BROADBAND-AT-SEA VSAT ANTENNA SYSTEM
Sea Tel, Inc.
4030 Nelson Avenue
Concord, CA 94520
Tel: (925) 798-7979
Fax: (925) 798-7986
Web:
http://www.cobham.com/seatel
Sea Tel Inc is also doing business as Cobham Antenna Systems
May 4, 2012
INSTALLATION MANUAL
FOR SEA TEL 4012 GX KU-BAND
Sea Tel Europe
Unit 1, Orion Industrial Centre
Wide Lane, Swaythling
Southampton, UK S0 18 2HJ
Tel: 44 (0)23 80 671155
Fax: 44 (0)23 80 671166
Web:
http://www.cobham.com/seatel
Document. No. 136878 Revision A

Advertisement

Table of Contents
loading

Related Manuals for Sea Tel 4012 GX KU-BAND

Summary of Contents for Sea Tel 4012 GX KU-BAND

  • Page 1 Southampton, UK S0 18 2HJ Fax: (925) 798-7986 Tel: 44 (0)23 80 671155 Web: http://www.cobham.com/seatel Fax: 44 (0)23 80 671166 Web: http://www.cobham.com/seatel Sea Tel Inc is also doing business as Cobham Antenna Systems May 4, 2012 Document. No. 136878 Revision A...
  • Page 2 Copyright © 2012 Sea Tel Inc All Rights Reserved. The information contained in this document is proprietary to Sea Tel, Inc.. This document may not be reproduced or distributed in any form without prior written consent of Sea Tel, Inc. The information in this document is subject to change without notice.
  • Page 3 Revision History ECO# Date Description March 7, 2012 PRELIMINARY Release. May 4, 2012 Production Release...
  • Page 4 The Equipments Maker / Supplier have to declare if his equipment / equipments contain any of the hazardous material listed below with concentration and duly signed and stamped. Vessel Name/Hull Number/Shipyard: Equipment Details: All Sea Tel manufactured antenna systems. Supplier Details: Sea Tel, Inc 4030 Nelson Ave Concord, CA.
  • Page 5 Other Substances inherent in the machinery, equipment or fittings of supplied system Type Equipments/Components Location (If Applicable) Approximate contain such materials quantity/volume Lubricating Oil Hydraulic Oil Lead Acid Batteries Alcohol Methylated Spirits Epoxy Resins Mercury Radioactive Materials Other (Specify) Copyright © Sea Tel, Inc 2011 Document Number 136150 rev A...
  • Page 6 All of the plastics used on Sea Tel antenna systems are completely inert and pose no harm when in use or when scrapped. All of the lubricating oils used on Sea Tel antenna systems are completely inert and pose no harm when in use or when scrapped.
  • Page 7 F: +1 (925) 798-7986 R&TTE Declaration of Conformity Sea Tel Inc. declares under our sole responsibility that the products identified below are in compliance with the requirements of: DIRECTIVE 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on Radio equipment and Telecommunication Terminal Equipment and the mutual recognition of their conformity.
  • Page 8 2009 version of FCC 47 C.F.R. § 25.222. Sea Tel hereby declares that the antennas listed below will meet the off-axis EIRP spectral density requirements of § 25.222 (a)(1)(i) with an N value of 1, when the following Input Power spectral density limitations are met: *0.6 Meter Ku Band, Models 2406 and USAT-24 are limited to...

  • Page 9: Table Of Contents

    Table of Contents 4012 GX Installation Manual 1. 4012 GX SYSTEM CONFIGURATION(S) ............................1-1 1.1......................................1-1 YSTEM ABLES 1.2................................... 1-1 THER NPUTS TO THE YSTEM 1.3. 4012 GX ........................... 1-1 IMPLIFIED BLOCK DIAGRAM OF A SYSTEM 1.4................................1-1 NTENNA ONFIGURATION 1.5.
  • Page 10 4012 GX Installation Manual Table of Contents 3.7.4. Other BDE connections ..............................3-12 3.8....................................... 3-12 INAL HECKS 3.8.1. Visual/Electrical inspection ............................... 3-12 3.8.2. Electrical - Double check wiring connections ......................3-12 3.9. ™ (MXP) ............................3-13 ETUP EDIA CHANGE OINT 4.
  • Page 11 Table of Contents 4012 GX Installation Manual 13.2.2. MXP Box Rear Panel Connections ..........................13-8 13.2.3. Integrated SCPC Receiver ..............................13-8 13.2.4. Control Interface ..................................13-9 13.2.5. SW1 Local Band Select Output ............................13-9 13.2.6. SW2 Blockage/ TX Mute Output ............................. 13-9 13.2.7.
  • Page 12 4012 GX Installation Manual Table of Contents This Page Intentionally Left Blank...

  • Page 13: Gx System Configuration(S)

    4012 GX System Configuration(s) 4012 GX Installation Manual 4012 GX System Configuration(s) The 4012 GX Stabilized Antenna system is to be used for Transmit/Receive (TX/RX) satellite communications, it is comprised of two major groups of equipment. These are the Above Decks Equipment (ADE) and the Below Decks Equipment (BDE). There will also be interconnecting cables between the ADE &...

  • Page 14: Open Antenna-Modem Interface Protocol (Openamip™) Specification

    MXP/PCU (setup parameters) are actually compatible for the intended satellite(s). 1.5.2. Interface requirements: 1.5.2.1. Hardware Sea Tel Media Xchange Point (MXP) Any Satellite modem manufacturer that is compatible with OpenAMIP CAT5 Patch cable 1.5.2.2. Software Sea Tel MXP software version (latest).
  • Page 15 Set keep alive in seconds (0 = off) “a 5” i s1 s2 Set Antenna Vendor (s1) and device (s2) 2 parameters: “i Sea Tel DAC-2202” s b1 b2 Antenna Status: 2 parameters: “s 1 1” b1 is functional status and b2 is Tx allowed...
  • Page 16 4012 GX Installation Manual 4012 GX System Configuration(s) This Page Intentionally Left Blank...

  • Page 17: Site Survey

    Site Survey 4012 GX Installation Manual Site Survey The objective of the Site survey is to find the best place to mount the antenna & the below decks equipment, the length and routing of the cables and any other items or materials that are required to install the system and identify any other issues that must be resolved before or during the installation.

  • Page 18: Mounting Foundation

    The height of the pedestal should be kept as short as possible, taking into account recommendations given in other Sea Tel Guidelines. The minimum height of the pedestal above a flat deck or platform to allow access into the radome for maintenance should be 0.6 meters (24 inches).

  • Page 19: Mounting Height

    2.5. Mast Configurations Sea Tel recommends the ADE be mounted on the ship in a location which has both a clear line-of-sight to the target satellites in all potential azimuth/elevation ranges and sufficient support against vibration excitement. If possible, mounting the ADE pedestal directly to ship deckhouse structures or other box stiffened structures is preferred.

  • Page 20: Vertical Masts

    4012 GX Installation Manual Site Survey 2.5.1. Vertical Masts Vertical masts are a very ancient and common mast design. In essence, it is the mast derived from the sailing mast, adapted for mounting the ever-increasing array of antennae ships need to communicate with the world.

  • Page 21: Truss Mast

    For every 100 Kilograms of ADE weight over 250 Kilograms, the depth of the platform stiffeners should be increased by 50 millimeters and thickness by 2 millimeters. Sea Tel does not have a recommended arrangement for a truss mast – the variability of truss mast designs means that each installation needs to be evaluated separately.

  • Page 22: Ade/Bde Coaxial Cables

    4012 GX Installation Manual Site Survey moisture exists. The ends of the conduit shall be sealed with cable glands (preferred), mastic or low VOC silicon sealant after the cables have been passed through. Cables passing through bulkheads or decks shall be routed through approved weather tight glands. 2.8.1.

  • Page 23: Grounding

    Site Survey 4012 GX Installation Manual 2.9. Grounding All metal parts of the ADE shall be grounded to bare metal at the mounting pedestal. Grounding straps from the base of the ADE to a dedicated lug on the mounting pedestal are preferred, but grounding may also be accomplished by exposing bare metal under all mounting bolts prior to final tightening.
  • Page 24 4012 GX Installation Manual Site Survey This Page Intentionally Left Blank...

  • Page 25: Installation

    Installation 4012 GX Installation Manual Installation Your antenna pedestal comes completely assembled in its radome. This section contains instructions for unpacking, final assembly and installation of the equipment. It is highly recommended that installation of the system be performed by trained technicians.

  • Page 26: Installing The Ade

    4012 GX Installation Manual Installation 3.3. Installing the ADE The antenna pedestal is shipped completely assembled in its radome. Please refer to the entire Site Survey chapter of this manual. Base Hatch Access - Mounting the radome directly on the deck, or platform prevents access to the hatch in the base of the radome unless an opening is designed into the mounting surface to allow such entry.

  • Page 27: Installing The 61" Radome Assembly

    Installation 4012 GX Installation Manual Attach shackles and four part web lifting sling arrangement to the eyebolts. Attach a suitable length tagline to one of the eyebolts. After hoisted into place the lifting eyes are to be removed & replaced with the stainless hardware that was removed in step 4 (the eyes are galvanized with bare thread that will rust if left exposed to the weather).
  • Page 28 Other locations around the radome base are MUCH thicker, requiring longer strain reliefs than the ones provided by Sea Tel. Refer to the strain relief installation procedure provided in the Drawings chapter of this manual.
  • Page 29 Installation 4012 GX Installation Manual 14. Remove the clamp bar and Roxtec® Multidiameter® blocks from their cable mounting frame in the cable passage channel. 15. Remove the rubber bar from the top of the Roxtec® Multidiameter® blocks. 16. Remove the Roxtec® Multidiameter® blocks from the cable mounting frame.

  • Page 30: Grounding The Pedestal

    Braid is the conductor of choice where flexibility is required. Sea Tel uses braid to cross axes of the antenna pedestal and to connect various subassemblies together.

  • Page 31: Removing The Shipping/Stow Restraints Prior To Power-Up

    Installation 4012 GX Installation Manual Provide a grounding strap/cable (of adequate gauge for the length) to provide a good ground drain for the antenna pedestal. This cable/strap must also be insulated where it may be exposed to weather. NOTE: Minimum gauge should not be smaller than 10 AWG, even for a short cable run.

  • Page 32: Removing The El Shipping/Stow Restraint

    4012 GX Installation Manual Installation To un-stow the antenna, remove the pin bolt from the LOCK position. Install the pin bolt into the STOW hole and tighten. This assures that it does not get lost and will be ready for re-use if the antenna needs to be stowed again at a later date.
  • Page 33 Installation 4012 GX Installation Manual To un-restrain the elevation axis of the antenna, unthread the two hex nuts. Remove the hex nuts and washer from the stow pin- bolt. Remove the stow pin-bolt from the bracket. Remove the washer from the stow pin-bolt and thread one of the 2 hex nuts onto the bolt and tighten.

  • Page 34: Removing The Cl Shipping/Stow Restraint

    4012 GX Installation Manual Installation Tighten the hex nut to prevent the hardware from loosening while in the un-stowed configuration. Verify that the antenna rotates freely through its full elevation range of motion. 3.5.3. Removing the CL Shipping/Stow Restraint The CL Shipping/Stow restraint is formed by a red locking bar with adjustable bumpers at each end of the bar.

  • Page 35: Installing The Below Decks Equipment

    Assure that the Gyro Compass output is turned OFF when handling and connecting wiring to the MXP. CAUTION - Allow only an authorized dealer to install or service the your Sea Tel System components. Unauthorized installation or service can be dangerous and may invalidate the warranty.

  • Page 36: Other Bde Connections

    4012 GX Installation Manual Installation 3.7.3.1. Ships Mains Connect the desired power cord from the rear panel of the MXP to power sourse (UPS power recommended). 3.7.3.2. J1 (Modem RX) Connect this RXIF Output to the satellite modem RX Input. 3.7.3.3.

  • Page 37: Setup - Media Xchange Point™ (Mxp)

    Installation 4012 GX Installation Manual 3.9. Setup - Media Xchange Point™ (MXP) Now that you have installed the hardware, you will need to setup, calibrate and commission the antenna. You may also need to load/update the modem option file, which is not part of the scope of this manual, contact the airtime provider NOC for guidance.
  • Page 38 4012 GX Installation Manual Installation This Page Intentionally Left Blank 3-14...

  • Page 39: Configuring A Computer For The Mxp

    Configuring a Computer for the MXP 4012 GX Installation Manual Configuring a Computer for the MXP The first thing you need to do is to configure your computer so that it will display the MXP screens. Follow these instructions to accomplish that.
  • Page 40 4012 GX Installation Manual Configuring a Computer for the MXP From your computer desktop, click the Control Panel button. Click on “View network status and tasks”. Click “Change adapter settings”. Click on “Local Area Connection.”...
  • Page 41 Configuring a Computer for the MXP 4012 GX Installation Manual Click on “Properties”. Click on “Internet Protocol Version 4 (IPv4)”. 10. Click on “Use the following IP address:...
  • Page 42 4012 GX Installation Manual Configuring a Computer for the MXP 11. In the IP Address boxes, enter “10.1.1.102” (This is for the IP address of your computer). NOTE: You could use 101, 102, 103, etc. as long as it is not the same as the address of the MXP, which is “10.1.1.100”...
  • Page 43 17. Open your browser, and enter the URL: “10.1.1.100”. 18. At the log in screen enter the user name (Dealer, SysAdmin, or User). Contact Sea Tel Service for the password. 19. After you log in you will see the System Status...
  • Page 44 4012 GX Installation Manual Configuring a Computer for the MXP This Page Intentionally Left Blank...

  • Page 45: Setup - Ship's Gyro Compass

    Setup – Ship’s Gyro Compass 4012 GX Installation Manual Setup – Ship’s Gyro Compass The Ships Gyro Compass connection provides true heading (heading of the ship relative to true North) input to the system. This allows the ICU to target the antenna to a “true” Azimuth position to acquire any desired satellite. After targeting, this input keeps the antenna stabilized in Azimuth (keeps it pointed at the targeted satellite Azimuth).
  • Page 46 4012 GX Installation Manual Setup – Ship’s Gyro Compass If there is NO Gyro Compass (ie on a large stationary rig which is anchored to the ocean floor) set the GYRO TYPE parameter to “No Gyro” or to “Fixed”. Fixed mode is used when you do not have a gyro compass, but the ship/vessel/rig is stationary at a fixed heading that you can manually enter for satellite targeting.

  • Page 47: Setup - Tracking Receiver - Vsat

    Setup – Tracking Receiver – VSAT 4012 GX Installation Manual Setup – Tracking Receiver – VSAT 6.1. Determining the IF Tracking Frequency (MHz) The IF Tracking frequency parameter is a value entered into the MXP MHZ Sub-Menu. The value itself may be provided by your air-time provider and the MHz value will be entered directly in this sub-menu.
  • Page 48 4012 GX Installation Manual Setup – Tracking Receiver – VSAT This Page Intentionally Left Blank...

  • Page 49: Setup - Home Flag Offset

    Setup – Home Flag Offset 4012 GX Installation Manual Setup – Home Flag Offset Home Flag Offset is used to calibrate the relative azimuth value of the antenna to the bow line of the ship. This assures that the encoder input increments/decrements from this initialization value so that the encoder does not have to be precision aligned. When the antenna is pointed in-line with the bow (parallel to the bow) the “Relative”...

  • Page 50: You Observe "Home" Pointing Is Left Of The Bow-Line

    4012 GX Installation Manual Setup – Home Flag Offset 7.1.1. You Observe “Home” Pointing is LEFT of the Bow-line: In this example, I observe that the Home position is short of the bow line. I estimate that it is about 45 degrees. I target my desired satellite and record the Calculated Azimuth to be 180.5.

  • Page 51: Entering A Small Value As Az Trim

    Setup – Home Flag Offset 4012 GX Installation Manual Access the System Configuration screen Enter new Home Flag value (positive or negative value) Click SAVE 7.1.1. Entering a small value as AZ TRIM If the amount of offset is greater than +/-5 degrees, enter it as Home Flag Offset. If it is within +/-5 degrees, you should enter it in AZ TRIM.
  • Page 52 4012 GX Installation Manual Setup – Home Flag Offset Access the Reflector Configuration screen Use Auto Trim, or enter the small amount of AZ Trim value Click SAVE...

  • Page 53: Setup - Blockage Zones

    Setup – Blockage Zones 4012 GX Installation Manual Setup – Blockage Zones The Blockage Zones function inhibits the antenna from transmitting within certain pre-set zones. To set up the blockage zones go to the System Configuration screen. Notice that identifying an Azimuth blockage zone is as easy as entering the relative bearings of the start and stop points for that blockage.
  • Page 54 4012 GX Installation Manual Setup – Blockage Zones But wait, that’s not all! You can even name each blockage zone...

  • Page 55: Setup - Targeting

    Setup – Targeting 4012 GX Installation Manual Setup – Targeting In this lesson you will learn how to optimize the targeting of the antenna to track on or near a desired satellite (within +/-1 degree. 9.1. AUTO TRIM The Auto Trim function will automatically calculate and set the required Azimuth and Elevation trim offset parameters required to properly calibrate the antennas display to the mechanical angle of the antenna itself, while peaked ON satellite.

  • Page 56: Manually Optimizing Targeting

    4012 GX Installation Manual Setup – Targeting Click SAVE 9.2. Manually Optimizing Targeting First, assure that all of your Ship & Satellite settings in the MXP are correct. Access the Satellite Search screen Target the desired satellite by selecting it from the drop down list.
  • Page 57 Setup – Targeting 4012 GX Installation Manual Access the Reflector Configuration page. 10. Enter the Elevation Trim in the EL field. 11. Enter the Azimuth Trim in the AZ field. 12. Click Save. 13. Re-target the satellite several times to verify that targeting is now driving the antenna to a position that is within +/- 1.0 degrees of where the satellite signal is...
  • Page 58 4012 GX Installation Manual Setup – Targeting This Page Intentionally Left Blank...

  • Page 59: Setup - Satellite Configuration

    The satellite selection will in turn control the hardware on the antenna pedestal to select the correct TX & RX hardware and the correct tracking settings. Sea Tel provides quad-band LNBs as standard on the 4012 GX antennas. Access the Satellite Configuration screen.
  • Page 60 4012 GX Installation Manual Setup – Satellite Configuration Select desired Band from its drop down menu. Assure that reflector is set to “Primary”. Select Cross-Pol LNB (XPol) or Co-Pol LNB (CoPol) as is appropriate for this satellite. Click the Save button. 10-2...

  • Page 61: Quick Start Operation

    Quick Start Operation 4012 GX Installation Manual Quick Start Operation If your system has been set up correctly, and if the ship has not moved since the system was used last, the system should automatically acquire the satellite from a cold (power-up) start. Once the satellite has been acquired, the modem then should achieve lock and you should be able to use the system.
  • Page 62 4012 GX Installation Manual Quick Start Operation Check Latitude, Longitude and Heading. These should be correct, but may be updated if necessary. Access the System Status screen. Find the Latitude, Longitude and Heading displayed values. If they are correct skip to step 12.

  • Page 63: If Satellite Signal Is Found But Network Lock Is Not Achieved

    Quick Start Operation 4012 GX Installation Manual 12. Check for blockage (this is the MOST common cause of not being able to acquire the desired satellite). 13. Verify that the correct satellite is selected. 14. Check cable connections to assure that a cable has not been disconnected.
  • Page 64 4012 GX Installation Manual Quick Start Operation Find the Latitude, Longitude and Heading displayed values. If they are correct skip to step 11. If the Latitude & Longitude values are not correct, access the Communication Interfaces screen and enter the ships Latitude &...

  • Page 65: T Otarget A Different Satellite

    Quick Start Operation 4012 GX Installation Manual 11.4. To Target a different satellite To target a different satellite go to the Satellite Search Auto screen and select the desired satellite from the drop down list. When you make that selection you will see the temporary message: Acquiring Satellite Signal…Please Wait Shortly after that you will see the...
  • Page 66 4012 GX Installation Manual Quick Start Operation This Page Intentionally Left Blank 11-6...

  • Page 67: Optimizing Cross-Pol Isolation

    Optimizing Cross-Pol Isolation 4012 GX Installation Manual Optimizing Cross-Pol Isolation Now that all of the other setup items have been checked and changed as necessary, it is time to contact the NOC to arrange for cross-pol isolation testing and whatever other commissioning the NOC asks for. Read this procedure thoroughly before you are asked to begin.
  • Page 68 4012 GX Installation Manual Optimizing Cross-Pol Isolation Double check with the NOC to assure that cross-pol is still optimized. Conduct any other testing as directed by the NOC (ie P1dB compression). 12-2...

  • Page 69: Gx Technical Specifications

    4012 GX Technical Specifications The specifications of your antenna system are below. For Naval Engineering level information on this subject, please refer to Antenna Installation Guideline – Site Arrangement, document number 130040_A available on the Sea Tel Dealer Support Site. 13.1.

  • Page 70: Smw Quad Band Lnb

    4012 GX Installation Manual 4012 GX Technical Specifications 13.2.3. SMW Quad Band LNB Gain (typical) 54dB Noise Figure 0.8dB Current (typical) 270mA LO Phase Noise (typical) -75 dBc @ 1 KHz -75 dBc @ 10 KHz -105 dBc @ 100 KHz -120 dBc @ >1 MHz LO Stability (over temp) +/-10 or +/-25 KHz...

  • Page 71: Integrated Control Unit (Icu)

    4012 GX Technical Specifications 4012 GX Installation Manual 13.3. Integrated Control Unit (ICU) Connectors AC Power 100-240 VAC, 2A-1A Mini USB GPS Input RJ-11 Motor Control DA-15S Rotary Joint L-Band SMA Connector, L-Band Input RF M&C DE-9S Feed DB-25S Service DE-9S Coax Switch LNB-A...

  • Page 72: Stabilized Antenna Pedestal Assembly

    Roll +/- 20° at 8 second period Pitch 10° Fixed Az Relative 0, 45 and 90° with respect to roll input Mounting Height Sea Tel recommends that you not exceed tangential accelerations of 0.5G (See below chart) 13-4...

  • Page 73: Gps (Integrated On Pedestal)

    4012 GX Technical Specifications 4012 GX Installation Manual Pedestal Mounting Height vs Roll Period @ 25 degrees of Roll amplitude Recomended Reduced System Performance Possible Full System Performance Mechanical Reduced Stabilization Accuracy Failure Full System Performance Full Stabilization Accuracy Roll Period in Seconds 13.6.

  • Page 74: Radome Assembly , 61

    4012 GX Installation Manual 4012 GX Technical Specifications 13.7. Radome Assembly, 61” Type Frequency Tuned Material A sandwich Size Diameter 1.54m (60.6 Inch) Height 1.56m (61.7 Inch) Hatch Size 0.43 x 0.66m (17 x 26 Inch) (min) Weight 115 lbs (Empty) RF attenuation (Ku Band) Less than 0.4dB @ 10.7-14.50GHz dry Wind:...

  • Page 75: Mechanical Conditions

    4012 GX Technical Specifications 4012 GX Installation Manual 13.1.3. Mechanical Conditions Systematic Vibration Amplitude (single peak) 5.0 millimeters Acceleration 2.0 G (20m/s2) Frequency Range 1Hz-150Hz Shock (Transient Vibration) Response Spectrum I - II - III Peak Accel., m/s2 100 - 300 - 500 Duration, ms 11 - 6 - 3 Number of Cycles...

  • Page 76: Mxp Box Rear Panel Connections

    4012 GX Installation Manual 4012 GX Technical Specifications 13.2.2. MXP Box Rear Panel Connections 4 Ethernet Port (RJ-45) 1 Ethernet Port Internal (RJ-45) 1 Power Input 1 SMA Connector (RX from Rotary Joint to Diplexer) 1 F-Connector from Diplexer to Modem RX Port 8 Tri Colored MXP status LEDs Small Form Factor Pluggable USB Devise (Mini B)

  • Page 77: Control Interface

    4012 GX Technical Specifications 4012 GX Installation Manual 13.2.4. Control Interface External AGC Connectors 2 screw terminal connections Input Voltage Level 0-5 VDC Impedance 30K Ohm Control (Logic Sense can be reversed by Low Level (<1.25VDC)= Modem Lock adding 128 to the system type) High Level (>1.25 VDC)= Modem Unlock Switched outputs 4.7K pull up or Pull Down...

  • Page 78: Icu/Pedestal Power Supply

    4012 GX Installation Manual 4012 GX Technical Specifications 13.2.8. ICU/Pedestal Power Supply Voltage 24VDC Wattage 150W Current Capacity 6.5A 13.2.9. BUC Power Supply Voltage 24VDC Wattage 150W Current Capacity 6.5A 13.3. BDE Environmental Conditions Temperature 0 to 40 degrees C Humidity Up to 100% @ 40 degrees C, Non-Condensing 13.4.

  • Page 79: Cables

    Antenna L-Band IF Coax Cables (Customer Furnished) Due to the loss across the length of the RF coaxes at L-Band, Sea Tel recommends the following 50 ohm coax cable types (and their equivalent conductor size) for our standard pedestal installations. Type N male...
  • Page 80 4012 GX Installation Manual 4012 GX Technical Specifications This Page Intentionally Left Blank 13-12...

  • Page 81: Drawings

    DRAWINGS 4012 GX Installation Manual DRAWINGS 14.1. 4012 GX Ku-Band Model Specific Drawings Drawing Title 134725-1_A1 Enclosure Assembly, MXP 14-3 134968-601_A System, 4012GX in 61” Radome 14-7 134639-1_ System Block Diagram, 4012GX, Ku-Band 14-9 134563-1_A Below Decks Kit, 4012GX 14-13 134805-1_B 61”...
  • Page 82 4012 GX Installation Manual DRAWINGS This Page Intentionally Left Blank 14-2...
  • Page 83 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 133373-1 PCB ASS'Y, MXP-2011 1 EA 133729-5 POWER SUPPLY SWITCHING, 75W 1 EA 122660-6 HARNESS, AC ENTRY, 18 IN. CHASSIS 1 EA 126597-17 B3 CABLE ASS'Y, .156 ORG IDC TO PIN TERM (NOT SHOWN) (P/S DC TO J106) 1 EA 135558-1...
  • Page 84 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 6 EA 110941-3 SCREW, JACK, 4-40 X .312 LG 2 EA 120077-112 SCREW, FLAT HD, PHIL, M3 X 4, S.S. 12 EA 120077-116 SCREW, FLAT HD, PHIL, M3 X 6, S.S. 15 EA 119745-116 SCREW, PAN HD, PHIL, M3 x 6, S.S.
  • Page 85 NOTES: UNLESS OTHERWISE SPECIFIED IDENTIFY ASS'Y P/N & S/N PER SEA TEL SPEC. 122930 APPROX. WHERE SHOWN. IDENTITY PCB ASSY P/N & S/N PER SEA TEL SPEC 122930 APPROX WHERE SHOWN. MANUFACTURE PER SEA TEL STANDARD 122298. COSMETIC INSPECTION PER SEA TEL SPEC 127212.
  • Page 86 PART OF ITEM 1 SIZE SCALE: DRAWING NUMBER 134725 2 OF 2 SHEET NUMBER...
  • Page 87 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 134803-1 GENERAL ASS'Y, 4012GX PL C1 AntSys_Crate 1 EA 135006-1 A1 RADOME ASS'Y, GA INSTALL, 61 IN, TX/R PL C1 SN AntSys_Crate 1 EA 132345-1 A1 SSPB, KU, 8W, CODAN MINI BUC, FULL-BA PL C1 I1 SN w/134803-1,1 AntSys_Crate...
  • Page 88 Do Not Copy, Distribute or Disclose Without Prior 134968 Written Approval From Sea Tel. DASH RADOME BASE FRAME AC KIT SYSTEM TOTAL 4012 GX 3rd ANGLE 1 OF 1 Copyright c Sea Tel, Inc 2011 - Unpublished Work FIRST USED: SHEET NUMBER PROJECTION...
  • Page 89 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 134803-1 GENERAL ASS'Y, 4012GX 1 EA 134512-1 ANTENNA ASS'Y, 4012GX, KU 2 EA 136128-2 LNB, SMW, QUAD LO, KU BAND, TYPE N 1 EA 132345-1 A1 SSPB, KU, 8W, CODAN MINI BUC, FULL-BA 1 EA 132956-1 CIRCUIT BREAKER BOX ASS'Y, 6 AMP...
  • Page 90 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 2 EA 119479-10 B1 CABLE ASS'Y, CAT5 JUMPER, 10 FT. 1 EA 119478-5 D CABLE ASS'Y, RJ-45 SERIAL, 60 IN. 1 EA 133287-2 A1 CABLE ASS'Y, USB 2.0, 6FT, A/M TO MIN 1 EA 120643-25 CABLE ASS'Y, RS232, 9-WIRE, STRAIGHT, 1 EA 116700-6...
  • Page 93 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 111115-6 B1 CABLE ASS'Y, F(M)-F(M), 6 FT. 1 EA 111079-6 G1 CABLE ASS'Y, SMA(M)-N(M), 6 FT. 2 EA 119479-10 B1 CABLE ASS'Y, CAT5 JUMPER, 10 FT. 1 EA 119478-5 D CABLE ASS'Y, RJ-45 SERIAL, 60 IN.
  • Page 95 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 134804-1 RADOME TOP FAB, 61 IN, TUNED KA/KU, W 1 EA 129419-1 B3 RADOME BASE ASS'Y, 50 IN, SMOOTH, WHI 8 EA 114580-029 WASHER, FLAT, 1/4, S.S. 4 EA 114586-540 SCREW, HEX HD, 1/4-20 x 1-1/4, S.S.
  • Page 96 ACCESS HATCH (INSIDE)) NOTES: UNLESS OTHERWISE SPECIFIED 1. MANUFACTURE PER SEATEL STANDARD 122298. IDENTIFY PER SEA TEL SPECIFICATION 122930 APPROX WHERE SHOWN GENERAL SURFACE AND APPEARANCE STANDARDS PER 127212, CLASS 2B. DO NOT APPLY ADHESIVE. HARDWARE SHOWN DESIGNER/ENGINEER: DRAWN BY:...
  • Page 98 Purpose. To define the installation procedure for installing strain reliefs in “smooth base” radomes. Scope. This installation procedure applies to fiberglass radomes having Sea Tel’s standard four-hole mounting pattern, and M12 mounting hardware , in the 80-180 cm (34-66 in) nominal size range, typically referred to as “smooth”...
  • Page 99 Procedure, Radome Strain Relief Installation Making the holes PLANNING: Space has been allowed for up to 5 ea. strain reliefs, but, install only as many as needed. (Typically only 2-3 for TX/RX systems). Refer to Fig 2 then plan which hole positions to use. For 76-inch radomes lowest holes may be approx 1.5 inches from inside wall corner with floor (ref drawing 129416).
  • Page 100 Procedure, Radome Strain Relief Installation Measure, mark and drill pilot holes CAUTION: The hole locations cannot be determined accurately from outside of the radome. Using full scale drawing 132234, provided in the strain relief kit, measure mark and drill pilot holes from the inside out, and using only light pressure, use the small drill bit, (~1/8”...
  • Page 101 Procedure, Radome Strain Relief Installation Fig. 5 – Outside view. Rotate General Assembly (G.A.) Once cables have been installed, rotate General Assembly (G.A.), to ensure cables are routed properly and do not interfere with azimuth rotation. Fig. 6 – Inside view. Records.
  • Page 102 Procedure, Radome Strain Relief Installation Strain relief positioning for 80-180 cm (34-66 in) smooth based radomes, (May use Sea Tel drawing 132234 as template.) Document No Page 5 of 6 131226 Rev A Form # 117140-B...
  • Page 103 Procedure, Radome Strain Relief Installation Strain relief positioning for 193 cm (76-inch) radomes. (May use Sea Tel drawing 132234 as template.) Document No Page 6 of 6 131226 Rev A Form # 117140-B...
