- Page 1 KC2200CN 1/3" CCD DSP COLOR CAMERA INSTALLATION INSTRUCTIONS Ultrak Worldwide Support Center: 1301 Waters Ridge Drive Lewisville, TX 75057 (800) 796-2288 (972) 353-6400 FAX (972) 353-6670 ®...
- Page 2 (972) 353-6400 ALL RIGHTS RESERVED. NO PART OF THIS PUBLICATION MAY BE REPRODUCED BY ANY MEANS WITHOUT WRITTEN PERMISSION FROM ULTRAK. THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL RESPECTS. HOWEVER, ULTRAK CANNOT ASSUME RESPONSIBILITY FOR ANY CONSEQUENCES RESULTING FROM THE USE THEREOF.
-
Page 3: Explanation Of Graphical Symbols
USERS OF THE PRODUCT ARE RESPONSIBLE FOR CHECKING AND COMPLYING WITH ALL FEDERAL, STATE, AND LOCAL LAWS STATUTES CONCERNING MONITORING RECORDING OF VIDEO AND AUDIO SIGNALS. ULTRAK SHALL NOT BE HELD RESPONSIBLE FOR THE USE OF THIS PRODUCT IN VIOLATION OF CURRENT LAWS AND STATUTES. -
Page 4: Important Safeguards
IMPORTANT SAFEGUARDS READ INSTRUCTIONS -- All the safety and operating HEED WARNINGS -- Follow all instructions marked on the instructions should be read before the appliance is operated. video monitor or equipment. RETAIN INSTRUCTIONS -- The safety and operating LIGHTNING -- For added protection for video monitor or instructions should be retained for future reference. -
Page 5: Fcc Compliance Statement
FCC COMPLIANCE STATEMENT INFORMATION TO THE USER : THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS B DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE IN A RESIDENTIAL INSTALLATION. - Page 6 THIS PAGE INTENTIONALLY LEFT BLANK.
-
Page 7: Table Of Contents
TABLE OF CONTENTS SECTION 1 ABOUT THE KC2200CN CAMERA......1 PURPOSE............1 FEATURES ............1 SECTION 2 CAMERA CONTROLS AND CONNECTIONS ..3 CAMERA BACK ..........3 CAMERA FRONT ..........4 CAMERA SIDE........... 4 SECTION 3 CAMERA INSTALLATION AND ADJUSTMENT ..5 CONTENTS OF PACKAGE ....... - Page 8 THIS PAGE INTENTIONALLY LEFT BLANK. viii...
-
Page 9: About The Kc2200Cn Camera
ABOUT THE KC2200CN CCD DSP COLOR CAMERA PURPOSE This manual describes how to set up and operate the KC2200CN camera. FEATURES The KC2200CN DSP color security camera provides a low-cost solution to closed-circuit television (CCTV) and security surveillance applications. The features of this camera include: •... - Page 10 THIS PAGE INTENTIONALLY LEFT BLANK.
-
Page 11: Camera Controls And Connections
SECTION 2 CAMERA CONTROLS AND CONNECTIONS BACK VIEW FRONT VIEW IRIS LEVEL E.I. AUTO IRIS VIDEO MONITOR INTERPHONE SIDE VIEW CAMERA BACK 1. EI Switch – This switch turns on and off the electronic iris function. 2. Auto Iris Switch – This switch allows the user to select between video- and DC-type auto-iris lenses. -
Page 12: Camera Front
Motion sensors, alarm contacts and two-way intercom boxes can also be connected to this port. To purchase optional accessories, contact your authorized Ultrak dealer/distributor. 5. Iris Level Control – This control adjusts the picture for optimum quality when used with a dc iris lens. -
Page 13: Camera Installation And Adjustment
SECTION 3 CAMERA INSTALLATION AND ADJUSTMENT CONTENTS OF PACKAGE Installation of the KC2200CN camera must be performed by qualified service personnel in accordance with all local and national electrical and mechanical codes. Carefully remove the color camera and its accessories from the carton and verify that they were not damaged in shipment. - Page 14 IMPORTANT: The maximum recommended load of the mounting bracket is 11 lbs (5Kg). The KC2200CN observation camera has a ¼"-20 UNC mounting hole located at the top and the bottom of the camera housing to allow for top or bottom mounting. Mount the camera on the stand by threading the mounting bolt into either mounting hole on the camera.
- Page 15 If the provided camera cable is not long enough, do not substitute a telephone cable as it could damage the camera and/or the monitor. Contact your authorized Ultrak dealer/ distributor to purchase longer cables. continued on next page...
-
Page 16: Manual Iris Lens Adjustment
BASIC INSTALLATION, continued Plug the cable into the connector port labeled MONITOR located on the back of the camera. Plug the other end of the cable into the corresponding camera connector port on the back of the observation monitor. Plug the monitor’s power cable into a suitable wall outlet. -
Page 17: Video-Type Auto-Iris Lens Installation And Adjustment
VIDEO-TYPE AUTO-IRIS LENS INSTALLATION AND ADJUSTMENT The KC2200CN camera supports video-type auto-iris lenses to adjust for changing light levels. Perform the following steps to install and adjust a video-type auto-iris lens. Thread the video-type auto-iris lens onto the lens mount on the front of the camera. - Page 18 AUTO-IRIS LENS INSTALLATION AND ADJUSTMENT, continued Apply power to the KC2200CN camera. Adjust the focus ring on the lens for an optimum picture. If the picture is not visible, set the lens for proper exposure by adjusting the ALC (automatic level control) and Level on the lens.
-
Page 19: Dc-Type Auto-Iris Lens Installation And Adjustment
Thread the dc iris lens onto the lens mount on the front of the camera. If using an Ultrak lens, skip to step three. If using a non-Ultrak lens, use the manufacturer’s instructions to solder the connector that comes supplied with the camera to the lens control wires. -
Page 20: Backfocus Adjustment
Make sure that the EI switch located on the back of the camera is set to OFF. Apply power to the KC2200CN camera. Adjust the dc-type auto-iris lens for an optimum picture using the IRIS LEVEL control on the back of the camera. -
Page 21: Zoom Lens Backfocus Adjustment
BACKFOCUS ADJUSTMENT, continued 4. When the iris is open to the widest point, readjust the focus for a clear picture. If a clear picture is not visible, set the focus ring to midrange. 5. Loosen the backfocus lock screw. 6. Adjust the backfocus ring for a clear picture. 7. - Page 22 ZOOM LENS BACKFOCUS ADJUSTMENT, continued Loosen the backfocus lock screw. Adjust the backfocus ring for the clearest picture. Adjust the zoom on the lens to the far telephoto position. Adjust the backfocus ring for the clearest picture. Adjust the zoom on the lens back to the widest picture.
-
Page 23: Troubleshooting
SECTION 4 TROUBLESHOOTING If problems occur, verify the installation of the camera with the instructions in this manual and with other operating equipment. Isolate the problem to the specific piece of equipment in the system and refer to the equipment manual for further information. PROBLEM CHECK Make sure the system is plugged in. - Page 24 THIS PAGE INTENTIONALLY LEFT BLANK.
-
Page 25: Preventive Maintenance
SECTION 5 PREVENTIVE MAINTENANCE Following the preventive maintenance schedule allows detection and correction of minor faults before they become serious and cause equipment failure. Every three months, perform the following: Inspect all connecting cables for deterioration or other damage. Clean components with a clean damp cloth. Verify that all the mounting hardware is secure. - Page 26 THIS PAGE INTENTIONALLY LEFT BLANK.
-
Page 27: Specifications
SECTION 6 SPECIFICATIONS Image Sensor: 1/3" color CCD Video Format: NTSC Horizontal Frequency: 15.734 KHz Vertical Frequency: 59.94 Hz Resolution: >330 TV lines Signal/Noise Ratio: 46dB (AGC off) Minimum Illumination: 2.0 Lux (F1.2) Video Output: 1.0 Vp-p, 75 Ohms, unbalanced Synchronization: External/observation monitor Electronic Shutter:... - Page 28 Made in Korea Printed in Korea REV. 02/00...
