1. LCD Display
2. Feed Key
3. Menu Key
4. Power On/Off Key
5. Info Setting Key
6. Battery Status Indicator
7. Error/Power Indicator
8. Media Cover Release Latch
9. Peel-Off Sensor
10. Printhead
11. Media Holder Lock Lever
12. Media Holder
13. Media Cover
14. Platen Roller
15. Label Peel Cover
16. Tear/Peel Bar
Note:
1 For LCD panel refer to pages 13 and 29

Printer Overview

1
3
15
5
7
9
10
12
14
16
11
