- Page 1 Range Cooker Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 3 CE Declarations of Conformity: This appliance has been designed, constructed and marketed in compliance with safety requirements of EEC Directive 2006/95/ EEC (Low voltage) and requirements of EMC Directive 2004/108/EEC. This appliance has been manufactured to the strictest standards and complies with all applicable legislation, including Electrical safety (LVD) and Electromagnetic interference compatibility (EMC).
-
Page 4: User Information
User Information • Read the instructions carefully before using the cooker. • Keep the instructions in a safe place for future reference. • Follow the instructions for first use (page 6). • Always use oven gloves when removing shelves and trays from the cooker. - Page 5 • Pan handles should never stand out beyond the edge of the worktop. This will help ensure children cannot reach them. • Do not use pans with rough bases (e.g. cast iron) as these may scratch the hob surface. • Do not switch on the hob zones without cookware in place.
-
Page 6: Before First Use
Overheating can be caused by incorrect use of an oven or defective components. If an oven switches off due to overheating, wait for the oven to cool down before using it again. If the error continues, contact CDA Customer Care. - Page 7 Hob: 1. Front left dual zone 1.0/2.2kW / 140/210mm 2. Rear left zone 1.2kW / 140mm 3. Centre dual zone 1.1/2.0kW 140x250mm 4. Rear right zone 1.8kW / 180mm 5. Front right zone 1.2kW / 140mm 6. Residual heat indicators Control panel: 7.
- Page 8 How to Use the Hob The ceramic surface of the hob allows fast transmission of heat vertically from the heating elements under the glass to the pans on the hob top. The heat does not spread horizontally, so the hob top remains relatively cool only a few centimetres from the zone in use.
- Page 9 Using the dual zones The dual zones are formed of two separate coils of resistant material. To turn on the dual zone, turn the control knob fully clockwise to position. Residual heat indicators The hob is equipped with residual heat indicators which warn when any of the zones are hot to the touch, both during and after cooking.
- Page 10 Efficient Use of Your Hob The hob is equipped with zones of different sizes, designed to accommodate most shapes and sizes of pan. For best results, only use pans with flat bottoms and choose appropriate zones depending on the sizes of the pans. The most efficient use of the hob is shown below, where the pans and zones are correctly chosen.
- Page 11 Choose pans which are between the sizes recommended in the table above, and with bases that are as non-reflective as possible, e.g. dull and dark. Only pans recommended for use on ceramic hobs should be used. Pans with aluminium bases may leave silver streaks or spots on the hob.
-
Page 12: Using Your Main Oven
Using Your Main Oven Important Cooking function knob To choose the function, turn the cooking function knob clockwise to the required setting. Each of the oven functions uses different elements within the oven to offer you the best choice of cooking every time. These are explained below: Oven Light This function switches on the oven light without using any... - Page 13 For both grill functions please note: • Always grill with the oven door closed. • Put the grill pan as close to the grill as possible. • Do not grill for more than 30 minutes at a time. • Preheat the grill for approximately five minutes with the oven door closed.
- Page 14 Defrost Using the fan only this oven function circulates the air around the oven cavity, speeding up the natural defrost process (1kg takes approximately one hour, depending on the type of food). Fan Oven Using the circular element and the fan with a temperature between 60ºC and Max, this cooking function blows the air into and around the oven cavity.
-
Page 15: Main Oven
Programming the Main Oven Please note: • The semi-automatic and automatic cooking programmes will only work with the main oven. Cooking time indicator • The alert beep will cut off after 2 End of cooking time indicator 3 Minute minder indicator two minutes if it is not switched off 4 Current time indicator 5 Decrease key... - Page 16 • Then touch to select the required duration for the minute minder. When the correct duration shows on the display, either touch or wait for approximately five seconds. The minute minder indicator will remain lit to confirm the minute minder is on. •...
-
Page 17: Automatic Cooking
Please note: At the end of the cooking programme, remember to turn off the oven manually. Automatic cooking The main oven can be set to switch on and off automatically at preset times up to a maximum of 10 hours. To set an automatic cooking programme, follow the steps for setting a semi-automatic programme above, and then: •... - Page 18 Using Your Second Oven Control Knob Important: The control knob does not rotate through a full 360°. Rotate it clockwise from the “Off” position to turn the oven on, then rotate it anticlockwise back to the “Off” position to turn the oven off. Do not try to force the knob past the position.
- Page 19 Browning Oven Using only the top oven element pre-set at 250°C, this uses convection heat for browning and crisping. Ideal for cauliflower or macaroni cheese. Grill This function radiates the heat from the grill element. The temperature is pre-set to maximum , for efficient grilling.
-
Page 20: Cleaning The Cooker
Cleaning The Cooker IMPORTANT: Always disconnect the appliance from the power supply before undertaking any cleaning or maintenance. You should always allow the cooker to cool fully after use before undertaking any cleaning or maintenance. • Steam cleaners must not be used when cleaning this appliance •... -
Page 21: Cleaning The Hob
Over time with use, the stainless steel surface may discolour; this is normal and does not constitute a fault with this appliance. Proprietary stainless steel cleaners are available. Cleaning the Hob You should use a non-abrasive cleaner to clean the hob top. Any abrasive cleaner (including Cif) will scratch the surface and could erase the markings. -
Page 22: Cleaning The Oven
Cleaning The Oven Interiors To clean the oven interior, suitable proprietary chemical cleaners may be used after first consulting with the manufacturer’s recommendations and testing a small sample on the oven cavity. fig. 7 Do not use metal scrapers or harsh cleaners on the oven door glass. -
Page 23: Removing The Oven Doors
Removing The Oven Doors The oven door can easily be removed as follows: fig.10 • Open the door to the full extent (fig. 10). • Open the lever A completely on the left and right hinge (fig. 11). • Hold the door as shown in fig. 14. fig.11 •... - Page 24 Changing The Oven Lights 1. Disconnect the electrical power supply (for example, by switching off the main isolator switch). 2. Unscrew the light cover. 3. Fit a new bulb. 4. Refit the cover. Note: Use only bulbs designed to resist up to 300°C with the following characteristics: 230 V, type E14 and same power of the replaced bulb (check watt power as stamped on the bulb itself).
-
Page 25: Installation
Installation The manufacturer will not be held responsible for any damage to property or injury to persons/animals resulting from incorrect installation of this appliance. We recommend you seek the help of another individual when installing this appliance to prevent damage or injury. Installation requirements This range cooker is designed to be installed flush with adjacent worktops... - Page 26 If Fitting a Cooker Hood Above the Range Cooker: If a cooker hood is to be installed above the range cooker, the height of the hood above the hob must be at least 650mm. If the instructions supplied with the hood dictate that the hood must be installed at a height greater than 650mm, then that height is the minimum required.
- Page 27 Anti-tilt bracket/chain This appliance is supplied fitted with safety chains and wall mounted brackets to prevent it tilting forwards. These should be fitted as part of the installation. You must ensure that the fixings are suitable for the wall type. Those included may not be suitable in all situations.
-
Page 28: Mains Electricity Connection
Mains Electricity Connection Warning! This appliance must be earthed To connect this appliance to a UK standard mains supply, connect the bridging links between 1-2-3 for the live feed and 4-5 for the neutral feed We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. - Page 29 Release the two locks located at either side of the connector cover at the rear of the appliance. Feed the mains lead through the cable clamp to prevent accidental disconnection. Tighten the cable clamp securely and close the connector cover. Please note: •...
- Page 31 E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice.
- Page 32 Please contact our Customer Care Department for Service on the details below Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu...
