Oven
Manual for Installation, Use and Maintenance
Model:
SVA 100 PP
Customer Care Department • The
Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SVA 100 PP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CDA SVA 100 PP

Summary of Contents for CDA SVA 100 PP

  • Page 1 Manual for Installation, Use and Maintenance Model: SVA 100 PP Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...

  • Page 2: Appliance Information

    The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance.

  • Page 3: Before Using For The First Time

    – Switch the empty oven ON at maximum temperature for about two hours to eliminate traces of grease and smell from the components. – Let the oven cool down, switch off the electrical supply, then clean the inside of the oven with a cloth soaked in water and neutral detergent and dry thoroughly.
  • Page 4 – Always use oven gloves when removing the shelves and food trays from the oven whilst hot. – Clean the oven regularly and do not allow fat or oils to build up in the oven base or trays. Remove spillages as soon as they occur.

  • Page 5: Control Panel

    Please Note: This appliance incorporates a safety cooling fan which you will hear operating whenever the oven or grill are in use. The cooling fan may also operate when the oven is switched off. This fan is to reduce the external temperature of the appliance and cool the internal components.

  • Page 6: General Features

    – Circular element 2200 W Note: Upon first use, it is advisable to operate the oven at the maximum temperature for 60 minutes in the position possible traces of grease on the heating elements. Repeat the operation for another 15 minutes with the grill element on as explained in the chapters TRADITIONAL GRILLING and USE OF THE GRILL.

  • Page 7: How To Use The Oven

    50 °C to 225 °C). The thermostat indicator light will illuminate when the oven is switched on and turns off when the oven reaches the correct temperature. The light will cycle on and off during cooking in line with the oven temperature.

  • Page 8: Traditional Grilling

    The oven light will operate on all selected functions. Defrosting Frozen Foods Only the oven fan comes on. Use with the thermostat knob set to “ ” - other positions have no effect. The food is thawed by ventilation without heating.

  • Page 9: Cooking Advice

    Set the switch to position and the thermostat knob to position 150 °C. Bread becomes fragrant again if wet with a few drops of water and put into the oven for about 10 minutes at the highest temperature. Simultaneous Cooking of Different Foods With the function selector in position at the same time.

  • Page 10: Clock And Timer With "Touch-Control" Keys

    - Oven set for manual cooking “ ” ” and AUTO AUTO flashing - Automatic cooking being set “ ” and AUTO steady illumination - Oven set for automatic cooking, cooking taking place. “ ” key); ” Fig. 4...

  • Page 11: Setting The Clock

    ” symbol is steady illuminated. Using the Timer You can use the timer at any time, even when the oven is not in use. The timer does not turn the oven off. The timer can be set for up to 23 hours and 59 minutes.

  • Page 12: Automatic Cooking

    The oven will switch off but is now set for automatic cooking. If you are already at home to turn the oven on and only want the oven to turn off automatically, start cooking as normal, then follow step 4 or step 5 to set a time to stop the oven.

  • Page 13: Do's And Do Not's

    – Do read the user instructions carefully before using the oven for first time. – Do allow the oven to heat for one and a half hours, before using for the first time, in order to expel any smell from the new oven insulation, without the introduction of food.

  • Page 14: Care And Maintenance

    Inside of Oven The oven should always be cleaned after use when it has cooled down. The cavity should be cleaned using a mild detergent solution and warm water. Suitable proprietary chemical cleaners may be used after first consulting with the manufacturers recommendations and testing a small sample of the oven cavity.
  • Page 15 CAUTION: Do not store flammable material in the oven. CAUTION: Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
  • Page 16 WARNING: Ensure the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. – Let the oven cavity and the heating elements to cool down; – Switch off the electrical supply; – Remove the protective cover C (fig. 5);...
  • Page 17 Assembling and Dismantling of the Side Runner Frames – Assemble the wire racks to the oven walls using the 2 screws (Fig. 6). – Slide the tray and rack into the runners (Fig. 7). The rack must be fitted so that the safety catch, which stops it sliding out, faces the inside of the oven.

  • Page 18: Removing The Oven Door

    Oven Door Removing the Oven Door The oven door can easily be removed as follows: – Open the door to the full extent (fig. 8a). – Open the lever A completely on the left and right hinges (fig. 8b). – Hold the door as shown in fig. 8.
  • Page 19 Removing the Inner Pane of Glass The oven door has two panes. To clean these, you need to remove the inner pane. 1. Lock the door open: –...
  • Page 20 – Reassemble the seal G in the correct way (fig. 17) by hooking the no. 3 fixing hooks in the proper holes (fig. 18). – Unlock the oven door by opening it completely and closing the lever A on the left and right hinges (Fig. 19).

  • Page 21: Advice For The Installer

    • Always disconnect the appliance from the electrical supply before carrying out any maintenance operations or repairs. • The walls surrounding the oven must be made of heat-resistant material. • Taking care NOT to lift the oven by the door handle.
  • Page 22 The oven can be fitted in standard units, width and depth 60 cm. Installation requires a compartment as illustrated in figures 20 and 21. On the lover side, the oven must lay on supports standing the oven weight. Fig. 20 Fig. 21...
  • Page 23 To ensure internal ventilation, aeration channels must be provided as illustrated in the figures 22 and 23. 50 mm 30 mm Fig. 22 Fig. 23...

  • Page 24: Fixing The Oven

    Fixing the Oven Introduce the oven into the furniture opening and fix it with screws (not supplied) as figure 24. It is essential that the oven rests on a surface which will support its weight, as the screw fixing is only complementary.
  • Page 25 – To avoid damage to the lower trim please note the following instructions. – The lower trim is designed to allow for good air circulation and the correct opening of the oven door. – To ensure the trim is not damaged due to the appliance being placed on the floor, the appliance should be suitably supported as in below illustrations.

  • Page 26: Mains Electricity Connection

    Mains Electricity Connection Incorrect installation may be dangerous and the manufacturer can not be held responsible. Warning! This appliance must be earthed The manufacturer declines all responsibility for any problem caused by failure to observe this rule. THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSE SPUR OUTLET AND PROTECTED BY A 13A FUSE.
  • Page 27 Connection of the Power Supply Cable Unhook the terminal board cover by inserting a screwdriver into the two hooks “A” (fig. 27). Open the cable gland by unscrewing screw “F” (fig. 28), unscrew the terminal screws and remove the cable. The new supply cable, of suitable type and section, is connected to the terminal board following the diagram of fig.

  • Page 28: Appliance Servicing

    Appliance Servicing CDA provide a quality and effective after-sales service to cover all your servicing needs. Please attach your receipt to this page for safekeeping. Please help us to help you by having the following information available when booking a service-call: 1.
  • Page 29 After the first year and within five years, the parts will be supplied free of charge provided that the repair is carried out by an agent authorised by CDA and the labour will be charged at the commercial rate applicable at the time of repair.
  • Page 32 Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
