1. LCD Display
2. Feed
3. Menu
4. Power On/Off
5. Info Setting
6. Battery Status Indicator
7. Error Indicator
8. Media Cover Release Latch
9. Peel-off Sensor
10. Printhead
11. Media Holder Lock Lever
12. Media Holder
13. Media Cover
14. Platen Roller
15. Label Peeler Cover
16. Tear/Peeler Bar
Note:
1 The media sensor position is selectable by factory adjustment. Please refer to this figure for default settings.
(Default – center position)
2 For LCD panel, please refer to section 2.3.2 for more details

Printer Overview

1
3
15
5
7
9
10
12
14
16
