Regency Sunrise U32S-NG5 Owners & Installation Manual

Gas insert
Hide thumbs Also See for Sunrise U32S-NG5:

Advertisement

Quick Links

u32 sunrise
www.regency-fire.com
WarninG:
improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. refer to
this manual. for assistance or additional information consult
an authorized installer, service agency or the gas supplier.
for Your safetY
Do not store or use gasoline or other flammable vapours and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by an authorized
installer, service agency or the gas supplier.
Tested by:
918-788a
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
fpi fireplace products international ltd. 6988 Venture st., delta, Bc canada, V4G 1H4
Gas insert
owners &
installation Manual
MODELS: U32S-NG5
for Your safetY
What to do if you smell gas:
do not try to light any appliance
do not touch any electrical switch:
do not use any phone in your
building.
immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
if you
cannot reach your gas
supplier, call the fire department.
U32S-LP5
01/17/12
