- Page 1 User's Guide and Warranty Information PRe6 ™ Multi-Channel Analog Pre-Amplifier Bel Canto Design, LTD. 212 Third Avenue North Minneapolis, MN 55401 Phone: (612) 317.4550 Fax: (612) 359.9358 www.belcantodesign.com Info@belcantodesign.com ©2002 Bel Canto Design, LTD...
- Page 2 Thank you for purchasing the Bel Canto Design PRe6. As the proud owner of a PRe6 you can expect high quality performance for years to come. The PRe6 pre- sented in the following pages is designed to maintain very high value, setting the benchmark for design, quality and sonic accuracy while maintaining our heritage of musicality and realism.
-
Page 3: Power Connection
Bel Canto Design. Power Connection The power supply on the PRe6 is pre- set for the proper national voltage. The power cable should have the correct plug for your local power sys- tem. -
Page 4: Placement And Initial Setup
Placement and Initial Setup Because the PRe6 runs so cool it can be placed in many system locations without compromise. We do not rec- ommend placing weights or other objects directly on the PRe6. This may mar or scratch the chassis fin- ish. -
Page 5: Front Panel And Remote Control
The PRe6’s sonic performance will start to stabilize after approximately 40 hours of continuous power up. Front Panel and Remote Control Volume Up - Increases the output gain in 0.5 dB increments from 0 to 100, 100 being maximum gain. Unity gain is 84.0. -
Page 6: Volume Control
After 3 seconds from pressing MUTE (after the display dims), pressing MUTE again will bring the PRe6 out of Soft mute. Pressing MUTE twice within 3 seconds (before the display dims) will fully mute the unit. The volume quickly ramps down and “MUTE”... -
Page 7: Back Panel Configuration
(CD, Phono, Tuner, etc) except the TAPE input. When the tape out- put of a tape deck is connected to the TAPE IN of the PRe6 you may moni- tor your recording. Standby - When in standby mode the red LED is engaged and audio output is hard muted. -
Page 8: Configuration (Of) Inputs
CONFIG?. CONFIGURATION (of) INPUTS Using the down arrow button, CON- FIGURATION (of) INPUTS menu allows you to customize your PRe6 in the following ways: Define Input (5.1, 7.1, Stereo, Disable), Name Input, Set MAIN Volume, Set SoftMute Vol(ume), Set Zone2 Volume. -
Page 9: Save Config
SAVE CONFIG? screen, then use the UP/DOWN arrow buttons to select SAVE YES/NO and then press ENTER. ERASE CONFIG ? This will reset your PRe6 to the facto- ry settings, use the UP/DOWN arrow buttons to select ERASE YES/NO and then press ENTER. -
Page 10: Specifications
Power Requirements • 110-120 VAC 50-60 Hz or 220-240 VAC 50-60 Hz Dimensions • 17.5” W x 14.5” D x 4.5” H (445 mm x 368 mm x 114 mm) Weight: 24lbs. (13 kg) © 2002 bel canto design, Ltd. Zone 2 Function When a 7.1 input is not enabled in... - Page 11 Remote Enter Button 8 Times Press Enter To Edit Any Screen Press Configuration LEFT/RIGHT Inputs Button IN 1: Press UP/DOWN Button © 2002 bel canto design, Ltd. Press Configuration Offset? LEFT/RIGHT Button Press UP/DOWN Button Press UP/DOWN Button Input 1 Press LEFT/RIGHT 5.1 SURROUND...
