Page 1: Installation Tips
KD6 Z-SERIES DOME Buy Ultrak Cameras & Parts @ TLS Electronics INSTALLATION TIPS MAINTENANCE Manual Number 518854-2960 Ultrak ® 4465 Coonpath Road Carroll, OH 43112 (800) 443-6680•(740) 756-9222•FAX (740) 756-4237 518854-2960-D KDMU040013 7/20/01... - Page 2 WARNING THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT, THIS PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER MAY BE REQUIRED TO TAKE ADEQUATE MEASURES. WARNING TO REDUCE A RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE UNLESS ENCLOSED IN A WATERPROOF HOUSING.
- Page 3 PERMISSION FROM ULTRAK , INCORPORATED. THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL RESPECTS. HOWEVER, ULTRAK, INCORPORATED CANNOT ASSUME RESPONSIBILITY FOR ANY CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS OR NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE SUCH CHANGES.
- Page 4 518854-2960-D KDMU040013 7/20/01...
-
Page 5: Table Of Contents
TABLE OF CONTENTS Page DESCRIPTION..........................1 RECOMMENDED INSTALLATION TOOLS & CABLING............1 EQUIPMENT HANDLING ......................1 FIELD WIRING..........................2 KD6 Z-SERIES DOME SETUP....................3 TROUBLESHOOTING PROCEDURES ..................4 REMOVING THE BOTTOM DOME FROM THE TOP DOME.............5 MAINTENANCE ...........................5 REPLACEMENT PARTS ......................6 SPECIFICATIONS ........................17 518854-2960-D KDMU040013 7/20/01... - Page 6 518854-2960-D KDMU040013 7/20/01...
-
Page 7: Description
Diamond series control system. The KD6 Z-Series Dome consists of a top dome, pan and tilt unit, and a bottom dome. The KD6 Z-Series Dome can be mounted indoor on a ceiling pendant or wall pendant mounting bracket, in a dropped ceiling or a hard ceiling. -
Page 8: Field Wiring
FIELD WIRING The field wiring for a KD6 Z-Series Dome is terminated at the interface board. Refer to the installation guide provided for wiring connections. 1. Power - Each KD6 Z-Series Dome requires a separate power source. A 12Vdc or 24Vac interface board may be provided with the dome. -
Page 9: Kd6 Z-Series Dome Setup
The address is defined using a JPD series controller. The serial number of the KD6 Z-Series Dome is required to set the address. The serial number is located on the mounting bracket of the pan and tilt mechanism. -
Page 10: Troubleshooting Procedures
1-800-443-6681 (toll free USA) or 740-756-9222. Any equipment returned to Ultrak for warranty or service repair must have an Authorization to Return Material Number (ARM#) for its repair. The ARM# must be clearly marked on all return packages. -
Page 11: Removing The Bottom Dome From The Top Dome
Problem Possible Solution g. Scan drifts in one Joystick on JPD series controller out of adjustment. Recenter joystick direction (up, down, left, and verify coordinate settings. right). OPT> 3> 3 View coordinate display of joystick on LCD display. OPT> 3> 2 Display shows: P-### T-### Z-### ### should be 128 ±... -
Page 12: Replacement Parts
REPLACEMENT PARTS The following drawings and partial material lists are provided to assist in installing and servicing the KD6 Z-Series Dome. All servicing must be performed by qualified technicians who have attended an Ultrak training course. REPLACING THE CAMERA Perform the following procedures to replace the camera. - Page 13 Pendant Ceiling Mount Part Number 518855-1030 Item Description Sheet, 14 gauge (.0747) Thk x 4” x 9” Lg. CRS Tube, 1” Dia. X .065 Wall x 6” Lg. CS Plate, 3/16 Thk x 2.875 Dia. CS 518854-2960-D KDMU040013 7/20/01...
- Page 14 Wall Pendant Mount Part Number 518856-1030 Item Description Sheet, 14 gauge (.0747) Thk x 4” x 9” Lg. CRS Tube, 1” Dia. X .065 Wall x 6.75” Lg. CS Plate, 3/16 Thk x 2.875 Dia. CS 518854-2960-D KDMU040013 7/20/01...
- Page 15 KD6 Z-Series Dome Indoor Pendant Top Dome 518878-1040 (12vdc) Replacement Parts Item Part Number Description 518865-1130 Mounting Bracket Ring 518866-1120 Spacer Ring 518867-1130 8” Upper Dome 518868-1120 Interface Cable, 4-foot 518852-1020 Assembly, 12V Dome Interface Board 873020-1000 Nut, Regular Hex 7mm SST, M4...
- Page 16 KD6 Z-Series Dome Indoor Pendant Bottom Dome Part Number Description 518861-1130 Clear Bottom Dome 518861-2130 Smoked Bottom Dome 518854-2960-D KDMU040013 7/20/01...
- Page 17 KD6 Z-Series Dome Indoor Dropped Ceiling Top Can Part Number 518921-1040 Replacement Parts Item Part Number Description 518461-2140 7” Back Can 518916-1130 Mounting Bracket, Scan 518868-1120 Interface Cable 517082-8130 Drop Ceiling Mount 871024-1240 Screw, Pan Phil. Hd., SST, M4 x 24mm Lg.
- Page 18 KD6 Z-Series Dome Indoor Hard Ceiling Top Can Part Number 518940-1040 Replacement Parts Item Part Number Description 518461-3140 7” Back Can 518916-1130 Mounting Bracket, Scan 518868-1120 Interface Cable 518854-2960-D KDMU040013 7/20/01...
- Page 19 Hard Ceiling and Dropped Ceiling Bottom Domes Part Number Description 518630-1000 Bottom Dome, Smoked with Black Trim Ring 518630-2000 Bottom Dome, Smoked with White Trim Ring 518630-4000 Bottom Dome, Clear with Black Trim Ring 518630-5000 Bottom Dome, Clear with White Trim Ring 518854-2960-D KDMU040013 7/20/01...
- Page 20 Outdoor Wall Mount Part Number 518999-1040 Item Part Number Description 519018-1140 Mount 519003-1120 Seal 518854-2960-D KDMU040013 7/20/01...
- Page 21 Weather Dome 518946-1040 Item Part Number Description 700480-3130 Top Dome, Black 518634-1120 Seal, Dome Cap 515676-1130 Slip Ring Support 515991-2120 Dome Cap 517230-4140 White Weather Shroud 865701-0406 Screw, Phil. Pan. Hd. #4-40 x 3/16” 869068-0126 Washer, Retainer for #4-40 Screw 517024-1120 Safety Cable 861807-0011...
- Page 22 Weather Dome Bottoms Part Number Description 518087-1030 Bottom Dome, Smoked 518087-3030 Bottom Dome, Clear 7” Pan and Tilt Assembly (Scan) 518854-1040 (includes camera and lens) 843216-0900 Camera, Color 9 Vdc, ¼” Format NTSC Hz w/4-64mm Zoom Lens with 2X Digital Magnifier 843216-0901 Camera, Color 9Vdc, ¼”...
-
Page 23: Specifications
SPECIFICATIONS Power Requirements: 12Vdc – 15Vdc @ 1.1A, non-isolated 24Vac ±10% @ 0.75A, non-isolated Weather Dome Heater 24Vac @ 2.1A Pan and Tilt Angular Travel: Horizontal – 360° continuous slip ring design Vertical – 0° horizontal to 90° down Pan and Tilt Speed: Pan –...
