- Page 1 INSTALLATION MANUAL Millenium II 4000 Release Date: April 29, 2003 Publication Number: 620919547INS Revision Date: May 13, 2013 Revision: C Visit the IMI Cornelius web site at www.cornelius.com for all your Literature needs.
-
Page 2: Contact Information
Commercial Warranty. Cornelius will not be responsible for any repair, replacement or other service required by or loss or damage resulting from any of the following occurrences, including but not limited to, (1) other than normal and proper use and normal... -
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Instructions ..............1 Read and Follow ALL Safety Instructions . -
Page 4: Safety Instructions
Only trained and certified electrical, plumbing and refrigeration technicians should service this unit. ALL WIRING AND PLUMBING MUST CONFORM TO NATIONAL AND LOCAL CODES. FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY, DEATH OR EQUIPMENT DAMAGE. © 2003-2013, IMI Cornelius Inc. - 1 - Publication Number: 620919547INS... -
Page 5: Safety Precautions
Before shipping, storing, or relocating the unit, the unit must be sanitized and all sanitizing solution must be drained from the system. A freezing ambient environment will cause residual sanitizing solution or water remaining inside the unit to freeze resulting in damage to internal components. Publication Number: 620919547INS - 2 - © 2003-2013, IMI Cornelius Inc. -
Page 6: General Information
Shipping: 140 lbs. (63.5 kg) Operating: 220 lbs. (100 kg) Concentrate Supply Line Length: 50 feet (15.2 m) Total Maximum 15 feet (4.5 m) Vertical Maximum Approvals: UL CUL © 2003-2013, IMI Cornelius Inc. - 3 - Publication Number: 620919547INS... -
Page 7: Installation
2. Cut the banding strap and remove the exterior carton sleeve, internal fillers and plastic bag around the dis- penser. Carefully inspect for damage. NOTE: IMI Cornelius is not responsible for damaged freight. If damage is found, you must save all packaging material and contact the freight carrier. Failure to contact the carrier within 48 hours of receipt may void your claim. - Page 8 10. LED Diagnostics LED diagnostic lights are mounted on the control board to assist in troubleshooting. There is one green LED and one red LED. Green LED Red LED © 2003-2013, IMI Cornelius Inc. - 5 - Publication Number: 620919547INS...
- Page 9 C. Turn off the water supply and connect the concentrate lines to their respective BIB. D. Depress and hold each start button until concentrate is observed flowing from the nozzle. E. Turn on the water supply. Publication Number: 620919547INS - 6 - © 2003-2013, IMI Cornelius Inc.
- Page 10 Try dislodging the debris by pressing the dispense switch several times or by turning the flow control adjustment screw all the way in and out several times. © 2003-2013, IMI Cornelius Inc. - 7 - Publication Number: 620919547INS...
-
Page 11: Cleaning & Sanitizing
B. Submerse the bag connector and bag valve assembly into the bucket of sanitizing solution. C. Press and hold the dispense button until sanitizing solution is dispensed through the mixing valve nozzle. Publication Number: 620919547INS - 8 - © 2003-2013, IMI Cornelius Inc. -
Page 12: Daily Cleaning & Maintenance
A. The ventilation grilles and the condenser fins should be cleaned periodically to maintain efficient refrigera- tion and to avoid compressor failure. The condenser fins can be cleaned with a vacuum cleaner or a soft bristle brush. © 2003-2013, IMI Cornelius Inc. - 9 - Publication Number: 620919547INS... - Page 13 M. Install the top, side and rear panels as well as the merchandiser. Connect the harnesses from the mer- chandiser and top panel to their appropriate terminals. N. Plug the dispenser into the electrical outlet and turn the unit on. Publication Number: 620919547INS - 10 - © 2003-2013, IMI Cornelius Inc.
-
Page 14: Panel Removal
Figure 3. 2. Depress the center of the merchandising panel. Figure 4. 3. Slide the top panel about 1 inch toward the rear of the unit and lift it off. © 2003-2013, IMI Cornelius Inc. - 11 - Publication Number: 620919547INS... - Page 15 4. Disconnect the wires from the key and power switches (black wires - key switch; brown wires - power switch). Figure 6. 5. Remove the cup rest and drip tray assembly. Figure 7. 6. Remove the splash panel by lifting up and pulling the bottom out. Publication Number: 620919547INS - 12 - © 2003-2013, IMI Cornelius Inc.
- Page 16 3 on the unit base. Figure 9. Figure 10. Figure 11. 8. Lift the rear panel up and off. Figure 12. 9. Disconnect the agitator motor wires to remove the merchandiser. Figure 13. © 2003-2013, IMI Cornelius Inc. - 13 - Publication Number: 620919547INS...
- Page 17 Figure 15. D. Remove the retaining clips from both sides of the water tank before lifting refrigeration chassis. E. Lift the refrigeration out of the water bath. Figure 16. Publication Number: 620919547INS - 14 - © 2003-2013, IMI Cornelius Inc.
- Page 19 IMI Cornelius Inc. www.cornelius.com...
