- Page 1 Multifunction Oven Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu...
-
Page 2: Appliance Information
The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance. -
Page 3: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 4 • Do not touch the appliance with wet or damp hands (or feet). • Do not use the appliance whilst in barefoot. • If you should decide not to use this appliance any longer (or decide to substitute another model), before disposing of it, it is recommended that it be made inoperative in an appropriate manner in accordance to health and environmental protection regulations, ensuring in particular that all potentially hazardous parts be made harmless, especially in relation to...
- Page 5 • FIRST USE OF THE OVEN - it is advised to follow these instructions: – Furnish the interior of the oven as described in the chapter “CLEANING AND MAINTENANCE”. – Switch on the empty oven on max to eliminate grease from the heating elements.
-
Page 6: Control Panel
Control Panel Fig. 1 Controls Description 1. Oven thermostat knob 2. Oven switch knob 3. Clock and timer with “Touch-Control” keys Warning Lights: 4. Power on indicator lamp 5. Oven thermostat indicator light Please Note: This appliance incorporates a safety cooling fan which you will hear operating whenever the oven or grill are in use. -
Page 7: Multifunction Oven
Multifunction Oven General Features As its name indicates, this is an oven that presents particular features from an operational point of view. In fact, it is possible to use 7 different programmes to satisfy every cooking need. The 7 positions, thermostatically controlled, are obtained by 4 heating elements which are: –... -
Page 8: How To Use The Oven
How to Use the Oven WARNING: The door is hot, use the handle. ATTENTION - MOST IMPORTANT Pay special attention not to touch the hot heating element inside the oven cavity. Thermostat Knob (Fig. 2) This only sets the cooking temperature and does not switch the oven on. -
Page 9: Traditional Grilling
Traditional Grilling The infrared grill element comes on. The heat is dispersed by radiation. Use with the oven door closed. The temperature can be regulated via the thermostat knob to between 50 °C and 225 °C. For cooking hints, see the chapter “USE OF THE GRILL”. Recommended for: Intense grilling, browning, cooking au gratin and toasting etc. - Page 10 Ventilated Grill Cooking The infrared grill element and the fan come on. The heat is dispersed mainly by radiation and the fan then distributes it all over the oven. Use with the oven door closed. The temperature can be regulated via the thermostat knob to between 50 °C and 225 °C.
-
Page 11: Cooking Advice
Cooking Advice Sterilization Sterilization of foods to be conserved, in full and hermetically sealed jars, is done in the following way: a. Set the switch to position b. Set the thermostat knob to position 185 °C and preheat the oven. c. - Page 12 Roasting To obtain classical roasting, it is necessary to remember: – that it is advisable to maintain a temperature between 180 °C and 200 °C. – that the cooking time depends on the quantity and the type of foods. Use of the Grill –...
-
Page 13: Clock And Timer With "Touch-Control" Keys
Clock and Timer with “Touch-Control” Keys Touched simultaneously (for more than 2 seconds): – setting the clock; – setting the timer volume (by touching once, along with the “ ” key); – to cancel automatic cooking at any time. Function selection (touched for more than 2 seconds): –... -
Page 14: Setting The Clock
“Touch-Control” Keys The “touch-control” keys should be operated by the fingers (just by touching the key). When using touch controls it is best to use the ball of your finger rather than the tip. The keys are automatically deactivated: – 8 seconds after the last selection; the deactivation is indicated by an acoustic signal (“beep”). To reactivate just touch the “... -
Page 15: Automatic Cooking
Automatic Cooking Use automatic cooking to automatically turn the oven on, cook, and then turn the oven off. 1. Check the clock shows the correct time. 2. Select the function and temperature (function and temperature knobs). The oven will come on. 3. -
Page 16: Do's And Do Not's
Do’s and do not’s – Do always grill with the oven door closed. – Do read the user instructions carefully before using the oven for first time. – Do allow the oven to heat as indicated in the specific sections, before using for the first time, in order to expel any smell from the new oven insulation, without the introduction of food. -
Page 17: Care And Maintenance
Care and Maintenance It is advisable to clean when the appliance is cold and especially for cleaning the IMPORTANT: enamelled parts. Before any operation Avoid leaving alkaline or acidic substances (lemon juice, vinegar, etc.) on the of cleaning and surfaces. maintenance Avoid using cleaning products with a chlorine or acidic base. - Page 18 Stainless Steel, Aluminium, Painted Parts and Silk-screen CAUTION: Printed Surfaces Do not use abrasive substances or non- Clean using an appropriate product. Always dry thoroughly. neutral detergents as Stainless steel surfaces: can be cleaned with an appropriate stainless steel cleaner. IMPORTANT: these parts must be cleaned very carefully to avoid scratching and these will irreparably damage the surface.
- Page 19 Assembling and Dismantling of the Side Runner Frames – Assemble the wire racks to the oven walls using the 2 screws (Fig. 5). – Slide into the guides, the shelf and the tray (Fig. 6). The rack must be fitted so that the safety notch, which stops it sliding out, faces the inside of the oven;...
- Page 20 Replacing the Halogen Oven Lights WARNING: Ensure the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. - Allow the oven cavity and the heating elements to cool down; - Switch off the electrical supply; - Remove the protective cover C (fig.
-
Page 21: Oven Door
Oven Door Removing and Replacing the Inner Door Glass Pane for Cleaning If you wish to clean the inner glass of the door, make sure you follow the precautions and instructions very carefully. Replacing the glass pane and the door incorrectly may result in damage to the oven and may void your warranty. IMPORTANT! - Take care, the oven door is heavy. -
Page 22: Removing The Oven Door
Removing the Oven Door The oven door can easily be removed as follows: - Open the door to the full extent (fig. 8a). - Open the lever A completely on the left and right hinges (fig. 8b). - Hold the door as shown in fig. 8. - Gently close the door (fig. - Page 23 Removing the Inner Pane of Glass The oven door is fitted with no. 2 panes: - no. 1 outside; - no. 1 inner. To clean all panes on both sides it is necessary to remove the inner pane as follows: Remove the Inner Glass Retainer 1.
- Page 24 Remove the Inner Glass Pane Lift and remove the inner pane slightly, as shown in the figure 10. Fig. 10...
- Page 25 After Cleaning, Replace the Inner Glass Pane When replacing the inner glass pane, make sure that: - you replace the pane correctly, as shown. The pane must be in the position described below in order to fit into the door and to ensure that the oven operates safely and correctly - you take extra care not to bump the edges of the glass against any object or surface - you do not force the pane into place.
- Page 26 Replace the Glass Retainer 1. Position the glass retainer, as shown in the figure 12. It should sit on the bottom edge of the outer glass. Check that the clamps M are not deformed or damaged. 2. Gently push the glass retainer back into place. You should be able to hear the tabs on both sides click as they lock the glass retainer in.
- Page 27 Refit the Door 1. Hold the door firmly (fig. 13). 2. Insert the hinge tongues into the slots, making sure that the groove drops into place as shown in the figure 14. 3. Open the door to its full extent. 4.
-
Page 28: Advice For The Installer
ADVICE FOR THE INSTALLER Important Appliance installation and maintenance must only be carried out by QUALIFIED TECHNICIANS and in compliance with the local safety standards. • Failure to observe this rule will invalidate the warranty. • A lways disconnect the appliance from the electrical supply before carrying out any maintenance operations or repairs. • The walls surrounding the oven must be made of heat-resistant material. • Taking care NOT to lift the oven by the door handle. The oven can be fitted in standard units, width 90 cm and depth 60 cm. Installation requires a compartment as illustrated in figures 16 and 17. - Page 29 Fig. 16 Fig. 17...
-
Page 30: Fixing The Oven
Fixing the Oven Introduce the oven into the furniture opening and fix it with 4 screws (not supplied) as figure 18. It is essential that the oven rests on a surface which will support its weight, as the screw fixing is only complementary. Adjust the hinges of furniture doors adjacent to the oven to allow a 4-5 mm gap between the furniture door and the oven frame. - Page 31 IMPORTANT: To avoid damage to the lower trim please note the following instructions. The lower trim is designed to allow for good air circulation and the correct opening of the oven door. To ensure the trim is not damaged due to the appliance being placed on the floor, the appliance should be suitably supported as in below illustrations.
-
Page 32: Mains Electricity Connection
Mains Electricity Connection Incorrect installation may be dangerous and the manufacturer can not be held responsible. Warning! This appliance must be earthed The manufacturer declines all responsibility for any problem caused by failure to observe this rule. THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSE SPUR OUTLET AND PROTECTED BY A SUITABLE FUSE. - Page 33 Connection of the Power Supply Cable Unhook the terminal board cover by inserting a screwdriver into the two hooks A (fig. 21). Open the cable gland by unscrewing screw F (fig. 22), unscrew the terminal screws and remove the cable. The new supply cable, of suitable type and section, is connected to the terminal board following the diagram of fig.
-
Page 34: Appliance Servicing
Appliance Servicing CDA provide a quality and effective after-sales service to cover all your servicing needs. Please attach your receipt to this page for safekeeping. Please help us to help you by having the following information available when booking a service-call: 1. - Page 36 Please contact our Customer Care Department, or for Service on the details below. Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu...
