Summary of Contents for Bel Canto eVo2
- Page 1 User's Guide and Operating Information eVo2 ™ eVo4 ™ eVo6 ™ Digital Power Processor Audio Power Amplifiers Bel Canto Design, LTD. 212 Third Avenue North Minneapolis, MN 55401 Phone: (612) 317.4550 Fax: (612) 359.9358 www.belcantodesign.com Info@belcantodesign.com ©2002-2004 Bel Canto Design, LTD...
- Page 2 Thank you for purchasing a Bel Canto Design eVo amplifier. As the proud owner of an eVo you can expect high quality performance for years to come. The eVo presented in the following pages is designed to maintain very high value, setting the benchmark for design, quality and sonic accuracy while maintaining our heritage of musicality and realism.The eVo amplifiers are multiple configuration,...
-
Page 3: Design Features
• THD and IMD <0.05% The eVo Digital Output Stage and Digital Power Processor The Bel Canto Design eVo digital out- put stage is of unique simplicity. The output uses 2 N channel MOSFET switches switching between the power supply rails. - Page 4 Any tampering of internal parts will imme- diately void your warranty. Complete and mail the Owner's Registration Card immediately in order to activate your warranty. © 2002-2004 bel canto design, Ltd. Warm-Up The eVo amplifier’s sonic perform- ance will continue to improve over the first several weeks of operation.
-
Page 5: Unpacking
If you lose or damage the packing materials or carton, please contact your dealer or distributor before attempting to transport the amplifiers. © 2002-2004 bel canto design, Ltd. Warning! The eVo amplifier’s power supply is preset for the proper national voltages before you receive it. -
Page 6: Line Level Inputs
RCA switch position will give the lowest noise operation. This will connect the system ground © 2002-2004 bel canto design, Ltd. Initial Setup Two inputs per channel are provided. The RCA jack is a standard input that accepts single-ended sources. - Page 7 High-power balanced mono operation can be obtained with the simple push of a button. Connect one input cable to any of the 4 input jacks on an eVo2 or input jack sets on an eVo4 or eVo6. Then depress the MONO/STEREO mode button.
- Page 8 LED remains on when the eVo is in normal operating mode. When the amplifier shuts down in protec- © 2002-2004 bel canto design, Ltd. tion mode a small red LED lights next to the front panel power switch. If...
-
Page 9: Amplifier Placement & Specifications
17.5 in x 14.5 in x 4.5 in Dimensions-mm WxDxH 44.5 cm x 37 cm x 11.5 cm Weight © 2002-2004 bel canto design, Ltd. We do not recommend placing weights or other objects directly on the eVo. This may mar or scratch the chassis finish. - Page 10 Bel Canto Design, LTD. 212 Third Avenue North Minneapolis, MN 55401 Phone: (612) 317.4550 Fax: (612) 359.9358 www.belcantodesign.com Info@belcantodesign.com ©2002-2004 Bel Canto Design, LTD eVo™ is a trademark of Bel Canto Design, LTD...
