- Page 2 Bel Canto Design Limited. Bel Canto Design Limited assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. Trademarks used in this publication: Bel Canto and the Bel Canto logo are registered trademarks of Bel Canto Design Limited.
- Page 3 Explanation of symbols used in this manual or on the TO COMPLETELY DISCONNECT THIS APPARATUS rear/underside of the apparatus: FROM THE AC MAINS, DISCONNECT THE POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE. The Lightning Flash with arrowhead symbol within an equilateral triangle is intended to THE MAINS PLUG OF THE POWER SUPPLY CORD alert the user to the presence of uninsulated SHALL REMAIN READILY ACCESSIBLE.
- Page 4 Fit a new 10 amp BS1362 approved fuse into the carrier GROUNDED. and push the carrier back into the plug. Bel Canto Design Ltd. declare that this product is in conformance The conformity of the designated product with the provisions of with the Low Voltage Directive 73/23/EEC and Electromagnetic...
- Page 5 Bel Canto products are automatically covered by a 90 day factory warranty that covers all internal parts and labor. Register online (http://www.belcantodesign.com/Belcanto_Warranty.html) within 30 days of purchase from an authorized dealer to automatically extend your warranty for 2 years starting from the date of purchase. If you do not have web access, please contact your dealer for assistance.
- Page 6 Because the C5i runs cool, it can be placed in many This may scratch or mar the chassis finish. Do not system locations without compromise. We do not use harsh chemicals when cleaning the outside of recommend placing weights or other objects directly your C5i.
- Page 7 Upon Power Up: Front Panel Digital Lock Indicator: When switched on, the C5i will display its software When no digital input signal is present on a selected revision. The SP1 input will be selected and Soft input, the first decimal point on the display will blink Mute will be active.
- Page 8 Hard mute is indicated by 3 decimals on the display. The Mute function will punch through to any Bel Canto unit set in Variable Output mode. VOL+: Increases the volume setting in Variable Output mode.
- Page 9 24/96 data rate. The system will • switch is in the 1 position. automatically recognize the C5i as an audio converter enumerated as Bel Canto USB 2496 when using Windows 98 or later and Fuse Drawer with 5 amp/250V slow blow •...
- Page 10 Volume Control Punch Through The Volume Up, Down and Mute functions on the remote control will affect any Bel Canto unit in Variable Output mode regardless of whether PRE, DAC, CD or TUNER is selected. It is recommended that only the device with volume control closest to the power amps be in Variable Output mode.
- Page 11 Power Output 1% THD: 120W @ 4 ohms, 60W @ 8 ohms per channel Minimum Load: 3 ohms per channel Peak Output Current: 30 amperes Frequency Response: +/-3 dB 1.5Hz-90kHz, 4 ohm load THD+N: 0.003% 1W, 1kHz, 4 ohms IMD (CCIF): 0.0003%, 1W, 14:15kHz, 4 ohms Output noise: <50uVRMS A-weighted 10Hz-20kHz...
- Page 12 version 1.0...
