721 30FLT-SM2-TB (LF) (SN)
1
J2 6510021721 30FLT-SM2-TB (LF) (SN)
1
J3 6510018450 TMP-S01X-B1
1
4
W1 8900004880 OPC-465
2
4
EP2 6910013310 MMZ1608D121B
1
MP1 8510011111 1922 VCO CASE-1
MP2 8510017220 2850 VCO COVER
MP3 8930056580 Spacer (AD)
MP4 8810007131 setscrew (H) 3×6 ZC3
DESCRIPTION QTY.
MP5 8510002280 VCOshield plate (A)
MP6 8930014140 earth spring (D)
1
MP7 8510016420 2506 VCO CASE
1
MP8 8510016430 2506 VCO COVER
1
1
[LOGIC-R UNIT]
1
REF. ORDER
NO. NO.
1
J1 6510022711 30FLZ-SM2-TB (LF) (SN)
1
J2 6510022711 30FLZ-SM2-TB (LF) (SN)
1
J4 6510019271 52365-0671
1
J5 6510021431 S8B-ZR-SM4A-TF (LF) (SN)
1
J6 6510023861 S9B-ZR-SM4A-TF (LF) (SN)
1
4
W1 8900013161 OPC-1313A (2732 RX-CTRL CABLE)
4
1
MP1 8510014481 2506 CPU SHIELD-1
1
MP3 8510002280 VCO shield plate (A) (FX-15)
MP4 8510010460 1691 MAIN SHIELD PLATE
MP5 8510010460 1691 MAIN SHIELD PLATE
*Note: Refer to SECTION 9 BOARD LAYOUTS.
DESCRIPTION QTY.
1
1
Screw abbreviations
1
1
1
1
1
(FX-15) 1
6 - 2
DESCRIPTION QTY.
1
1
1
1
2
1
7
1
1
2
4
DESCRIPTION QTY.
1
1
1
1
1
1
1
4
4
(FX-15) 1
1
1
1
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
BT: Self-tapping PH: Pan head
BiH: Binding head
ZK, ZK3: Black ZC, ZC3: Black
NI-ZU: Nickel-Zinc
