Page 1: Installation Guide
-Inch Roof-Mount DVD Player With DVD/CD/MP SYSTEM AVXMTG INSTALLATION GUIDE... -
Page 3: Table Of Contents
TABLE OF CONTENTS Important Notices ............................2 Materials Included in this Package ..................... 3 Removing and Installing Snap On Covers ..................4 General Vehicle Installation Approach ..................... 7 Connecting the Dome Lights ......................10... -
Page 4: Important Notices
System adjustments can be accomplished using the remote control, while product. seat-belts remain fastened. Enjoy your AUDIOVOX entertainment system but remember that the safety of all passengers remains the number one priority. An LCD panel and/or video monitor used for television reception, video or... -
Page 5: Materials Included In This Package
(3 pcs) *Note: The AVXMTG10U is supplied with a black snap-on shroud and screen cover. To install the pewter or shale snap-on shroud or screen cover, the black snap- on shroud and screen cover must be removed fi rst. See the following page for the removal process. -
Page 6: Removing And Installing Snap On Covers
REMOVING AND INSTALLING SNAP-ON COVERS Preparation Place the unit on a soft surface to avoid damaging the plastic. Materials Required Shroud Screen Cover Pry Tool 10” Overhead LCD Monitor with DVD Player Disconnecting the Screen Cover “C” “B” “A” “C” 1. - Page 7 Installing the Screen Cover “D” “D” “D” “D” 1. Open the LCD screen. 2. Hook the two tabs “D” at the bottom edge of the screen cover into the notches on the bottom edge of the LCD screen. 3. Snap the opposite side of the screen cover over the hinges.. Disconnecting the Shroud “E”...
- Page 8 Installing the Shroud “F” “F” “F” Expanded view 1. Open the LCD screen. 2. Slide the shroud over the unit. The shroud will snap into place at locations “F”.
-
Page 9: General Vehicle Installation Approach
GENERAL VEHICLE INSTALLATION APPROACH 1. Decide upon the system confi guration and options that will be installed. 2. Review all manuals to become familiar with electrical requirements and hookups. 3. Decide upon the mounting locations of all components and the method of mounting. 4. - Page 10 GENERAL VEHICLE INSTALLATION APPROACH Installing Unit to Roof Roof Roof Support Headliner Mounting Bracket Self-drilling Screws Video Unit M5 Screw...
- Page 11 GENERAL VEHICLE INSTALLATION APPROACH *Optional Relay Box Signal Harness To Dome Lights See “Connecting the Dome Lights” 6 Pin Power Harness 2 Pin Power Wire Harness with Choke AV IN 3 RCA Jack Pigtail...
-
Page 12: Connecting The Dome Lights
CONNECTING THE DOME LIGHTS The dome lights in the video monitor require three connections to the vehicle's wiring. There are two common types of dome light circuits used, positive or negative switched. Positive systems supply voltage to the interior lights to turn them on. Negative switched systems apply ground to illuminate the bulbs. To determine which system you have, you must locate the wires at the dome light. - Page 13 Positive Switched Dome Lighting To 6 pin Red/black-Lamp on constant connector Black/red-Lamp common +12 VDC on Monitor Purple/brown-Lamp Auto constant +12 VDC Factory Door Ajar Switch or Body Control Computer...
- Page 14 Negative Switched Dome Lighting Red/black-Lamp on To 6 pin Black/red-Lamp common connector Purple/brown-Lamp Auto constant +12 VDC constant +12 VDC Factory Door Ajar Switch or Body Control Computer...
- Page 15 This page intentionally left blank.
- Page 16 © 2010 AUDIOVOX,150 Marcus Blvd. Hauppauge, NY 11788 128-8902...
