Summary of Contents for Bel Canto REF500m
- Page 2 Design. The content of this manual is provided for information use only, is subject to change without notice, and should not be construed as a commitment by Bel Canto Design Limited. Bel Canto Design Limited assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
- Page 3 Explanation of symbols used in this manual or on the CAUTION rear/underside of the apparatus: • To reduce the risks of electric shock, do not remove the cover. • No user serviceable parts inside. This symbol is intended to alert the user to the •...
- Page 4 Fit a new 10 amp BS1362 approved fuse into the carrier GROUNDED. and push the carrier back into the plug. Bel Canto Design Ltd. declare that this product is in conformance The conformity of the designated product with the provisions of with the Low Voltage Directive 73/23/EEC and Electromagnetic...
- Page 5 Save all packing materials! They are custom missing, please contact your dealer, distributor or designed to protect the unit during transportation or Bel Canto Design. shipping. If the packing becomes lost or damaged, please contact your dealer or Bel Canto before attempting to transport your unit.
- Page 6 directly on the REF500 . This may scratch or mar Because the REF500 runs cool, it can be placed in the chassis finish. Do not use harsh chemicals many system locations without compromise. We do when cleaning the outside of your REF500 not recommend placing weights or other objects IMPORT ANT! Make all connections before...
-
Page 7: Rear Panel Connections
Rear Panel Connections Never Connect Either the Positive or Negative Speaker Output to Any Ground Contact! Connecting any Speaker Output on the REF500 to Ground will cause the amplifier to go into protection and could damage the amplifier and void the warranty. 1) Power Switch: Power is on when the switch is 3) Output Connections: Attach your loudspeaker to toggled to the I position and off in the O position. - Page 8 In case there is hum or ground noise, check that the RCA/XLR switch is in the correct position for the type of • connection being used. Ensure that the preamplifier or any source components are not producing hum by setting the preamplifier to a •...
-
Page 9: Specifications
Specifications Maximum Power Output: 500W 4 ohms, 250W 8 ohms Power Output 1% THD: 450W 4 ohms, 225W 8 ohms Minimum Load: 3 ohms Peak Output Current: 35 amperes Frequency Response: +/-3 dB 1.5Hz-70KHz, all loads THD+N: 0.003% 1W, 1KHz, 4 ohms IMD (CCIF): 0.0003%, 1W, 14:15KHz, 4 ohms Output noise:...
