Related Manuals for Uniden DECT 3115
Summary of Contents for Uniden DECT 3115
- Page 1 DECT 3115 For more exciting new products please visit our website: Australia: www.uniden.com.au New Zealand: www.uniden.co.nz...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: • This unit is NOT waterproof. DO NOT expose this unit to moisture. • DO NOT expose this unit to rain. - Page 3 5 of each • Battery cover • If any items are missing or damaged, contact your place of purchase immediately. Never use damaged products! • Need help? Get answers at our website: www.uniden.com.au for Australian model www.uniden.co.nz for New Zealand model.
-
Page 4: Table Of Contents
Contents InstallIng your phone ..............5 gettIng to know your phone ............. 6 Parts of the Base ........................6 Parts of the Handset ......................6 Using the Handset Menu ..................... 9 usIng your phone ...................... Using the Caller ID and Redial Lists ................. 12 Using Call Waiting ........................ -
Page 5: Installing Your Phone
InstallIng your phone Charge the Battery 1. Unpack all handsets, battery packs, and battery covers. 2. If you need to remove a cover, press in on the notch and slide the cover down and off. 3. Line up the battery connector with the jack inside the handset;... -
Page 6: Getting To Know Your Phone
gettIng to know your phone parts of the Base What it does In standby: FIND HS Find Handset page all handsets Charging Contacts parts of the handset MENU/ SELECT SPEAKER TALK/ FLASH DOWN PHONEBOOK 12-key dial pad #DND REDIAL/PAUSE INTCOM/CLEAR Microphone MESSAGE/MUTE Charging... - Page 7 Key Icon What it does • In standby or during a call: open the phonebook. PHONEBOOK • In the menu: go back to the previous screen. • When entering text: move the cursor to the left. Switch a normal call to the speakerphone (and back). SPEAKER • In standby: start a telephone call on your land line (get TALK/FLASH...
-
Page 8: Reading The Display
reading the display The table shows the possible Status status icons and what they icons mean. Since the icons appear based on what the phone is Current doing, you won’t see all the call info 1300366895 icons at the same time. Time &... -
Page 9: Using The Handset Menu
using the handset Menu Press MENU/SELECT open the menu. Press MENU/SELECT to choose Handset Setup the current option. Date & Time Handset Setup Press T-coil Handset Setup PHONEBOOK DOWN go back a screen Ringer Tones Handset Setup rotate through the options. -
Page 10: Entering Text On Your Phone
Date & Time Menu Use this menu to set the clock. Enter the date and time (DD/MM/YY); select AM or PM. Use to move the cursor past a digit without changing it. If you have CID service, you can set it to provide the time (Global Setup/ Time Adjustment). -
Page 11: Using Your Phone
switch between upper and lower case letters rotate through the punctuation and symbols usIng your phone This section explains the most common functions on the phone. To... Earpiece Speaker make a call, dial the Press TALK/FLASH. Press SPEAKER. number, then answer a call Press TALK/FLASH. -
Page 12: Using The Caller Id And Redial Lists
using the Caller Id and redial lists Caller ID (CID) is a service available from your telephone provider that shows the phone number (and sometimes the caller’s name) of the incoming calls. Contact your telephone provider for more information. Caller ID list Redial list • The phone saves the information • Each handset remembers... -
Page 13: Using Call Waiting
using Call waiting If you get a Call Waiting call, the phone can sound a tone and display any CID information received for the waiting call. For Australia: Press TALK/FLASH and then press 2 to accept the waiting call. The first caller is put on hold, and you will hear the new caller after a short pause. -
Page 14: Adding Phonebook Entries
adding phonebook entries With the phone in standby, open the phonebook. Press MENU/SELECT and select Create New. Enter a name, number, and then assign a personal ring if desired. • Enter the phone number (up to 20 digits) exactly as you would dial it. • If you need the phone to wait before sending the next set of digits, press to insert a 3-second pause. -
Page 15: Using Special Features
usIng speCIal Features power Failure Back up system The charged handset temporarily supplies power to the base unit, when a power failure occurs (power failure mode). You can then make and receive calls using a handset. None of the keys on the base unit are functional during the power failure mode. -
Page 16: Dnd (Do Not Disturb) Mode
# some of the functions are not available under the power failure back up stem. you cannot edit the phonebook (For eg, store a number). redial/CId will not be stored. dnd (do not disturb) Mode You can silence the ringers on the base and all handsets for a specific period of time. -
Page 17: Call Transfer
Call transfer To... Press... transfer a call INTCOM/CLEAR. The phone puts the call on hold and prompts you to select the handset you want to page. When the other handset accepts the call, you’ll be disconnected (press TALK/FLASHto rejoin the call). cancel a transfer TALK/FLASH to return to the call. -
Page 18: Chain Dialing
Chain dialing If you often have to enter a series of digits or a code number during a call, you can save that code number to a phonebook entry and use the phonebook to send the code number. 1. Make your call normally. 2. -
Page 19: Important Information
IMportant InForMatIon solving problems If you have any trouble with your phone, check this section first. If you need help, visit the customer support page of our website listed on the front cover. General Problems Possible Solutions • Check the telephone cord No handsets can make or receive connection. - Page 20 • Check for interference from There’s a lot of noise or static on appliances (microwave ovens, the line TVs, etc.) or wireless devices (baby monitors, WiFi equipment, etc.). Move the handset or base away from the interference source. • If you use a telecoil hearing aid, turn on T-coil mode (see page • If you have any service that uses the phone line, add a DSL or...
-
Page 21: Resetting Handsets
Installing a line Filter or dsl Filter A telephone line filter or DSL filter prevents services that use the phone line from causing interference on your phone. To get a line filter, contact your service provider or look in an electronics store. Plug the filter into the telephone wall jack and plug the base into the filter. -
Page 22: Ac Adaptor And Battery Information
aC adaptor and Battery Information AC Adaptor Base Charger Part number PS-S0635YL3 AAD-600S(M) Input voltage 100-240V AC, 50/60Hz 100-240V AC, 50/60Hz Output voltage 6V DC @ 350mA 9V DC @ 210mA • Use only the supplied AC adaptors. • Use the proper adaptor for the base and any chargers. • Do not place the unit in direct sunlight or subject it to high temperatures. -
Page 23: Wall Mounting The Base
wall Mounting the Base This phone can be mounted on any standard telephone wall plate using the supplied wall-mount bracket. Route the telephone cord through the hole of the wall-mount bracket. Connect the AC adaptor and the telephone cords as shown. Line up the four tabs on the wall-mount bracket (two at the top and two at... - Page 24 6 Place the mounting slots over the pins on the wall plate. 7 Slide the base down to lock it into place. Wall plate (To AC outlet) removing the wall-mount bracket At the bottom of the base, pinch the two “nose” of the wall-mount bracket as ahown, and then slide the bracket away from the base.
-
Page 25: Index
Index Privacy Mode 17 Any Key Answer 9 Auto Talk 9 Redial 7 Register a Handset 21 Resetting the Handset 21 Battery 22 Ringer 9 Caller ID 12 Voice Mail 18 Call Transfer 17 Call Waiting 13 Chain Dialing 18 Wall Mounting 23 Conference Calling 16 Warranty 26... -
Page 26: One-Year Limited Warranty
Warrantor The warrantor is either Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”) or Uniden New Zealand Limited (“Uniden NZ”) as the case may be. Terms of Warranty Uniden Aust/NZ warrants to the original retail purchaser only that the DECT 3115 (“the Product”), will be free from defects in materials and craftsmanship... - Page 27 Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden at the addresses shown below. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
- Page 28 ©2012 Uniden Australia Pty Ltd/Uniden New Zealand Limited Printed in Vietnam U01UN504BZA(0)
