IDC PRO SSD REPLACEMENT INSTRUCTIONS
S
O
AFETY
VERVIEW
•
Read and follow ALL SAFETY INSTRUCTIONS in this manual and any warning/caution labels on the unit
(decals, labels or laminated cards).
•
Read and understand ALL applicable OSHA (Occupational Safety and Health Administration) safety
regulations before operating this unit.
S
A
AFETY
LERT SYMBOL
This is the safety alert symbol. When you see this in the manual or on the unit, be alert to the
potential of personal injury or damage to the unit.
T
A
YPES OF
LERTS
Indicates an immediate hazardous situation which if not avoided WILL result in serious
!
DANGER:
injury, death or equipment damage.
Indicates a potentially hazardous situation which, if not avoided, COULD result in serious
!
WARNING:
injury, death, or equipment damage.
Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or
!
CAUTION:
moderate injury or equipment damage.
S
T
AFETY
IPS
•
Carefully read and follow all safety messages in this manual and safety signs on the unit.
•
Keep safety signs in good condition and replace missing or damaged items.
•
Learn how to operate the unit and how to use the controls.
•
Do not let anyone operate the unit without proper training. This appliance is not intended for use by very
young children or infirm persons without supervision. Young children should be supervised to ensure that
they do not play with the appliance.
•
Keep your unit in proper working condition and do not allow unauthorized modifications to the unit.
Revision Date: August 02, 2019
© 2019, Cornelius Inc.
IDC Pro - SSD Replacement Instructions
www.cornelius.com
- 1 -
Revision: A
Publication Number: 629097779INS

Advertisement

loading
Need help?

Need help?

Do you have a question about the IDC Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cornelius IDC Pro

Summary of Contents for Cornelius IDC Pro

  • Page 1 IDC Pro - SSD Replacement Instructions IDC PRO SSD REPLACEMENT INSTRUCTIONS AFETY VERVIEW • Read and follow ALL SAFETY INSTRUCTIONS in this manual and any warning/caution labels on the unit (decals, labels or laminated cards). • Read and understand ALL applicable OSHA (Occupational Safety and Health Administration) safety regulations before operating this unit.

  • Page 2: Safety Instructions

    IDC Pro - SSD Replacement Instructions AFETY NSTRUCTIONS WARNING: Before starting installation, read and understand all safety label and warnings on the machine. Also review and understand all safety instructions in the owners, installation and service manuals. Failure to comply could result in serious injury, death or damage to the equipment.
  • Page 3 MPORTANT Before replacing SSD, if unit is operational or you have a second IDC PRO unit with an identical brand lineup be sure to get a back up copy of the unit’s configuration onto a USB memory stick (see troubleshooting pages 13-17 Exporting brand configuration from a pre-existing machine “...

  • Page 4: Tools Required

    IDC Pro - SSD Replacement Instructions OOLS EQUIRED 1. Large Phillips Screw Driver 2. Fine Tip Phillips Screw Driver NOTE: Wear a properly grounded ESD wrist strap if available & minimize body contact with electronic components. SSD R EPLACEMENT NSTRUCTION...
  • Page 5 IDC Pro - SSD Replacement Instructions Table 1: (Continued) Carefully undo the lock screw to unlock the SSD. NOTE: DO NOT LOOSE THIS PART! Figure 3. Carefully replace the SSD with a new part. Figure 4. Carefully secure the lock screw to lock the SSD.
  • Page 6 IDC Pro - SSD Replacement Instructions Table 1: (Continued) Connect the Fan harness and replace the Cover. Make sure the silicone (white glue) doesn’t get in the way of the pins and connector. Figure 6. A. Close the SBC cover B.

  • Page 7: Troubleshooting

    IDC Pro - SSD Replacement Instructions ROUBLESHOOTING CREEN ESOLUTION OMES NCORRECT Table 2: Step Action Figure If image on the screen appears to be too far zoomed in or out, the screen resolution will need to be adjusted in the BIOS settings.
  • Page 8 IDC Pro - SSD Replacement Instructions Table 2: (Continued) “North Bridge” should already be highlighted, press the ENTER key. Figure 11. Use the down arrow key to highlight “LVDS Panel Type” and press ENTER key. Figure 12. From the dropdown list select the “1920 x 1080, 48 bit, 60hz”...
  • Page 9 IDC Pro - SSD Replacement Instructions Table 2: (Continued) LVDS Panel type will now read “1920 x 1080, 48 bit, 60hz”. Figure 14. Press F4 on the keyboard to Save and Exit. On the “Save & Exit Setup” screen, highlight “Yes”...
  • Page 10 IDC Pro - SSD Replacement Instructions ROUBLESHOOTING APPING RANDS Table 3: Step Action Figure Display the keypad screen by tapping each corner of the video screen start- ing in the upper right corner and con- tinuing to tap each corner in a counterclockwise direction, in the form of a “C”.
  • Page 11 IDC Pro - SSD Replacement Instructions Table 3: (Continued) The “Service UI” screen is displayed. Unit Setup Figure 18. Press the “Unit Setup” button to display the Unit Setup screen. Brand Mapping Figure 19. Press the “Brand Mapping” button to open the Brand Mapping screen.
  • Page 12 IDC Pro - SSD Replacement Instructions Table 3: (Continued) The Brand Selection screen opens and you can select the brand to be mapped to the valve location. Figure 21. Repeat Steps 4 & 5 for each location desired. When all the flavors on the RIGHT are mapped, press the LEFT button and repeat Steps 4 & 5 for the LEFT side or, if the setup will be identical on the LH &...
  • Page 13 IDC Pro - SSD Replacement Instructions ROUBLESHOOTING XPORTING RAND ONFIGURATION EXISTING ACHINE If you have an available machine with the same brand configuration, you can copy it over to another machine using a USB Stick. From the unit you need to obtain configuration file from the steps as follows:...
  • Page 14 IDC Pro - SSD Replacement Instructions Table 4: (Continued) Unplug one of the items in the USB ports on the backside of the door and insert USB drive into the open USB slot. Figure 24. Choose the “Backup & Restore”...
  • Page 15 IDC Pro - SSD Replacement Instructions Table 4: (Continued) Screen will go black and text will start to stream through the screen. Figure 27. Once that is finished, screen will go back to normal. Close out of Service menus and remove USB stick from back of door.
  • Page 16 IDC Pro - SSD Replacement Instructions ROUBLESHOOTING OADING ONFIGURATION Table 5: Display the keypad screen by tapping each corner of the video screen starting in the upper right corner and continuing to tap each corner in a counterclockwise direction, in the form of a “C”.
  • Page 17 IDC Pro - SSD Replacement Instructions Table 5: (Continued) Choose the “Backup & Restore” option from the “Service UI” menu. Figure 32. In the “Backup & Restore” menu select the “Load button”. Figure 33. A window will come up showing “Attached Media”.
  • Page 18 IDC Pro - SSD Replacement Instructions Table 5: (Continued) Select the “refresh-config.tar.gz” file and press “OK” button. Figure 35. screen will black configuration file will begin to upload onto the unit. Figure 36. Once the information has transferred you will be back to the “Backup & Restore”...
  • Page 19 IDC Pro - SSD Replacement Instructions Table 5: (Continued) Remove USB Stick from the screen and exit the service menus. Figure 38. Reconnect the cable that was disconnected to put in the USB stick. © 2019, Cornelius Inc. - 19 -...
  • Page 20 IDC Pro - SSD Replacement Instructions Publication Number: 629097779INS - 20 - © 2019, Cornelius Inc.
