- Page 1 D1917 PORTABLE 9" LCD MONITOR AND DVD PLAYER PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com...
- Page 2 An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used for vehicle information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for television reception, video or DVD play, the LCD panel or video monitor must be installed so that these features will only function when the vehicle is in “park”...
-
Page 3: Table Of Contents
Content A. Introduction ... 4 B. Cautions and Warnings ... 4 C. Contents ... 6 D. Powering and installation ... 6 E. Controls, Indicators, and Connectors ... 7 F. Loading and Playing a Disc ... 8 G. Basic Operation... 9 H. -
Page 4: Introduction
A. Introduction Thank you for choosing the D1917 portable DVD player. The main features include a 9" Digital Screen (16:9 Aspect Ratio) Liquid Crys- tal Display (LCD) monitor and a DVD player. The unit also contains a 3 in 1 card reader and a USB port. The unit is designed for use with SD/MMC, MS memory cards and USB memory devices. - Page 5 result in a fire or electric shock). Do not place anything heavy on the unit. To ensure proper ventilation and proper operation, never cover or block the slots and openings with a cloth or other material. Keep the unit away from an open flame such as fire, candle etc. Replacing the battery incorrectly is hazardous.
-
Page 6: Contents
7.Regional Coding Both the DVD player and disc are coded by region. These regional codes must match in order for the disc to play. If the codes don’t match, the disc won’t play. This unit’s code is region 1. DVD’s with other regional codes cannot be played in this unit C. -
Page 7: Controls, Indicators, And Connectors
E. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 2) 1) Battery Release Button 2) DC 9V Input Jack 3) AV Jack 4) AV In/Out Switch 5) USB Port 6) Power ON/OFF Switch 7) SD/MMC/MS Card Slot 8) Power LED 9) Remote Control Sensor 10) Cover Open Switch * Connecting to headphone jack number 1 will disable the... -
Page 8: Loading And Playing A Disc
19) Play/Pause Button F. Loading and Playing a Disc a. After connecting power to the unit, power on the DVD player with the power switch. The power indicator will light. b. Open the disc tray by sliding the OPEN switch in the direction of the arrow. -
Page 9: Basic Operation
G. Basic Operation POWER OPEN PAUSE STOP PLAY Skip + NEXT Skip - PREVIOUS FORWARD REVERSE ANGLE LEFT/RIGHT/UP/DOWN ENTER NUMBERS MENU REPEAT DISPLAY SUBTITLE AUDIO SETUP WIDE PDF created with FinePrint pdfFactory Pro trial version Turn the unit on/off Remove/load the disc Press to pause play and again to re-start play. -
Page 10: Menu
H. Menu A DVD is divided into sections called titles and chapters. When you play a DVD, the root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu. - Page 11 2. SUBTITLE During disc playback press ‘SUBTITLE’ to select the subtitle language you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed. If there are mul- tiple languages press ‘SUBTITLE’ again to select another subtitle lan- guage.
-
Page 12: All Repeat
4. A-B REPEAT a. During playback press ‘A-B’ to set the Starting Point A. b. Press ‘A-B’ a second time to set the Ending Point B. The player will repeatedly play the part between Point A and Point B. c. Press A-B a third time to cancel A-B repeat and resume normal playback. -
Page 13: Playing Audio Cds
6. ZOOM During playback press ‘ZOOM’ to enlarge the picture by 2X, 3X , 4X. (1) Press “ZOOM”one time, the picture will be enlarged 2X. (2) Press “ZOOM” a second time, the picture will be enlarged 3X. (3) Press “ZOOM” a third time, the picture will be enlarged 4X. (4) Press “ZOOM”... -
Page 14: Playing Mp3 Discs
Total Elapsed: The current track playing and the total time that the Total Remain: Display Off: USING THE1/ALL REPEAT FEATURE The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: • Track- repeats the track that is playing. •... -
Page 15: Using The Repeat Feature
1. Press the the left side of the screen. 2. Press ENTER to select the highlighted folder. The songs avail- able in the folder will be listed. 3. Use the ENTER to select and begin playback of the highlighted song. 4. -
Page 16: Connecting To Other Electronic Equipment
L. Connecting to other Electronic Equipment 1. Connecting to a TV or another monitor a. Set the AV In/Out Switch to the “Out” Position. b. Connect one end of the audio/video cable’s black (1/8” plug) plug into the unit’s DVD AV jack and connect the other end to the AUDIO INPUT jacks on your TV or Monitor using the AV adapter cable (white = left audio channel, red = right audio channel, yellow = video). -
Page 17: Playing Jpeg Files
M. Playing JPEG Files 1) Load the JPEG Disc into tray. 2) The DVD player will display a folder and the JPEGS contained within the folder in a thumbnail view. Choose the picture you desire by using the “UP” and “DOWN” buttons. -
Page 18: Setup
Off: The screen will not display the angle mark. c) Screen Saver On: Enables screen saver. Note: The DVD player will enter the Screen Saver mode after ap- proximately five minutes if the same image remains on the screen. Off: Disables screen saver. - Page 19 Note: The Last Memory position function will only work when the disc tray is opened. 2.Video Quality Setup 1) In Setup menu, press the Setup” and setup page. 2) Press the ENTER button, “Brightness” is highlighted. 3) Press the setup page. 4) Press 5) Press the ENTER to confirm your selection.
- Page 20 a) Audio: Selects the audio language you desire. Use the UP or DOWN buttons to select another audio language. b) Subtitle: Selects the subtitle language you desire. Use the UP or DOWN buttons to select another subtitle language. To turn subtitles OFF use the UP or DOWN button and select OFF.
-
Page 21: Specifications
Please fully charge the battery prior to first use. NOTE: When the DVD player is used with the battery as a power source, ensure that the battery has been charged for at least eight hours prior to connecting it to the DVD player. - Page 22 2. To charge the battery, please connect the power jack directly into the DVD player and leave the POWER switch in the OFF position. PDF created with FinePrint pdfFactory Pro trial version F (10...
- Page 23 2. Disconnect the DVD player from the AC power source. 2. Flip down the monitor. 3. Push the battery towards the rear of the DVD player until it locks into position. The lock position is indicated by a click. The battery will fit tightly to the player.
-
Page 24: Troubleshooting
Q. Troubleshooting PROBLEM No sound or distorted sound Can’t advance through a movie The icon ( ) appears on screen Picture is distorted No forward or reverse scan PDF created with FinePrint pdfFactory Pro trial version SOLUTION • Make sure your DVD is connected properly. Make sure all cables are securely inserted into the appropriate jacks. -
Page 25: Troubleshooting (Cont)
Troubleshooting (Cont) PROBLEM IR sensor inoperative Disc won’t play Play starts, but then stops immediately PDF created with FinePrint pdfFactory Pro trial version SOLUTION • Verify that the batteries in the remote are fresh. • Verify that the remote sensor eye is not obstructed. -
Page 26: Day Limited Warranty
AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor. - Page 27 © 2007 Audiovox Electronics Corporation 128-8056 PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com...
